IBASE Technology ASB200-838 User Manual

Fanless system with 3.5” disk-size sbc
Hide thumbs Also See for ASB200-838:
Table of Contents

Advertisement

Quick Links

Download this manual
ASB200-838
Fanless System with
3.5" Disk-Size SBC
User's Manual
Version 1.0
(May 2024)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASB200-838 and is the answer not in the manual?

Questions and answers

Related Manuals for IBASE Technology ASB200-838

Summary of Contents for IBASE Technology ASB200-838

  • Page 1 ASB200-838 Fanless System with 3.5” Disk-Size SBC User’s Manual Version 1.0 (May 2024)
  • Page 2 Copyright © 2024 IBASE Technology, Inc. All rights reserved. No part of this publication may be reproduced, copied, stored in a retrieval system, translated into any language or transmitted in any form or by any means, electronic, mechanical, photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc.
  • Page 3 0.1% by weight (1000 ppm) except for cadmium, limited to 0.01% by weight (100 ppm). • Lead (Pb) • Mercury (Hg) • Cadmium (Cd) • Hexavalent chromium (Cr6+) • Polybrominated biphenyls (PBB) • Polybrominated diphenyl ether (PBDE) ASB200-838 User Manual...

  • Page 4: Important Safety Information

    Do not disassemble, repair, or modify the device in any way. Doing so could create hazards, cause damage to the device, and may result in bodily injury or property damage. Additionally, such actions will void any warranty. ASB200-838 User Manual...

  • Page 5: Warranty Policy

    3. If repair service is required, visit the IBASE’s eRMA page to apply for RMA authorization. You will then print out the RMA form containing the assigned RMA number and include it with the items to be returned. ASB200-838 User Manual...

  • Page 6: Table Of Contents

    USB 3.2 Connector (CN6) ............28 2.5.6 Type-C Connector (CN7) ............29 2.5.7 USB 3.2 Stack Connector (CN8)..........29 2.5.8 COM1 RS-232/422/485 Serial Port (CN9) ....... 30 2.5.9 Nano SIM Card Slot (J1) ............31 2.5.10 DDR5 SO-DIMM Connector (J2)..........31 ASB200-838 User Manual...
  • Page 7 Security Settings ..................70 Boot Settings..................71 Save & Exit Settings................72 Appendix ....................... 74 I/O Port Address Map ................75 Interrupt Request Lines (IRQ) ..............77 Watchdog Timer Configuration ............... 78 Onboard Connector Reference Types ............ 82 ASB200-838 User Manual...

  • Page 9: Chapter 1 General Information

    Chapter 1 General Information The information provided in this chapter includes: Features • Packing List • Optional Accessories • Specifications • Product View • Dimensions •...

  • Page 10: Introduction

    1.1 Introduction The ASB200-838 is a compact and fanless embedded system powered by the IBASE IB838 3.5’’ Single Board Computer, featuring an onboard Intel® N-series Processor. Its robust design, coupled with a wide-range power input of 9V to 36V DC, ensures reliability in various environments. This system supports up to 16GB of DDR5 SO-DIMM memory and features 2x M.2 sockets...

  • Page 11: Packing List

    • 3-pin Terminal Block (for power) • 10-pin Terminal Block (for GPIO connector) • Side Brackets • Screws for Side Brackets • Power Adaptor and Power Cord • 1.4 Optional Accessories WiFi / Bluetooth Module Kit • ASB200-838 User Manual...

  • Page 12: Specifications

    Desktop or wall mount (wall mount kit included) • Mounting Type Optional VESA mount kit • 180mm (W) x 150mm (D) x 72mm (H) Dimensions 7.08” (W) x 5.9” (D) x 2.83” (H) Certificate CE / LVD / FCC Class B ASB200-838 User Manual...
  • Page 13 Operating: 0.25 Grms / 5 ~ 500 Hz • Vibration Protection Non-operating: 1 Grms / 5 ~ 500Hz • Operating: 20 g / 11 ms • Shock Protection Non-operating: 40 g / 11 ms • All specifications are subject to change without prior notice. ASB200-838 User Manual...

