EGR ROLLTRAC ELECTRIC Installation Instructions Manual page 3

1
CANISTER ASM. QTY: 1
3
LHS RAIL QTY: 1
5
HEADERBAR QTY: 1
6
SCRW0973
SCREW M6x15
QTY: 10
11
NUTS0311
T-NUT
QTY: 14
15
MISC5632-RH
FRONT SEAL
QTY: 1
19
CLIP4240PC-RH
TUB SUPPORT BRACKET
QTY: 1
23
M6x20 HEX HEAD
SCRW0997
QTY: 40
RT0094
KIT CONTENTS - COMPONENT NUMBER AND QUANTITY
EGR RollTrac FITTING KIT IN BOX
7
MISC5620PC-RH
CORNER BRACKET
QTY: 1
12
WASH6094
SPACER
QTY: 2
16
MISC5632-LH
FRONT SEAL
QTY: 1
20
CLIP4240PC-LH
TUB SUPPORT BRACKET
24
TAPE0751
TAPE 3x12x500mm
QTY: 2
2
4
8
MISC5620PC-LH
CORNER BRACKET
QTY: 1
13
CLIP4146PC-RH
TUB SUPPORT BRACKET
QTY: 1
17
KIT040298
REAR DRAINAGE TUBE
QTY: 2
QTY: 1
25
TAPE0784
TAPE 6x12x600mm
QTY: 2
Page 3 of 36
FRONT COVER QTY: 1
RHS RAIL QTY: 1
9 10
MISC5621
MOUNTING BRACKET
SIDE RAIL BRACKET
QTY: 6
14
CLIP4146PC-LH
TUB SUPPORT BRACKET
18
FRONT DRAINAGE TUBE
21 22
CONS70097
DOUBLE SIDED TAPE
CABLE TIE
QTY: 10
26
TAPE0857
EPDM BLOCK
QTY: 2
MISC5421
QTY: 6
QTY: 1
QTY: 2
TAPE0856
QTY: 2
Issue 1: 03/07/24
