- Page 1 ISR215 Ruggedized Edge Computer with NXP i.MX 8M Plus - ARM Cortex-A53 Quad Processor User’s Manual Version 1.0 (September 2024)
- Page 2 No part of this publication may be reproduced, copied, stored in a retrieval system, translated into any language or transmitted in any form or by any means, electronic, mechanical, photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc. (hereinafter referred to as “IBASE”).
- Page 3 • Cadmium: 100 ppm • Mercury: 1,000 ppm • Lead: 1,000 ppm • Bis(2-ethylhexyl) phthalate (DEHP): 1,000 ppm • Butyl benzyl phthalate (BBP): 1,000 ppm • Dibutyl phthalate (DBP): 1,000 ppm • Diisobutyl phthalate (DIBP): 1,000 ppm ISR215 User’s Manual...
-
Page 4: Important Safety Information
Do not try to repair, disassemble, or make modifications to the device. Doing so will void the warranty and may result in damage to the product or personal injury. CAUTION Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries by observing local regulations. ISR215 User’s Manual... -
Page 5: Warranty Policy
The arrangement of the peripherals • Software used (such as OS and application software) 3. If repair service is required, please apply for an RMA number from the IBASE’s website or contact your distributor or sales representative for assistance. ISR215 User’s Manual... -
Page 6: Table Of Contents
BSP Source Guide ..............25 Building BSP Source ................26 4.1.1 Preparation ................26 4.1.2 Building release ..............27 4.1.2.1 For yocto/Ubuntu/debian ............27 4.1.2.2 For android ................27 4.1.3 Installing release to board ............27 Appendix ...................... 29 ISR215 User’s Manual... -
Page 7: Chapter 1 General Information
Chapter 1 General Information The information provided in this chapter includes: • Features • Packing List • Specifications • Product View • Dimensions... -
Page 8: Introduction
General Information 1.1 Introduction The ISR215 is a rugged edge computer powered by the NXP i.MX 8M Plus ARM Cortex-A53 quad processor, designed for demanding industrial applications. It features 3GB LPDDR4, 16GB eMMC with an SD expansion slot, and multiple connectivity options including USB, HDMI, Ethernet, and 5G via an M.2 B-Key (3052). -
Page 9: Specifications
General Information 1.4 Specifications Product Name ISR215-Q316I ARM-based IOT Gateway, NXP i.MX 8M Plus - ARM ISR215-Q316I Cortex-A53 Quad 1.6GHz Description processor, 3GB LPDDR4, 16GB eMMC IBR215-Q316I 2.5” SBC System Motherboard System • Android 13 • Yocto 4.0 Operating System •... -
Page 10: Product View
1.5 Product View I/O View No. Name No. Name OTG Port Boot Setting USB Ports Power On/Off HDMI Port SD card socket and two screw holes for DIN rail mounting GbE LAN Port DC-in Power input Antenna holes (reserved) ISR215 User’s Manual... - Page 11 General Information ISR215 User’s Manual...
-
Page 12: Dimensions
General Information 1.6 Dimensions Unit: mm ISR215 User’s Manual... -
Page 13: Chapter 2 Hardware Configuration
Chapter 2 Hardware Configuration This section contains general information about: • Installations • Connectors... -
Page 14: Installations
1. To install the M.2 card on the board, remove the device cover, locate the slot and align the keys of the card with those of the interface in a way similar to the images below and fix the card onto the brass standoff with a screw. ISR215 User’s Manual... -
Page 15: Wifi / Lte Antenna Installation
Wall Mounting Installation 1. Turn the device upside down. 2. Prepare at least 4 screws (M3) to Attach the wall-mount kit to the install the device on the wall. device using 4 screws. ISR215 User’s Manual... -
Page 16: Setting The Jumpers
Open When two pins of a jumper are encased in a jumper cap, this jumper is closed, i.e. turned On. When a jumper cap is removed from two jumper pins, this jumper is open, i.e. turned Off. ISR215 User’s Manual... -
Page 17: Connector Locations On Motherboard
Hardware Configuration 2.3 Connector Locations on Motherboard Motherboard: IBR215 ISR215 User’s Manual... -
Page 18: Connectors Quick Reference
HDMI Port GbE LAN Port P2, P3 Dual USB 3.0 Type-A Port Mini-USB OTG Port M.2 E-Key (3052) Slot SIM Card Socket System On/Off Button SW2, CN17 Factory Use Only Serial Port P18, P19, IO Board Port ISR215 User’s Manual... -
Page 19: Rtc Lithium Cell Connector (Cn1)
Hardware Configuration 2.4.1 RTC Lithium Cell Connector (CN1) Signal Name Signal Name RTC_VCC Ground ISR215 User’s Manual... -
Page 20: Audio Line-In & Line-Out Connector (Cn2)
Hardware Configuration 2.4.2 Audio Line-In & Line-Out Connector (CN2) Signal Name Signal Name Ground Line_Out_R Line_Out_L Ground Line_In_R Line_In_L ISR215 User’s Manual... -