  • Page 14: Product View

    1.6 Product View Front View Name Name Antenna Holes Power Switch Digital I/O (4-In / 4-Out) DC in +12V~ +36V HDD LED ASB200-838 User Manual...
  • Page 15 General Information Rear View Name Name COM1 RS-232/422/485 Display Port LAN Port COM Port Holes USB Type-C Antenna Holes USB 3.x Ports COM Port ASB200-838 User Manual...
  • Page 16 Oblique View ASB200-838 User Manual...

  • Page 17: Dimensions

    General Information 1.7 Dimensions Unit: mm ASB200-838 User Manual...

  • Page 18: Chapter 2 Hardware Configuration

    Chapter 2 Hardware Configuration The information provided in this chapter includes: Installations • Descriptions and locations of connectors •...

  • Page 19: Installations

    If you need to install or replace an SSD or a HDD, first unscrew the single screw (as indicated below) to remove and lift the hard drive cover. Then, proceed to remove the other screws securing the SSD/HDD drive. ASB200-838 User Manual...

  • Page 20: Card Installation

    2.1.2 M.2 Card Installation 1. Remove the bottom chassis cover by loosening the 9 screws and the COM port standoff as indicated below. 2. Locate the M.2 card slots to install the M.2 cards. ASB200-838 User Manual...

  • Page 21: Memory Installation

    3. Gently push the module down in an upright position until the clips of the slot close to hold the module in place when the module touches the bottom of the slot. To remove the module, press the clips outwards with both hands, and the module will pop-up. ASB200-838 User Manual...

  • Page 22: Wifi / 3G / 4G Antenna Installation

    Thread the WiFi / 3G / 4G antenna cable through an antenna hole. Then fasten the antenna as shown below. Info: The diameter of the nut is around 6.35 mm (0.25”-36UNC). 2.1.5 Side Bracket Installation Use the screws provided in the accessory kit to attach the side bracket to the case. ASB200-838 User Manual...

  • Page 23: Pinout For Com Ports, Dc Power & Digital I/O Connectors

    DCD, Data carrier detect DSR, Data set ready RXD, Receive data RTS, Request to send TXD, Transmit data CTS, Clear to send DTR, Data terminal ready RI, Ring indicator Ground Assignment RS-232 RS-422 RS-485 DATA- DATA+ Ground Ground Ground ASB200-838 User Manual...
  • Page 24 DC Power Input Connector (terminal block) • Assignment Pin Assignment Ground +12V ~ +24V Chassis Ground Digital I/O Connector (terminal block) • Pin Assignment Pin Assignment Ground ASB200-838 User Manual...

  • Page 25: Setting The Jumpers

    1 2 3 When two pins of a jumper are encased in a jumper cap, this jumper is closed, i.e. turned On. When a jumper cap is removed from two jumper pins, this jumper is open, i.e. turned Off. ASB200-838 User Manual...

  • Page 26: Jumper & Connector Locations On The Motherboard

    2.3 Jumper & Connector Locations on the Motherboard Motherboard: IB838 ASB200-838 User Manual...

  • Page 27: Jumpers Quick Reference

    M.2 B-key / Sierra Module Selection Sierra Module Interface Selection Clear CMOS Data Clear ME Register 2.4.1 eDP Panel Power Selection (JP1) Function Pin closed Setting 3.3V (default) Note: This is for setting Pin1~Pin5 voltage of CN2. ASB200-838 User Manual...

  • Page 28: Lvds Panel Brightness Selection (Jp2)

    Function Pin closed Setting 3.3V (default) Note: This is for setting Pin3 voltage of J21. 2.4.3 LVDS Panel Power Selection (JP3) Function Pin closed Setting 3.3V (default) Note: This is for setting Pin19~Pin20 voltage of J10, J15. ASB200-838 User Manual...

