PORTABLE MID-RISE LIFT
Model: MR06
△
DANGER
!
Read the entire contents of this manual before using
this product. Failure to follow instructions and safety
precautions could result in serious injury or even
death. Make sure all other operators also read this
manual. Keep this manual near the machine so that it
can be seen by all users. By proceeding with
installation and operation, you agree that you are
fully understand the contents of this manual and take
full responsibility for the use of the product.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AMGO Hydraulics MR06
Summary of Contents for AMGO Hydraulics MR06
- Page 1 PORTABLE MID-RISE LIFT Model: MR06 △ DANGER Read the entire contents of this manual before using this product. Failure to follow instructions and safety precautions could result in serious injury or even Cargo Claims death. Make sure all other operators also read this If there is any missing or damaged manual.
- Page 2 CONTENTS PROFILE ..................1 IMPORTANT SAFETY INSTRUCTIONS ..........3 I. PRODUCT FEATURES AND SPECIFICATIONS ........5 II. INSTALLATION REQUIREMENT ............. 6 III. INSTALLATION STEPS ............... 7 IV. EXPLODED VIEW ..............15 V. OPERATION INSTRUCTIONS ............19 VI. MAINTENANCE SCHEDULE ............20 VII. TROUBLE SHOOTING .............. 21 VIII.
- Page 3 PROFILE This instruction manual is specially prepared for you. Your new lift is the product of over a decade of continuous research, testing and development and is the most technologically advanced lift on the market today. Please make sure to read through this manual before operating the lift. Record the information on the nameplate label here: Model No.:_______________ Serial No.:_______________...
- Page 4 SAFETY WARNING LABEL Fig.1...
- Page 5 IMPORTANT SAFETY INSTRUCTIONS In order to properly maintain your product and ensure operator safety, it is the responsibility of the product owner to read and follow these instructions! 1. Ensure product installation complies with all applicable local regulations and rules, such as Occupational Safety and Health Administration regulations and electrical codes.
- Page 6 14. Danger! The power supply used in this type of lift has high voltage. Please disconnect the power supply before any circuit repair. Unplug in case the power supply is accidentally switched on during maintenance. 15. Warning! There is a risk of explosion. There are parts in the equipment that produce arc light and spark.
- Page 7 I. PRODUCT FEATURES AND SPECIFICATIONS (See Fig.2) PORTABLE MID-RISE MODEL MR06 Mechanical lock with manual lock release, no extra air required. ● Portable design: the lift can easily move to the required sit. ● Two kinds of rubber pads included ●...
- Page 8 II. INSTALLATION REQUIREMENT A. TOOLS REQUIRED Screw Set Hook spanner (40~42mm) English Spanner (12″) Pliers Wrench sets ： ＃ ＃ ＃ ＃ 、15 、17 、19 Fig. 2 B. POWER SUPPLY The power supply capacity must be more than 2.0HP, with a cord larger than 12AWG, and must be properly grounded.
- Page 9 III. INSTALLATION STEPS A. Check the parts before assembly, confirm all the parts are completed. 1. Packaged lift, power unit and power unit stand and telescoping dolly. Move the parts aside, open the outer packing and check the parts according to the shipment parts list (See Fig.
- Page 10 3. Open the carton of power unit stand and check the parts . (See Fig. 5) Fig.5 B. Install power unit stand, lock release handle and telescoping dolly. (See Fig. 6) 1. Assemble power unit stand, safety release handle and U-shaped pipe strap. Fig.
- Page 11 2. Install the power unit. Fig. 7 3. Install the telescoping dolly. Fig. 8...
- Page 12 4. Instruction of telescoping dolly. 4.1 To use the dolly, pull the extension casing to the longest and then rotate it counterclockwise until the rod is tightened with the casing. (See Fig. 9) 1.Pull the lengthened casing 2.Rotate counter clockwise Fig.
- Page 13 C. Install oil hose and lock release cable tube. (See Fig. 11) Connect the oil hoses and lock-release cable tube as shown below. Fig. 11...
- Page 14 D. Install safety device and lock release cable Prepare the safety device parts to install the lock release cable. Pass the lock release cable through the hole in the bolt and then tighten the nut. Fig. 12 Fig. 13 Item Part# Description 11640150...
- Page 15 Adjustment of sliding arm. Raise the lift and lock it at around 30" height, tighten the nylok nut of sliding arms. ( Note: make sure the arms can move from side to side) (See Fig. 14) Tighten the nylok nut Fig.
- Page 16 F. Install electric system Connect the power source according to the data plate of Motor. Note: For the safety of operators, the lift must be well grounded. Single phase motor (See Fig.15) Connecting the two power supply wires to terminals of AC contactor marked L1, L3. The ground wire is connected to the ground wire terminal.
- Page 17 IV. EXPLODED VIEW Model MR06 Fig.
- Page 18 PARTS LIST FOR MODEL MR06 Item Part# Description QTY. 11640001-01 Platform 11640002A Stackable adapter bracket 11209052B Extension adapter (2.5”) 11209051B Extension adapter (1.5”) 10201046A Rubber pad support assy. 10209009 Round head bolt M6*8 10680004 Rubber pad 10640003 Support frame 11640023A...
- Page 19 Item Part# Description QTY. 10209005 Nylok nut M8 10630107 Cotter pin φ3*20 10206006 Flat washer φ12 1003085005 U-shaped pipe strap 1102022004-01 Fixing connecting plate 1003015002-01 Oil hose assy. 1/4” x 120 11/16" 10209060 3/8SA EO/R (M)×1/4JIC(M) fitting 10209033 Flat washer φ8 10209034 Lock washer φ8 10217002...
- Page 20 CYLINDER （10640116） Fig.17 Item Part# Description QTY. 12-1 11640657 Bore weldment 12-2 11640031A Piston rod 12-3 10201034 Bleeding plug 12-4 11203083 Head cap 12-5 10209078 Dust ring 12-6 10201032 O ring 12-7 10203084 O ring 12-8 11203079 Piston 12-9 10206069 O ring 12-10 10203082...
- Page 21 Manual Power unit valve position instruction Protective ring Oil return port Check valve Relief valve Release valve Throttle valve Oil outlet Handle for release valve Fig.18 V. OPERATION INSTRUCTIONS 1. Connect the oil hoses between cylinder and power unit, connect the power wires, then the lift is ready to use.
- Page 22 3. Lower the lift: raise the lift out of safety position ( fig 22), clench the lock release handle (fig. 23), then press the release valve handle to lower the vehicle (fig 24) c. press the release valve b. Clench the lock release a.
- Page 23 VII. TROUBLE SHOOTING TROUBLE CAUSE REMEDY 1. Button does not work 1. Replace button 2. Wiring connections are not in good 2. Repair all wiring connections condition Motor does not 3. Motor burned out 3. Repair or replace motor 4. Safety Switch is damaged 4.
- Page 24 VIII. CAR LIFT SAFETY TIPS Put this safety tips in a place where you can always alert the operator. Please reference to the lift manufacturer’s manual for specific information about the lift. 1. Check the lift daily. If the machine breaks down or has damaged parts, do not operate, and use original equipment parts to repair.
- Page 25 72215507 2024/07...
