Instruction Leaflet IL191023EN
Eaton Green Motion Building Pro and
Green Motion Fleet Pro commissioning
Effective January 2024
Contents
Description
Document overview . . . . . . . . . . . . . . . . . . . . . . . . . .3
Accessing Admin Menu . . . . . . . . . . . . . . . . . . . . . . . .5
EV charge station commissioning via Wi-Fi . . . . . . .8
EV charge station commissioning via Ethernet . . .9
EV charge station commissioning via cellular
(non-Eaton SIM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
EV charge station in non-CNM
(non-network) mode . . . . . . . . . . . . . . . . . . . . . . . 10
EV charge station commissioning to a
third-party (non-Eaton) CPO software . . . . . . . . . 11
EV charge station setup during loss of CPO . . . . 12
Page
Advertisement
Related Manuals for Eaton Green Motion Building Pro
Summary of Contents for Eaton Green Motion Building Pro
- Page 1 EV charge station commissioning to a third-party (non-Eaton) CPO software . . . . . . . . . 11 EV charge station setup during loss of CPO . . . . 12...
- Page 2 CONTENTS OF THIS DOCUMENT SHALL NOT BECOME PART OF OR MODIFY ANY CONTRACT BETWEEN THE PARTIES . In no event will Eaton be responsible to the purchaser or user in contract, in tort (including negligence), strict liability or otherwise for any special, indirect, incidental or...
- Page 3 For scenarios other than the ones mentioned in the Notice on page 2, refer to this document for instructions to connect Green Motion Building Pro and Green Motion Fleet Pro (EV charge station) to Eaton CNM software . Additionally, this document provides instructions to operate your EV charge station in a non-CNM (non-network) mode .
- Page 4 Instruction Leaflet IL191023EN Eaton Green Motion Building Pro and Green Motion Fleet Pro commissioning Effective January 2024 Figure 2 shows LCD home screen of an EV charge station with various icons . EV charge station Ethernet Wi-Fi Cellular power rating...
- Page 5 The Admin Menu of all EV charge stations is password protected . Default password to log in is eaton . Users who log in with default password will be required to update to a stronger password . See Figure 4 .
- Page 6 Instruction Leaflet IL191023EN Eaton Green Motion Building Pro and Green Motion Fleet Pro commissioning Effective January 2024 Figure 6 shows the Admin Menu available to installers . Figure 6. Admin Menu EV Charger Info includes model number, serial number, OCPP ID, and display ID of the EV charge station .
- Page 7 Eaton Green Motion Building Pro and Instruction Leaflet IL191023EN Green Motion Fleet Pro commissioning Effective January 2024 System Settings will provide access to General Settings (time, LCD language, sensor light, and maximum output current settings), EV Charger Logs, and ability to perform Factory Reset .
- Page 8 Effective January 2024 EV charge station commissioning via Wi-Fi All Building Pro and Fleet Pro models support Wi-Fi . The Eaton EV charge station supports only 2 .4 GHz Wi-Fi currently . To access Wi-Fi settings on your EV charge station, go to Admin Menu -> Connectivity Settings ->...
- Page 9 All Building Pro and Fleet Pro models support Ethernet connection . Once an Ethernet (RJ45) cable with valid internet connection is plugged in, the EV charge station will automatically attempt to connect to the Eaton CNM . LCD screen icons indicate both an Ethernet connection and an Eaton CNM connection .
- Page 10 Model numbers GMEV48CMC1-WC and GMEV80CMC1-WC have a 4G module . As indicated earlier, these model numbers ship with an SIM card supplied by Eaton’s CNM . If users wish to use a different SIM card, they need to follow the instructions provided (Fleet Pro Instructions and Building Pro Instructions) to carefully disassemble the EV charge station and replace the SIM card .
- Page 11 EV charge station commissioning to a third-party (non-Eaton) CPO software Follow the instructions below to commission the EV charge station to a non-Eaton CNM software . If you are using an EV charge station with 4G module, please note that you will have to replace the SIM card with the one supplied by your CPO provider .
- Page 12 Instruction Leaflet IL191023EN Eaton Green Motion Building Pro and Green Motion Fleet Pro commissioning Effective January 2024 EV charge station setup during loss of CPO Your EV charge station offers two options in the event it loses connection to CPO: 1.
