Summary of Contents for Prestigio MULTIBOARD PRIME PMB528L653
- Page 3 1. Safety information ......................1 2. Preparing for operation ………………………………………………………………………………………….…….. 3 3. The stand kit ……………………………………………………………….………………………………………………… 4 4. Control Panel ....................... 5 Prepare to install ………………………….……………………….…………………………………………....5 Terminal Interface ……......................5 PC Interface ……......................7 Remote Control ........................8 5. Connection and Setting ....................11 6.
-
Page 4: Safety Warning
User manual Prestigio Solutions MultiBoard Safety Warning • Before operating, please read this manual thoroughly, and keep it for future reference. • Image shown in this manual is indicative only. There may be differences between the pictures and the actual product, please prevail in kind. - Page 5 User manual Prestigio Solutions MultiBoard Temperature • Normal operating temperature is 0 ~ 40℃. • Do not place the unit near or over a radiator or a heater. • If your unit is suddenly moved from a cold to a warm place, please unplug the power cable and do not turn it on at least 2 hours, making sure the moisture inside the unit is all evaporated.
- Page 6 User manual Prestigio Solutions MultiBoard You can fix the device to the wall using the wall mounting kit. • This MultiBoard multimedia panel can only be attached to the wall using the wall mounting kit recommended by Prestigio Solutions . Use of other wall mounting equipment may lead to unstable installation and risk causing serious injury.
- Page 7 User manual Prestigio Solutions MultiBoard • Prestigio Solutions MultiBoard • Remote control* multimedia panel • 4 writing pens* • 1 interactive pen* • 2 pens for • Power cord simultaneous writing • USB-driver disc • USB cable • HDMI cable •...
- Page 8 User manual Prestigio Solutions MultiBoard Number Items Function description Magnetic zone Area for placing the absorptive magnetic pen Tap to enter energy-saving, press at least 2 seconds to enter standby mode Remote control Receive the remote signal. signal receiver USB 3.0...
- Page 9 User manual Prestigio Solutions MultiBoard TYPE-C Number Items Function description External computer image input AUDIO IN External computer audio input SPDIF Carry multichannel sound via optical signals. RS232 Serial interface, used for mutual transfer of data between devices AUDIO OUT...
- Page 10 User manual Prestigio Solutions MultiBoard L A N A u d i o O U T A u d i o I N TYPE-C Number Items Function description Audio Out Audio output to the external speaker Audio In External computer audio input...
- Page 11 User manual Prestigio Solutions MultiBoard Remote control button instruction EN - 7 EN - 8...
-
Page 12: Detailed Function Description
User manual Prestigio Solutions MultiBoard Detailed Function Description Number Items Function description Power on/off Enter or exit mute mode. Start PC's Windows key Space PC's Space key Alt+Tab PC's Alt+Tab key Alt+F4 PC's Alt+F4 key Numeric keys Numeric input keys... -
Page 13: Remote Control Instruction
User manual Prestigio Solutions MultiBoard Remote Control Instruction Install Batteries 1) Open back cover of battery component on the back of remote control. 2) Install AAA type battery according to the corresponding electrode, make sure battery positive and negative pole are correct ("+"to"+", "-" to "-"), please do not mix using old and new batteries. - Page 14 User manual Prestigio Solutions MultiBoard For the safety of you and the machine please do not connect any power plug before peripheral wires connections. 1. External Computer and Touch Connection 1) Use VGA cable to connect to VGA output port of external computer, and meanwhile use headphone audio cable to connect to external computer audio output interface.
- Page 15 User manual Prestigio Solutions MultiBoard 2. Audio and Video Equipment 1) Use HDMI cable to connect audio and video equipment with HDMI output. 2) After cable connection, plug in power cord, and switch power on. 3) Press to turn equipment on.
-
Page 16: Usb Connection
User manual Prestigio Solutions MultiBoard 6. USB Connection EN - 13... -
Page 17: Touch Menu Operation
User manual Prestigio Solutions MultiBoard Touch Menu Operation Call up Method Take middle point position on the bottom of display screen as starting point, Use touch pen to drag towards screen center position to call up touch menu, as shown below. - Page 18 User manual Prestigio Solutions MultiBoard Setting Menu General Setting • Press INPUT button on remote control or via touch A method to call up General Setting menu. • Press button on remote control to select the channel you need. • Press the Enter button on remote control or directly click with touch pen to confirmselected input channel.
- Page 19 User manual Prestigio Solutions MultiBoard Detail Setting Menu Press Menu on remote control or click the icon on General Setting menu with touch pen to call up detail setting menu. Detail setting menu includes Audio, Screen, Display and Adjust. Audio •...
- Page 20 User manual Prestigio Solutions MultiBoard Screen • Press button on remote control to select Screen setting menu. • Press on remote control or directly click with touch pen to select the option. • Press Enter on remote control or directly click with touch pen to enter the selected mode.
- Page 21 User manual Prestigio Solutions MultiBoard Display • Press button on remote control to select Display setting menu. • Press button on remote control or directly click with touch pen to select the option. • Press Enter on remote control to enter adjustment mode, and press button or directly click with touch pen to adjust each option.
- Page 22 User manual Prestigio Solutions MultiBoard Adjust • Press button on remote control to select Adjust setting menu. • Press button on remote control or directly click with touch pen to select the option. • Press Enter on remote control to enter adjustment mode, and press button or directly click with touch pen to adjust each option.
-
Page 23: Touch Function
User manual Prestigio Solutions MultiBoard Machine Fails to Work Normally Remote control failure Check whether there are other objects between remote control and equipment control receiving window, thus leading to failure of remote control. Check whether the battery electrode in the remote control is correct. - Page 24 User manual Prestigio Solutions MultiBoard Video Function Can’t Work Normally No picture and no Check whether the machine is started state. sound Check whether signal wire is well plugged, whether INPUT is corresponding to it. If in internal computer mode, check whether internal computer is started.
- Page 25 User manual Prestigio Solutions MultiBoard Proper maintenance can avoid many early faults and regular careful cleaning can make machine brand new. Please unplug power plug before cleaning and maintenance, to prevent electric shock. Clean Screen Please mix and stir even a little fabric softener or tableware detergent with alcohol.
- Page 26 User manual Prestigio Solutions MultiBoard ARTICLE PMB528L653 PMB728L753 PMB728L863 PMB751G983 Screen size, inch 65" (UHD) 75" (UHD) 86" (UHD) 98" (UHD) Screen resolution 3840х2160 3840х2160 3840х2160 3840х2160 Response time Viewing angle 178/178 178/178 178/178 178/178 LED/ IR 20 point touch, 10 point...
- Page 27 The Prestigio trademark and logo are the property of Prestigio Plaza Limited. "Prestigio" is a registered trademark belonging to the Prestigio company. Applicable law: this document is drawn up in accordance with the law of Cyprus.
- Page 28 User manual Prestigio Solutions MultiBoard EN - 25...