  • Page 29: At / Atx Selection (Jp4)

    AT / ATX Selection (JP4) Function Pin closed Setting Note: AT: Auto power on; ATX: Manual power on 2.4.5 M.2 B-key / Sierra Module Selection (JP5) Function Pin closed Setting M.2 B-key (default) Sierra Module Note: The setting is via J3. ASB200-838 User Manual...

  • Page 30: Sierra Module Interface Selection (Jp6)

    2.4.6 Sierra Module Interface Selection (JP6) Function Pin closed Setting PCIE (default) Note: The setting is via J3. 2.4.7 Clear CMOS Data (SW1) Function Setting Normal (default) P1-OFF Clear CMOS P1-ON ASB200-838 User Manual...

  • Page 31: Clear Me Register (Sw1)

    Hardware Configuration 2.4.8 Clear ME Register (SW1) Function Setting Normal (default) P2-OFF Clear ME Register P2-ON ASB200-838 User Manual...

  • Page 32: Connectors Quick Reference

    LVDS Connectors J10, J15 SMBUS Connector Power JTAG Connector M.2 E-Key 2230 Connector COM2, COM3, COM4 RS-232 Ports J18, J16, J14 RTC Battery Connector LVDS Backlight Connector 80 Port Debug Tool Connector Digital I/O Connector Front Panel Connector ASB200-838 User Manual...

  • Page 33: Sata Connectors (Cn1)

    Pin Assignment Pin Assignment Ground Ground Ground 2.5.2 eDP Connector (CN2) Remarks: KEL_SSL00-40S Note: Use JP1 to set Pin1~ Pin5 voltage; Total current: 1A Pin27, Pin36 Total current: 1A Pin28, Pin35 Total current: 1A Pin31 Total current: 0.5A ASB200-838 User Manual...
  • Page 34 AUXP eDP Vcc AUXN Ground Ground +3.3V Ground EDP BKLT (+12V) Ground Hot Plug detect Ground Ground TXN3 TXP3 Back Light Control Ground Back Light Enable TXN2 EDP BKLT (+12V) TXP2 +3.3V Ground Ground TXN1 TXP1 Ground ASB200-838 User Manual...

  • Page 35: Dp Connectors (Cn3)

    Hardware Configuration 2.5.3 DP Connectors (CN3) Pin Assignment Pin Assignment LAN0_P LAN3_N LAN0_N CONFIG LAN1_P AUXP LAN1_N LAN2_P AUXN Hot Plug LAN2_N LAN3_P +3.3V/0.5A ASB200-838 User Manual...

  • Page 36: Lan Connectors (Cn4, Cn5)

    2.5.4 LAN Connectors (CN4, CN5) 2.5.5 USB 3.2 Connector (CN6) ASB200-838 User Manual...

  • Page 37: Type-C Connector (Cn7)

    Hardware Configuration 2.5.6 Type-C Connector (CN7) Note: DP, USB 3.2, DC Output: +5V/3A 2.5.7 USB 3.2 Stack Connector (CN8) ASB200-838 User Manual...

  • Page 38: Com1 Rs-232/422/485 Serial Port (Cn9)

    DCD, Data carrier detect Ground DTR, Data terminal ready Ground CTS, Clear to send TX, Transmit RTS, Request to send RX, Receive RI, Ring Indicator Assignment RS-232 RS-422 RS-485 (default) Ground Ground Ground Ground Ground Ground Data+ Data- ASB200-838 User Manual...

  • Page 39: Nano Sim Card Slot (J1)

    Hardware Configuration 2.5.9 Nano SIM Card Slot (J1) 2.5.10 DDR5 SO-DIMM Connector (J2) ASB200-838 User Manual...

  • Page 40: B-Key 3052 Connector (J3)

    2.5.11 M.2 B-Key 3052 Connector (J3) *With sierra LTE card, USB/PCIE I/F is configurable by JP5, JP6. 2.5.12 DC Power Input Connector (J4) Assignment +9V ~ +36V Ground ASB200-838 User Manual...

