Altair IPcom IPB-306 User Manual page 10

MENU
Menu
Menu Elements
Navigation through the Menu window
The Menu will be displayed by briefly pressing the MENU key, if the device is
configured with 2 channels or by holding the MENU key for 4 or 6 channels. To scroll
through the different elements of the Menu, the right rotor of the IPB-306 will be
used. Turning the rotor clockwise will scroll down and turning the rotor
counterclockwise will scroll up in the Menu.
To enter a sub-menu, simply select it and then press the same rotor (ENTER).
To go back in the different sub-menus you must press the left rotor.
Menu window elements
Each of the sub-menus will give access to the visualization and modification of the values of different
parameters of the device:
• 
AUDIO:




• 
INDICATORS:


• 
VISIBILITY:



• LOCK: 

• PRIVATE CALL: It allows establishing a point-to-point connection with any of the devices that belong
to the system. This sub-menu will list the name of each of the devices that belongs
to the system and are active right now.
•
REPLAY: It will play the last few seconds of listening received on the device. The number of
seconds
Settings>General
• 
BLUETOOTH:



ALTAIR IPcom Series: Model IPB-306
Mic Gain: Modifies the microphone gain. [1-10]
Sidetone Gain: Modifies sidetone (own voice on listening) gain. [1-5]
Program Input Volume: Modifies the volume of the Program Input. [1-16]
Main Volume: Modifies the overall volume of the device. [1-16]
Channel 1-6 Volume: Modifies the individual volume of each channel. [1-16]
Name: Shows the name of the device and allows to modify it.
Buzzer: Turns Buzzer on or off on the device. [ON-OFF]
Vibrator: Turn Vibrator on or off on the device. [ON-OFF]
Contrast: Modifies the contrast of the display. [1-16]
Brightness: Modifies the brightness of the display. [1-16]
LED Brightness: Modifies the brightness of the keys LEDs. [1-10]
All Lights off CFG: When this parameter is activated, level 1 of LED Brightness
completely disables the LEDs of all the keys. [ON-OFF]
Lock Keys CFG: Allows to select the section to block. [Sect. A | Sect. B | ALL]
Lock Keys: Locks the selected keys on the device. [ON-OFF]
played is defined
Bluetooth: Turns Bluetooth on or off. [ON-OFF]
Bluetooth Key: Allows you to assign a pin for pairing. Not very often used.
Paring: Activates pairing mode.
Delete Pairs: Removes all paired devices. [NO-YES]
through the NEBULA
8
Users>Advanced
