- Page 1 Eaton Green Motion Green Motion Building and Green Motion Fleet commissioning guide...
- Page 2 CONTENTS OF THIS DOCUMENT SHALL NOT BECOME PART OF OR MODIFY ANY CONTRACT BETWEEN THE PARTIES. In no event will Eaton be responsible to the purchaser or user in contract, in tort (including negligence), strict liability or otherwise for any special, indirect, incidental or consequential damage or loss whatsoever, including but not limited to...
-
Page 3: Table Of Contents
3.0 EV CHARGE STATION COMMISSIONING VIA ETHERNET ........5 4.0 EV CHARGE STATION COMMISSIONING VIA CELLULAR (NON-EATON SIM) ..... 6 5.0 EV CHARGE STATION IN NON-CNM (NON-NETWORK) MODE . -
Page 4: Document Overview
For scenarios other than the ones mentioned in the “NOTICE” on the previous page, refer to this document for instructions on how to use Eaton’s EV charge station Commissioning Tool to connect Green Motion™ Building and Green Motion Fleet (EV charging station) to Eaton CNM software. - Page 5 Instructions on how to install this EV charger Commissioning Tool and connect to the EV charge station are provided in Section 8.0. You will need a laptop or a computer with Windows 8/10/11 and an RJ45 (Ethernet) cable. ® Green Motion BuildinG and Green Motion FleetcoMMissioninG Guide IL191013EN June 2023 www.eaton.com...
-
Page 6: Ev Charge Station Commissioning Via Wi-Fi
2.0 EV charge station commissioning via Wi-Fi Model numbers GMEV40CME1B-WC and GMEV80CME1B-WC support Wi-Fi. To use Wi-Fi for Eaton CNM connectivity, users are required to use the Eaton EV charger Commissioning Tool. The Eaton EV charge station currently supports only 2.4 GHz Wi-Fi. - Page 7 RJ45 (Ethernet) cable. Once the EV charge station powers up, it will connect to the Wi-Fi router and subsequently to the Eaton CNM. The image below shows the EV charge station is connected to a local Wi-Fi connection and the Eaton CNM.
-
Page 8: Ev Charge Station Commissioning Via Ethernet
All Green Motion Building and Green Motion Fleet model numbers support Ethernet connection. When an Ethernet (RJ45) cable with valid internet connection is plugged in, the EV charge station will automatically attempt to connect to the Eaton CNM. LCD screen icons indicate both an Ethernet connection and an Eaton CNM connection. -
Page 9: Ev Charge Station Commissioning Via Cellular (Non-Eaton Sim)
Model numbers GMEV40CMC1B-WC and GMEV80CMC1B-WC have a 4G module. As indicated earlier, these model numbers ship with an SIM card supplied by Eaton’s CNM. If you wish to use a different SIM card, you need to follow the instructions provided to carefully disassemble the EV charge station and replace the SIM card. - Page 10 When the EV charge station powers up, it will attempt to establish cellular connectivity with the carrier network. Once successfully connected to the cellular network, it will attempt to connect with the Eaton CNM. “Cellular” and “Eaton CNM” icons will be illuminated on the display when successful connections are established.
-
Page 11: Ev Charge Station In Non-Cnm (Non-Network) Mode
Reboot EV Charge station). 5. Disconnect the EV charge station from the Commissioning Tool by disconnecting the RJ45 (Ethernet) cable. The EV charge station is now available in non-network mode. Green Motion BuildinG and Green Motion FleetcoMMissioninG Guide IL191013EN June 2023 www.eaton.com... -
Page 12: Ev Charge Station Commissioning To A Third-Party (Non-Eaton) Cnm Software
6.0 EV charge station commissioning to a third-party (non-Eaton) CNM software Follow the instructions below to commission the EV charge station to a non-Eaton CNM software. 1. Connect the EV charge station to the Commissioning Tool per instructions in Section 8.0. -
Page 13: Update Ev Charge Station Lcd Display Language (English/French/Spanish)
RJ45 (Ethernet) cable. When the EV charge station is powered up, the LCD display language will be updated. Figure 13. Change the LCD display language on your EV charge station Green Motion BuildinG and Green Motion FleetcoMMissioninG Guide IL191013EN June 2023 www.eaton.com... -
Page 14: Ev Charge Station Commissioning Tool Install And Setup
8.0 EV charge station Commissioning Tool install and setup 8.0 EV charge station Commissioning Tool install and setup Eaton’s EV charge station Commissioning Tool is available on Eaton’s product website for Green Motion Building and Green Motion Fleet, under the Resources section. - Page 15 2. Right click on the ‘Ethernet’ connection (connected to EV charge station) and select Ethernet Properties -> Networking Tab -> Internet Protocol Version 4 (TCP/IPv4). Select this setting and click Properties. See image below. Figure 16. Ethernet connection properties Green Motion BuildinG and Green Motion FleetcoMMissioninG Guide IL191013EN June 2023 www.eaton.com...
- Page 16 Users may see a firewall setting pop up. Check the settings as shown and click ote: Allow Access. Figure 18. Firewall setting to allow access to Commissioning Tool Green Motion BuildinG and Green Motion FleetcoMMissioninG Guide IL191013EN June 2023 www.eaton.com...
- Page 17 If you are still unable to connect your computer to the EV charge station, please check the firewall list and add “eaton green motion building and fleet commissioning tool. Exe” to the Allow list. Figure 19. Add EV charge station Commissioning Tool to Allow list...
- Page 18 1. To connect to the EV charge station, you will need the EV charge station serial number, which is found on a QR code sticker attached to the EV charge station. Default password to log in is “eaton” . It is recommended that this default password be updated to a stronger password upon installation.
- Page 19 Settings -> Password Reset tab. Once connected, you will be able to update various EV charge station settings available under the Settings menu. Green Motion BuildinG and Green Motion FleetcoMMissioninG Guide IL191013EN June 2023 www.eaton.com...
- Page 20 6. Within 15 minutes, power cycle the EV charge station by tripping and resetting the circuit breaker powering the EV charge station. 7. You can now connect to the EV charge station with the default password (eaton). 8. You will be required to update the password to a stronger password.
