- Page 1 Green Motion chargers Installation guide: Green Motion™ Building Pro cord replacement...
-
Page 2: Table Of Contents
Contents PRODUCT INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 PACKAGE CONTENTS . -
Page 3: Product Introduction
Eaton Green Motion Building Pro replacement NACS EV connector and 20-foot cord. J1772 EV connector and 25-foot cord. For use with Eaton Green Motion Building Pro, 48 A For use with Eaton Green Motion Building Pro, 48 A (GMEV48CME1-WC, GMEV48CMC1-WC). -
Page 4: Installation
THE LINE SIDE OF THE MAIN BREAKER IS ENERGIZED UNLESS POWER IS DISCONNECTED UPSTREAM. EATON WILL NOT ASSUME RESPONSIBILITY FOR PROPERTY DAMAGE OR PERSONAL INJURY RESULTING FROM MISUSE OF THE INFORMATION IN THIS PUBLICATION. NOTICE INSTALL EQUIPMENT IN CONFORMANCE WITH CODES. GREEN MOTION BUILDING PRO CORD REPLACEMENT www.eaton.com... -
Page 5: General Reference
WARNING - Risk of Explosion . This equipment has arcing or 10” max sparking parts that should not be exposed to flammable vapors. This equipment should be located at least 18 inches (460 mm) above the floor. 48” max GREEN MOTION BUILDING PRO CORD REPLACEMENT www.eaton.com 18” min... -
Page 6: A Remove The Old Charging Cable
(1) . Loosen the screws (2) along the back of the unit and remove the upper cover. You may need to remove the charger from the mount to access the screws . Refer to Green Motion Building Pro IL191021EN for instructions on how to remove the charger . - Page 7 Installation Guide STEP A-2 Disconnect CS and CP signal wires and cut the zip-ties as needed . Remove the screws for the L1, L2 and ground wires . Ground GREEN MOTION BUILDING PRO CORD REPLACEMENT www.eaton.com...
- Page 8 Green Motion Building Pro cord replacement STEP A-3 Remove the screws (1) holding the cable clamp and set it aside . Loosen the EV cord grip nut (2) and remove the cable through the housing . GREEN MOTION BUILDING PRO CORD REPLACEMENT www.eaton.com...
-
Page 9: B Install The New Charging Cable
[A] into the housing. Position the cable with approximately 0.5 inch of wire insulation above the cable clamp . Tighten the cable clamp (2) . Tighten the EV cord grip to secure the cable . 0.5 inch Reference: • EV charging cable [A] GREEN MOTION BUILDING PRO CORD REPLACEMENT www.eaton.com... - Page 10 • GND: 13 .9 lbf-in Note: Only connect this wire if using the J1772 cord . Do not connect if using a NACS cord . Ground Reference: • NACS premium cord holster [B] GREEN MOTION BUILDING PRO CORD REPLACEMENT www.eaton.com...
-
Page 11: Installation Is Complete
Replace the upper cover (1) and tighten the screws (2) along the back of the unit . Replace the lower cover (3) and tighten the two screws on the underside of the front . Installation is complete. It is safe to restore power. GREEN MOTION BUILDING PRO CORD REPLACEMENT www.eaton.com... - Page 12 1000 Eaton Boulevard Cleveland, OH 44122 United States Eaton .com © 2025 Eaton All Rights Reserved Eaton is a registered trademark . Printed in USA IL191025EN / Bally Rev 03 All trademarks are property February 2025 of their respective owners .
