General Information
Multiboard Light+ interactive panel is designed for working with Android-based applications, creating and processing data. It can be mounted on a
wall or floor stand using a VESA mount. Provides wired and wireless connection to the Internet, wired and wireless connection of external devices,
installation of internal mini computer. Operation is via touch screen and/or remote control (RC) unit.
Technical specifications
Model
Specifications
Power supply (input) 50/60 Hz, 300.0 W (max.)
Screen diagonal
Screen resolution
Screen technology
Viewing angle
Brightness; contrast
Frequency; response time
Connectors
System characteristics
Network specifications
Speakers
Video camera
Microphones
Material; color
Size of compatible
VESA mount
Size (L×W×H) (mm)
Net weight (kg)
Operating conditions
Storage conditions
Scope of supply
Warranty
Service life
Limitations and warnings
ATTENTION! The warnings, precautions and instructions contained in this document do not include all possible hazardous situations. Use common
sense when operating the device.
1. Use caution when moving and installing the interactive panel. Installation must be carried out by qualified installers (at least 2 persons).
2. Use the device indoors only. Do not expose the device to high temperatures (from an electric heater, direct sunlight). Do not allow liquids or dust
into the device.
3. Do not block the ventilation holes of the device.
4. This device is not intended for use by children under 14 years old or by persons of reduced physical, mental or intellectual capacity without sufficient
experience or knowledge of its operation.
5. Do not disassemble the device or attempt to repair it yourself.
6. Only connect cables to the interactive panel when it is turned off.
7. Do not crimp or pinch the cables connected to the interactive panel. Do not allow cables to come into contact with hot surfaces or sharp objects.
Do not use uncertified or damaged cables.
8. Use the interactive panel connectors only for their intended purpose. Do not insert foreign objects into the connectors, do not use force when
connecting cables or flash drives to the connectors.
9. Regularly update the installed software and firmware of the device to the latest versions.
10. Before installing the software, make sure that its system requirements match the parameters of the interactive panel. If you have any questions
about the operation of the software, please contact the support service of its developer.
11. Touch the touchscreen only with clean, dry hands or the stylus provided. Avoid hitting the screen or touching it with sharp objects.
12. Turn off and unplug the device before cleaning. Clean the surface with a slightly damp cloth using light strokes, without pressure. Do not use
harsh detergents or abrasives or metal sponges.
13. Unplug the device from the power supply during lightning storms.
14. Before turning off the interactive panel or putting it in standby mode, make sure that the mini computer (if available) installed in the panel is
turned off.
15. If the interactive panel is not used for an extended period of time, unplug it from the power supply.
16. Do not leave a still image on the screen for more than an hour – this causes pixel burnout.
If you have any problems or questions while using the device, contact the technical support before returning it to the seller. To do so, fill out the form
at the bottom of the home page at prestigio-solutions.com.
8
PSMB068P650
AC 100–240 V, 1.4 A,
50/60 Hz, 380.0 W (max.)
65" (display space 64.5") 75" (display space 74.5")
LCD, touch (infrared), up to 40 simultaneous action points, Direct LED backlight
350 cd/m²; 1,200:1
AUDIO IN (×1); AUDIO OUT (×1); DP IN (×1); HDMI IN (×2); HDMI OUT (×1); JAE (80 pin) (×1); LAN (RJ45) (×2);
MIC IN (×1); RS232 IN (×1); S/PDIF (×1); USB Type A 2.0 (×1); USB Type A 3.0 (×4); USB Type B 3.0 (×3);
CPU: ARM Cortex A73 2.2 GHz (×4) + ARM Cortex A53 2.0 GHz (×4). GPU: Mali-G52 MP8 (800 MHz). RAM: 8 GB.
LAN: 10/100/1,000 Mbps. Wi-Fi 802.11 (a/b/g/n/ac) 2.4 / 5.0 GHz, ≤ 18.79 dBm (75.68 mW).
BT 4.2 / 5.1, ≤ 3.96 dBm (2.49 mW); NFC ≤ 30 cm (NFC-A, NFC-B)
2.1 (16.0 W, high-frequency (×2); 16.0 W, low-frequency (×1))
Sensor: 1/2.8", CMOS, 8 MP, Ultra HD (4K, ≤ 30 fps). Video compression: MJPEG. Viewing angle: 103° (diagonal) /
64° (vertical) / 94° (horizontal). Focusing distance: ≥ 80 cm
600×400 (M8)
1,482.1×105.6×936.7 1,716.5×105.6×1,069.7
38.5
Temperature 0...+40 °C; relative humidity 10–80 % (non-condensing)
Temperature −40...+60 °C; relative humidity 10–80 % (non-condensing)
Multiboard Light+ interactive panel, RC unit, 2 power cables (E/F and G plugs) (3 m),
USB Type A/B cable (3 m), HDMI cable (3 m), styluses (6 pcs.), multifunctional pen, Quick Start Guide
2 years + 1 year free service, unless otherwise specified by local law (see prestigio-solutions.com/warranty)
PSMB068P750
AC 100–240 V, 1.7 A, AC 100–240 V, 2.1 A,
50/60 Hz, 460.0 W (max.)
≤ 0.5 W in standby mode
86" (display space 85.6")
3,840×2,160 (Ultra HD) (16:9)
178° (vertical) / 178° (horizontal)
400 cd/m²; 1,200:1 400 cd/m²; 1,200:1
60 Hz; ≤ 8 ms
USB Type C (×2); VGA IN (×1); SD card slot
ROM: 64 GB. OS Android 11 (pre-installed)
8 pcs; sound capture radius ≤ 8 m
Aluminum, tempered glass; black
800×400 (M8)
1,961.8×105.6×1,207.7
53.5
3 years
Multiboard Light+
PSMB068P860 PSMB068P980
AC 100–240 V, 2.2 A,
50/60 Hz, 480.0 W (max.)
98" (display space 97.5")
450 cd/m²; 1,200:1
800×600 (M8) 800×600 (M8)
2,230.8×121.7×1,356.4
66.7
