Multiboard Light+
EN
I – Appearance (see pages 4–5)
A – front panel
1 Microphones
2 Video camera
3 Screen
4 USB Type A 3.0 connectors
5 USB Type C connector
6 Magnetic surface for accessories
7 Speakers
8 NFC sensor
9 IR receiver, light sensor
10 Handles
11 Slot for mini computer (
12 Power connector
13 Power button
14 Video camera and microphones on/off button
15 USB Type B 3.0 connectors
NOTE. The I-9 elements are combined into one unit and concealed by non-removable protective cover.
II – Remote control unit (see page 5)
A – appearance
1 Power button
2 Source selection button
3 Menu navigation buttons
4 Confirmation button
5 Button to enter / exit System Settings menu
6 Button to open the home page of the menu
NOTE. The remote control requires 2 AAA batteries (not included in the package).
III – Wall mounting example (see page 6)
ATTENTION! A VESA standard wall mount is required. Installation involves drilling into the wall. Installation tools (drill,
hammer, screwdriver, wrench, construction level) are required. They are not included in the package.
1 Installing vertical guides on the interactive panel
2 Installing the interactive panel: aligning the guides and the mounting frame
3 Additional fixation
NOTE. See also the instructions for the wall mount used.
NOTE. The wall mount is not included in the package.
IV – Example of installation on a floor stand (see page 6 *)
ATTENTION! If you are using a stand on wheels, you must lock the wheels before installing the interactive panel on it.
NOTE. See also the instructions for the floor stand used.
NOTE. The floor stand is not included in the package.
* Stand type may vary.
© 2024 Prestigio Solutions
B – side panels
JAE connector)
B – recommendations for use
C – bottom panel
16 DP IN connector
17 HDMI IN connectors
18 USB Type C connector
19 USB Type A 3.0 connectors
20 USB Type A 2.0 connector
21 SD card slot
22 S/PDIF connector
23 AUDIO OUT connector
24 HDMI OUT connector
25 MIC IN connector
26 RS232 IN connector
27 LAN (RJ45) connectors
28 VGA IN connector
29 AUDIO IN connector
30 Power toggle switch
7 Button to return to the previous page of the menu
8 Button to switch to mini computer
9 Button to call the writing and drawing function
10 Screenshot button
11 Volume control buttons
12 Mute/unmute button