Page 21: I2C Connector (Cn13)
Hardware Configuration 2.4.3 I2C Connector (CN13) Signal Name Signal Name I2C3_SCL I2C3_SDA Ground I2C4_SCL I2C4_SDA Ground ISR215 User’s Manual... -
Page 22: Lvds Dc Power Input (P17,Cn18)
Hardware Configuration 2.4.4 LVDS DC Power Input (P17,CN18) CN18: DC Input/Output Header Pin Assigment Pin Assigment Ground Ground 12V~24V 12V~24V P17: 12V~24V DC input ISR215 User’s Manual... -
Page 23: System On/Off Button (Sw2, Cn17)
Hardware Configuration 2.4.5 System On/Off Button (SW2, CN17) SW2: On/Off Switch CN17: On/Off Signal Header Pin Assigment Pin Assigment Ground ONOFF_B ISR215 User’s Manual... -
Page 24: Serial Port (P16)
Hardware Configuration 2.4.6 Serial Port (P16) Assigment Assigment DEBUG_RX DEBUG_TX Ground ISR215 User’s Manual... -
Page 25: Io Board Port (P18, P19, P20)
CSI_P2_DP3 SD1_DATA0 SD1_DATA1 SD1_CMD SD1_CLK SD1_DATA2 SD1_DATA3 UART1_TXD UART1_RXD UART_TX3/RTS1 UART_RX3/CTS1 VDCDC3_1V8 VDCDC5_3V3 CLKO1_CSI1_MCLK CLKO2_CSI2_MCLK LCD_BL_PWM/GPIO1_01/PWMO1 GPIO1_00/32K_OUT Ground Ground HUB_DP6 HUB_DM6 HUB_DP1 HUB_DM1 HUB_TXDP1 HUB_TXDM1 HUB_RXDP1 HUB_RXDM1 Ground Ground HUB_DP2 HUB_DM2 HUB_TXDP2 HUB_TXDM2 HUB_RXDP2 HUB_RXDM2 USB_PWR_OUT1 USB_PWR_OUT2 ISR215 User’s Manual... - Page 26 Ground LVDS0_TX3_N LVDS0_TX3_P LVDS0_TX2_N LVDS0_TX2_P LVDS0_CLK_N LVDS0_CLK_P LVDS0_TX1_N LVDS0_TX1_P LVDS0_TX0_N LVDS0_TX0_P CSI_P1_DN3 CSI_P1_DP3 CSI_P1_DN2 CSI_P1_DP2 CSI_P1_CKN CSI_P1_CKP CSI_P1_DN1 CSI_P1_DP1 CSI_P1_DN0 CSI_P1_DP0 LVDS1_TX3_N LVDS1_TX3_P LVDS1_TX2_N LVDS1_TX2_P LVDS1_CLK_N LVDS1_CLK_P LVDS1_TX1_N LVDS1_TX1_P LVDS1_TX0_N LVDS1_TX0_P CSI_P2_DN0 CSI_P2_DP0 CSI_P2_DN1 CSI_P2_DP1 CSI_P2_CKN CSI_P2_CKP ISR215 User’s Manual...
-
Page 27: Chapter 3 Software Setup
Chapter 3 Software Setup This chapter introduces the following setup on the device: (for advanced users only) • Make a recovery SD card • Upgrade firmware through the recovery SD card... -
Page 28: Make A Recovery Sd Card
PC through the mini-USB port (P4 connector), and change the boot mode to download mode. Boot the IBR215 and flash SD via CMD command “uuu.exe uuu- sdcard.auto”. Alternatively, double-click “FW_down-sdcard.bat” (Same way as PCBA update) ISR215 User Manual... -
Page 29: Upgrade Firmware Through The Recovery Sd Card
Driver Installation 3.1.2 Upgrade Firmware through the Recovery SD Card Put recovery files into USB flash disk (FAT32) A> Yocto/Ubuntu: Copy all recovery files into PATH: /USB_flash_disk/hmsupdate/yocto/ B>Android: Copy all recovery files into PATH: /USB_flash_disk/hmsupdate/android/ ISR215 User Manual... - Page 30 Plug (step1)SD and (step2)USB flash disk into IBR215 Normal boot IBR215 (SW1 Pin1 OFF), start recovery eMMC automatically. The update information will show on HDMI. Show “Flashing successfully completed”, then power off and remove recovery SD and USB flash disk. ISR215 User Manual...
-
Page 31: Chapter 4 Bsp Source Guide
Chapter 4 BSP Source Guide This chapter is intended for advanced software engineers to build BSP source. The topics covered in this chapter are as follows: • Preparation • Installing Toolchain • Building release • Installing release to board... -
Page 32: Building Bsp Source
4.1 Building BSP Source 4.1.1 Preparation The recommended minimum Ubuntu version is 18.04 or later. Install necessary packages before building: sudo apt-get install gawk wget git-core diffstat unzip texinfo gcc-multilib \ build-essential chrpath socat cpio python python3 python3-pip python3-pexpect \ xz-utils debianutils iputils-ping python3-git python3-jinja2 libegl1-mesa libsdl1.2-dev \ pylint3 xterm Download toolchain... -
Page 33: Building Release
4.1.2 Building release 4.1.2.1 For yocto/Ubuntu/debian cd /home/bsp-folder ./build-bsp-5.4.sh 4.1.2.2 For android cd /home/bsp-folder source build/envsetup.sh lunch evk_8mp-userdebug make ANDROID_COMPILE_WITH_JACK=false ./imx-make.sh –j4 make –j4 4.1.3 Installing release to board cd /home/bsp-folder for yocto/Ubuntu/debian 1. cp file in release/ to windows 2. - Page 34 This page is intentionally left blank.
-
Page 35: Appendix
Appendix This chapter contains the following information: Onboard Connector Types... - Page 36 A. Onboard Connector Types Compatible Mating Function Connector Onboard Type Type for Reference LVDS Display Hirose Hirose P13, P14 Connector DF13E-10DP-1.25V DF13E-10DP-1.25C TechBest UART Connector WT02M-30002-06132 SHR-03V-S-B LVDS Backlight Control TechBest Molex Connector 1024041008 51021-0400 JCTC Audio Line-In & Line- E-Call 11002H00-1P Out Connector...