  • Page 41: Usb 2.0 Connector (J5)

    Hardware Configuration 2.5.13 USB 2.0 Connector (J5) Remarks: HK_DF11-8S-PA66H Pin Assignment Pin Assignment +5V/0.5A Ground Data- Data+ Data+ Data- Ground +5V/0.5A 2.5.14 SPI Flash Tool Connector (J6) Remarks: Factory use only. ASB200-838 User Manual...

  • Page 42: Audio Connector (J7)

    Audio Connector (J7) Remarks: HK_DF11-12S-PA66H Pin Assignment Pin Assignment Lineout_L Lineout_R JD_FRONT Ground LINEIN_L Linein_R JD_LINEIN Ground MIC_L MIC-R JD_MIC1 Ground 2.5.16 SATA HDD Power Connector (J8) Remarks: E-CALL 0110-071-040 Pin Assignment Pin Assignment +5V/1A Ground Ground +12V/1A ASB200-838 User Manual...

  • Page 43: Speaker Out Connector (J9)

    Hardware Configuration 2.5.17 Speaker Out Connector (J9) Remarks: E-CALL_0110-161-040 Pin Assignment Pin Assignment SPK_L+ SPK_R- SPK_L- SPK_R+ Remarks: 2.1 W/Ch Into 4 Ω at 5 V 1.4 W/Ch Into 8 Ω at 5 V ASB200-838 User Manual...

  • Page 44: Lvds Connectors (J10, J15)

    ** J10: Channel-A, J15: Channel-B Remarks: HIROSE_DF20G-20DP-1V(56) Note: Use JP3 to set Pin19~Pin20 voltage.Total current: 1A Pin Assignment Pin Assignment TX0P TX0N Ground Ground TX1P TX1N Ground Ground TX2P TX2N Ground Ground CLKP CLKN Ground Ground TX3P TX3N Power Power ASB200-838 User Manual...

  • Page 45: Smbus Connector (J11)

    Hardware Configuration 2.5.19 SMBUS Connector (J11) Pin Assignment Pin Assignment PLT_RST# SMB_DATA GPIO SMB_CLK- Ground 2.5.20 M.2 E-Key 2230 Connector (J13) *Supports CNVI Card ASB200-838 User Manual...

  • Page 46: Com2, Com3, Com4 Rs-232 Ports (J18, J16, J14)

    TXD, Transmit data DTR, Data terminal ready Ground DSR, Data set ready RTS, Request to send CTS, Clear to send RI, Ring indicator Not Used 2.5.22 RTC Battery Connector (J20) Note: Coin battery with cable. Pin Assignment Ground ASB200-838 User Manual...

  • Page 47: Lvds Backlight Connector (J21)

    Hardware Configuration 2.5.23 LVDS Backlight Connector (J21) Remarks: E-CALL_0110-161-040 Note: Use JP2 to set Pin3 voltage. Assignment Assignment +12V/1.5A Brightness Control Backlight Enable Ground 2.5.24 80 Port Debug Tool Connector (J22) Remarks: Factory use only. ASB200-838 User Manual...

  • Page 48: Digital I/O Connector (J23)

    Digital I/O Connector (J23) Remarks: E-CALL_0196-01-200-100 Pin Assignment Pin Assignment Ground +5V/0.5A OUT3 OUT1 OUT2 OUT0 2.5.26 Front Panel Setting Connector (J24) Remarks: E-CALL_0126-01-203-080 Assignment Pin Assignment PWR_BTN- PWR_BTN+ HDD_LED+, 3.3V HDD Active Ground Reset Power_LED+, 5V Ground ASB200-838 User Manual...

  • Page 49: Chapter 3 Driver Installation

    Chapter 3 Driver Installation This chapter introduces installation of the following drivers: Intel ® Chipset Software Installation Utility • Intel® Graphics Drivers • Realtek HD Audio Driver • Intel ® LAN Drivers • Intel ® ME Drivers • Intel ® Serial IO Drivers •...

