Altair IPcom IPB-306 User Manual page 11

MENU
Menu Structure
Level 1
MAIN MENU
NOTE:
At any point in the menu by pressing the
ESC button (left rotor) will return to the
previous level.
If you are at level 1, the menu window
will close and you will return to normal
operating mode.
ALTAIR IPcom Series: Model IPB-306
Level 2
AUDIO
INDICATORS
VISIBILITY
LOCK
PRIVATE CALL
REPLAY
BLUETOOTH
Level 3
MIC GAIN
SIDETONE GAIN
P. INPUT VOLUME
MAIN VOLUME
CHANNEL 1 VOLUME
CHANNEL 2 VOLUME
...
Press ESC
CHANNEL 6 VOLUME
NAME
BUZZER
Press ESC
VIBRATOR
CONTRAST
BRIGHTNESS
LED BRIGHTNESS
Press ESC
ALL LIGHTS OFF CFG
LOCK KEYS CFG
Press ESC
LOCK KEYS
IPB-316 Beltpack 1
IPB-316 Beltpack 2
Press ESC
...
BLUETOOTH
BLUETOOTH KEY
PAIRING
Press ESC
DELETE PAIRS
9
Parameter
[1-10]
[1-5]
[1-16]
[1-16]
[1-16]
[1-16]
[1-16]
[Type name]
[ON-OFF]
[ON-OFF]
[1-10]
[1-16]
[1-10]
[ON-OFF]
[Sect.A / Sect.B / ALL]
[ON-OFF]
Calling...
Calling...
[ON-OFF]
Enter code...
Pairing Mode...
[NO-YES]
