Summary of Contents for Austin Hughes LCD-AP12
- Page 1 dedicated LCD display solutions User Manual 12.1” LCD AP12 Aluminum front bezel NAP12 Front NEMA4 / IP65 OP12 Universal Mounting Open Frame UM-UV-621-12-Q313V3 www. es.com...
- Page 2 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
- Page 3 Contents < Part. 1 > AP12 / NAP12 Package Content Structure Diagram & Dimension P.2 - 3 Mounting Hardware & Installation P.4 - 5 < Part. 2 > OP12 Package Content Structure Diagram & Dimension P.7 - 8 Mounting Hardware & Installation <...
- Page 4 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
- Page 5 < Part 1 > < 1.1 > Package Content - / NAP12 12.1" LCD Display LCD-AP12 / NAP12 12.1" LCD display X 1 6ft VGA cable X 1 Power adapter X 1 Power cord X 1 Mounting hardware X 1 pack...
- Page 6 < 1.2 > Structure Diagram - LCD-AP12 / NAP12 Front view AP-12 NAP-12 Rear view Rear case LCD panel Protective 3mm glass 6mm aluminum front bazel Audio speaker ( for Audio or TV option ) LCD membrane Remote sensor Product Dimension...
- Page 7 < 1.2 > Dimension - LCD-AP12 / NAP12 12.1” LCD Display Front View Side View AP-12 NAP-12 Rear View UNIT : mm 1mm = 0.03937 inch Bottom View UM-UV-621-12-Q313V3 www.rackmountsales.com...
- Page 8 < 1.3 > Panel Mount Installation - LCD-AP12 / NAP12 M4*50mm screw M4*6mm screw Mounting bracket x 4 pcs x 4 pcs x 2 pcs Hardware set part no. UV-BK#1 Steps ■ Install 2 mounting brackets with 4 x M4*6mm screws ■...
- Page 9 < 1.3 > VESA mount Installation - AP / NAP-12 12.1” LCD Display M4 screw VESA mount ( 75*75mm ) ■ Hardware and M4*4 pcs for VESA mount are not provided UM-UV-621-12-Q313V3 www.austin-hughes.com...
- Page 10 < Part 2 > < 2.1 > Package Content - OP-12 OP-12 12.1" LCD display X 1 6ft VGA cable X 1 Power adapter X 1 Power cord X 1 Basic I/O Power AV2.2 upgrade I/O Audio Power S-Video DVI-D out - in - in Video PC UM-UV-621-12-Q313V3...
- Page 11 < 2.2 > Structure Diagram - OP-12 12.1" LCD Display Front view OP-12 Rear view Rear case LCD panel Audio speaker ( for Audio or TV option ) Universal open frame mounting LCD membrane Extended remote sensor membrane cable ( 66cm from AD board to sensor end ) Product Dimension Packing Dimension Gross...
- Page 12 < 2.2 > Dimension - OP-12 Front View Side View OP-12 Rear View UNIT : mm 1mm = 0.03937 inch Bottom View UM-UV-621-12-Q313V3 www.austin-hughes.com...
- Page 13 < 2.3 > Installation - OP-12 12.1” LCD Display ( I ) Universal mount ( II ) VESA mount ( 75*75mm ) M4 screw Hardware and M4*4 pcs for VESA mount are not provided UM-UV-621-12-Q313V3 www.austin-hughes.com...
- Page 14 < Part 3 > < 3.1 > Product Specifi cations AP / NAP-12 OP-12 Mechanical Design Front Panel Black, RAL 9005 Rear Casing Dark grey, RAL 7037 Dark grey, RAL 7037 VESA Mounting 100 x 100mm 100 x 100mm Other Mounting Panel mount Universal mount Protection...
- Page 15 12.1” LCD Display AP / NAP-12 OP-12 Physical Specifi cation Product ( W x D x H ) 344.7 x 68.2 x 256 mm 341.7 x 62.2 x 253 mm 13.6 x 2.7 x 10.1 inch 13.5 x 2.5 x 10 inch Packing ( W x D x H ) 515 x 117 x 429 mm 515 x 117 x 429 mm...
- Page 16 < 3.2 > On-screen Display Operation ( OSD ) Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen Toggle analog, digital &...
- Page 17 < Part 4 > Options 12.1” LCD Display < 4.1 > Option Table Options AP / NAP S-Video + Composite ( BNC ) DVI-D Audio Touchscreen DC Power TV * For TV option , this comes with RC-2 remote controller. P.13 UM-UV-621-12-Q313V3 www.austin-hughes.com...
- Page 18 < 4.2 > AV2.2 Upgrade Options : - DVI-D ( DVI-D TMDS single link ) - AV ( S-Video + Composite, BNC ) - Audio ( 3.5mm audio jacks for audio in & out, and 2W + 2W speakers ) Audio Power S-Video...
- Page 19 < 4.3 > Options : Touchscreen & driver 12.1” LCD Display 12.1" USB Touchscreen Specifi cation Model e-Resistive e-Capacitive Technology 5-Wire Resistive Capacitive Method Stylus or Finger Finger Activation Force ≤ 50g / Stylus=R0.8 ≤ 50g Durability 35,000,000 times 300 million touches Response Time 15 ms 20 ms...
- Page 20 < 4.4 > Options : DC Power Model Input rating Input voltage: 12-Volt 24-Volt 48-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V Input current - No load 50 mA 50 mA 50 mA - Full load 4950 mA 2450 mA 1220 mA...
- Page 21 < 4.5 > Options : TV ( Analog ) 12.1” LCD Display Audio Power S-Video DVI-D out - in - in Video PC For TV option : ( 1 ) The AD board comes standard with DVI-D, VGA, S-Video, BNC, audio inputs and RC-2 remote controller.
- Page 22 How to Use RC-2 Remote Controller INPUT MUTE -/-- FREEZE AUTO MENU SELECT ASPECT SLEEP ENTER BACK EXIT SWAP SOURCE POSITION AUDIO INPUT Select the source Switches on or off the TV Only use in TV mode. Select channels. For channel numbers 10 0 - 9 and above, enter the second digit within two seconds.
- Page 24 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2013 Austin Hughes Electronics Ltd. All rights reserved. UM-UV-621-12-Q313V3 www.austin-hughes.com...