  • Page 50: Introduction

    INF files for Plug & Play function for Intel chipset components. Follow the instructions below to complete the installation. 1. Run the drivers disk. Click Intel on the left pane and then Intel(R) AlderLake-N Chipset Drivers on the right pane. ASB200-838 User Manual...
  • Page 51 Next to continue. 4. Accept the software license agreement and proceed with the installation process. 5. On the Readme File Information screen, click Install. 6. After completing the installation, click Finish to complete the setup process. ASB200-838 User Manual...

  • Page 52: Vga Driver Installation

    3.3 VGA Driver Installation 1. Run the drivers disk. Click Intel on the left pane and then Intel(R) AlderLake-N Chipset Drivers on the right pane. 2. Click Intel(R) HD Graphics Driver. 3. Click Begin installation. ASB200-838 User Manual...
  • Page 53 Driver Installation 4. Click I agree to accept the license agreement. 5. On the next screen, click Start and then click Finish when installation has been completed. ASB200-838 User Manual...

  • Page 54: Hd Audio Driver Installation

    3.4 HD Audio Driver Installation 1. To complete the audio driver installation, go to the system’s Device Manager to Update driver of the High Definition Audio Controller. ◆ ◆ 2. Locate and install the driver manually. ◆ ASB200-838 User Manual...
  • Page 55 Driver Installation 3. Go to the subfolder shown below and click Next. ◆ 4. Windows has finished installing the drivers. Click Close. ASB200-838 User Manual...
  • Page 56 AlderLake-N Chipset Drivers on the right pane. 6. Click Realtek High Definition Audio Driver. 7. On the Welcome screen of the InstallShield Wizard, click Next. 8. On the next screen, click Next. 9. On the next screen, click Finish. ASB200-838 User Manual...

  • Page 57: Lan Driver Installation

    1. Run the drivers disk. Click Intel on the left pane and then Intel(R) AlderLake-N Chipset Drivers on the right pane. 2. Click Intel(R) PRO LAN Network Drivers.. 3. On the Network Connections screen, click Install Drivers and Software. 4. When the Welcome screen appears, click Next. ASB200-838 User Manual...
  • Page 58 5. On the next screen, accept the license agreement and click Next. 6. On the Setup Options screen, click Next to continue. 7. On the Ready to Install the Program screen, click Install. 8. When the Install wizard has completed the installation, click Finish. ASB200-838 User Manual...

  • Page 59: Intel® Management Engine Drivers Installation

    AlderLake-N Chipset Drivers on the right pane. 2. Click Intel(R) ME 15.x Drivers. 3. When the Welcome screen appears, click Next. 4. Accept the license agreement and click Next. 5. After Intel Management Engine Components have been successfully installed, click Finish. ASB200-838 User Manual...

  • Page 60: Intel(R) Serial Io Drivers Installation

    3. In the Welcome screen, click Next. 4. In the next screen, accept the license agreement and click Next. 5. In the Readme File Information screen, click Next. 6. In the Confirmation screen, click Next. 7. When installation has been completed, click Finish. ASB200-838 User Manual...

  • Page 61: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup This chapter describes the different settings available in the AMI BIOS that comes with the board. The topics covered in this chapter are as follows: Main Settings • Advanced Settings • Chipset Settings • Security Settings •...

  • Page 62: Introduction

    These defaults have been carefully chosen by both AMI and your system manufacturer to provide the absolute maximum performance and reliability. Changing the defaults could make the system unstable and crash in some cases. ASB200-838 User Manual...

  • Page 63: Main Settings

    BIOS Setup 4.3 Main Settings BIOS Setting Description Sets the date. Use the <Tab> key to switch between the System Date date elements. Set the time. Use the <Tab> key to switch between the System Time time elements. ASB200-838 User Manual...

