EGR ROLLTRAC ELECTRIC Installation Instructions Manual page 4

T-PATCH
27
RUBBER
EXTRUSION
QTY: 2
Drill
Ratchet & Sockets Allen Key
7mm (9/32")
10mm (25/64'')
13mm (33/64'')
50/50
Isopropyl Alcohol/Water
RT0094
EGR RollTrac FITTING KIT COMPONENTS IN BAGS
EGR RollTrac FITTING KIT ADDITIONAL ITEMS
28
SETTIG BRACE
QTY: 1
TOOLS REQUIRED - NOT SUPPLIED IN KIT
Holesaw
Ø29mm (11/8")
Ø38mm (11/2")
Centre Punch & Hummer
Allen Key
4mm (5/32'')
Ruler x2
MAIN HARNESS
CABLE TIE (500mm)
QTY: 8
METRIC Tape Measure
4mm (5/32'')
Torque Wrench
Silicone
Silicone Spray
1
Number inside a square indicate part number
1
Number inside circle indicate the sequence within a step
1
Number inside the hexagon indicate torque instruction
Page 4 of 36
BLADE FUSES
CABLE TIE (200mm)
QTY: 30
OWNERS
MANUAL
&
INSTALLATION
INSTRUCTIONS
Masking Tape
Fiberglass Tape
Scissors
Black Cloth Tape
3M Primer 94
(preferred) or
equivalent
Side Cutters
T40 Torx Key
GLOSSARY:
Issue 1: 03/07/24
