ALTAIR IPcom Series: Model IPB-306
13
USAGE EXAMPLES
Usage Examples
Basic 2 Channel Party Line System
IPB-306 beltpacks are shipped from the factory per-configured as a two channel beltpack each assigned to a
Party Line group. To start using the system, simply connect the beltpacks to an Ethernet switch equipped
with PoE power capability (otherwise connect DC power to each beltpack as shown). It's that easy!
Simple example of a Party Line system with a PoE switch
PoE Switch
Simple example of a Party Line system with a switch without PoE
Non PoE Switch