  • Page 64: Advanced Settings

    4.4 Advanced Settings This section allows you to configure system features according to your preference. ASB200-838 User Manual...
  • Page 65 Serial IO UART0 needs to be enabled to select BT interface. Bluetooth Interface BT Tile Mode Options: Enabled/Disabled Advanced Configure ACPI objects for wireless devices Settings Default: Disabled WWAN Configure WWAN related options. Configuration WWAN Device: enable or disable M.2 WWAN device ASB200-838 User Manual...
  • Page 66 Technology Technology. Active Number of E-cores to enable in each processor package. Efficient-cores Note: Number of cores and E-cores are looked at together. When both are (o,o), Pcode will enable all cores. Enable/Disable AES (Advanced Encryption Standard) ASB200-838 User Manual...
  • Page 67 CPU – Power Management Control Options Management Control Allows more than two frequency ranges to be Intel Speedstep supported Enable/Disable Intel Speed Shift Technology Intel Speed Shift support. Enabling will expose the CPPC v2 Technology interface to allow for hardware controlled P-states. ASB200-838 User Manual...
  • Page 68 4.4.4 PCH-FW Configuration ASB200-838 User Manual...
  • Page 69 TPM 1.2 will restrict support to TPM 1.2 devices. TPM 2.0 will restrict support to TPM 2.0 devices. Device Select Auto will support both with the default set to TPM 2.0 devices if not found, TPM 1.2 devices will be enumerated. ASB200-838 User Manual...
  • Page 70 Enables / Disables the system ability to hibernate (OS/S4 Enable Sleep State). This option may be not effective with some Hibernation ACPI Sleep Select the highest ACPI sleep state the system will enter State when the SUSPEND button is pressed. ASB200-838 User Manual...
  • Page 71 BIOS Setup 4.4.7 LVDS Configuration ASB200-838 User Manual...
  • Page 72 Select an optimal setting for the Super IO device. Options are: IO=2E8h; IRQ=7; IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12; Change Settings IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12; IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; Standby Power on Enable – provide the standby power for devices. S5 (Eup) Disable – shutdown the standby power. ASB200-838 User Manual...
  • Page 73 Hardware Monitor BIOS Setting Description These fields are the parameters of the hardware Temperatures / monitoring function feature of the motherboard. The Voltages values are read-only values as monitored by the system and show the PC health status. ASB200-838 User Manual...
  • Page 74 4.4.10 AMI Graphic Output Protocol Policy ASB200-838 User Manual...
  • Page 75 Max.time the device will take before it properly reports Device itself to the Host Controller. ‘Auto’ uses default value: for a power-up delay Root port it is 100ms, for a Hub port the delay is taken from Hub descriptor. ASB200-838 User Manual...

  • Page 76: Chipset Settings

    4.5 Chipset Settings 4.5.1 System Agent (SA) Configuration 4.5.1.1. Graphics Configuration: ASB200-838 User Manual...
  • Page 77 Enables / Disables Serial Port 0 ~ 2. SATA Ports Hot Plug Enables / Disables SATA Ports HotPlug. Power-On After Power Specify what state to go to when power is failure re-applied after a power failure (G3 state) ASB200-838 User Manual...

  • Page 78: Security Settings

    The mode change requires platform reset. Secure Boot mode options: Standard or Custom. In Custom mode, Secure Boot Policy variables can Secure Boot Mode be configured by a physically present user without full authentication ASB200-838 User Manual...

  • Page 79: Boot Settings

    Number of seconds to wait for setup activation key. Timeout 65535 (0xFFFF) means indefinite waiting. Bootup NumLock Selects the keyboard NumLock state. State Quiet Boot Enables / Disables Quiet Boot option. FIXED BOOT Sets the system boot order. ORDER Priorities ASB200-838 User Manual...

  • Page 80: Save & Exit Settings

    Saves the changes done so far as User Defaults. Restore User Defaults Restores the user defaults to all the setup options. Launch EFI Shell from Attempts to launch EFI shell application (Shell.efi) filesystem device from one of the available filesystem devices. ASB200-838 User Manual...
  • Page 81 BIOS Setup This page is intentionally left blank. ASB200-838 User Manual...

  • Page 82: Appendix

    Appendix This section provides the mapping addresses of peripheral devices and the sample code of watchdog timer configuration. I/O Port Address Map • Interrupt Request Lines (IRQ) • Digital I/O Sample Code • Watchdog Timer Configuration •...

  • Page 83: I/O Port Address Map

    Programmable interrupt controller 0x00000030-0x00000031 Programmable interrupt controller 0x00000034-0x00000035 Programmable interrupt controller 0x00000038-0x00000039 Programmable interrupt controller 0x0000003C-0x0000003D Programmable interrupt controller 0x000000A0-0x000000A1 Programmable interrupt controller 0x000000A4-0x000000A5 Programmable interrupt controller 0x000000A8-0x000000A9 Programmable interrupt controller 0x000000AC-0x000000AD Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller ASB200-838 User Manual...
  • Page 84 0x00000D00-0x0000FFFF PCI Express Root Complex 0x00003090-0x00003097 Standard SATA AHCI Controller 0x00003080-0x00003083 Standard SATA AHCI Controller 0x00003060-0x0000307F Standard SATA AHCI Controller 0x00000040-0x00000043 System timer 0x00000050-0x00000053 System timer 0x00002000-0x000020FE Motherboard resources 0x00000060-0x00000060 Standard PS/2 Keyboard 0x00000064-0x00000064 Standard PS/2 Keyboard ASB200-838 User Manual...

  • Page 85: Interrupt Request Lines (Irq)

    Microsoft PS/2 Mouse IRQ 4294967293 PCI Express Root Port #9 - 54B0 Intel(R) USB 3.20 eXtensible Host Controller - IRQ 4294967291 1.20 (Microsoft) IRQ 4294967294 PCI Express Root Port #7 - 54BE IRQ 4294967278 Intel(R) Management Engine Interface #1 ASB200-838 User Manual...

  • Page 86: Watchdog Timer Configuration

    (SIO == 0) printf("Can not detect Fintek 81964, program abort.\n"); return(1); }//if (SIO == 0) if (argc != 2) printf(" Parameter incorrect!!\n"); return (1); bTime = strtol (argv[1], endptr, 10); printf("System will reset after %d seconds\n", bTime); if (bTime) ASB200-838 User Manual...
  • Page 87 // THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY // KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE // IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR // PURPOSE. ASB200-838 User Manual...
  • Page 88 (result); //--------------------------------------------------------------------------- void Unlock_F81964 (void) outportb(F81964_INDEX_PORT, F81964_UNLOCK); outportb(F81964_INDEX_PORT, F81964_UNLOCK); //--------------------------------------------------------------------------- void Lock_F81964 (void) outportb(F81964_INDEX_PORT, F81964_LOCK); //--------------------------------------------------------------------------- void Set_F81964_LD( unsigned char LD) Unlock_F81964(); outportb(F81964_INDEX_PORT, F81964_REG_LD); outportb(F81964_DATA_PORT, LD); Lock_F81964(); //--------------------------------------------------------------------------- void Set_F81964_Reg( unsigned char REG, unsigned char DATA) Unlock_F81964(); ASB200-838 User Manual...
  • Page 89 #define F81964_DATA_PORT (F81964_BASE+1) //--------------------------------------------------------------------------- #define F81964_REG_LD 0x07 //--------------------------------------------------------------------------- #define F81964_UNLOCK 0x87 #define F81964_LOCK 0xAA //--------------------------------------------------------------------------- unsigned int Init_F81964(void); void Set_F81964_LD( unsigned char); void Set_F81964_Reg( unsigned char, unsigned char); unsigned char Get_F81964_Reg( unsigned char); //--------------------------------------------------------------------------- #endif // F81964_H ASB200-838 User Manual...

  • Page 90: Onboard Connector Reference Types

    Serial Port DF11-10S-PA66H DF11-10DS-2C DC Power Hao Guo Xing Ye Input WAFER396-2S-WV VHR-2N Dupont Dupont Digital I/O 2.00 mm-pitch pin 2.00 mm-pitch header (Male) (Female) E-CALL Backlight 0110-161-040 PHR-4 Hirose Hirose LVDS J10, J15 DF20G-20DP-1V DF20A-20DS-1C SSL00-40S SSL20-40S ASB200-838 User Manual...
