DIGITRAK FALCON F2+ USER MANUAL
DCI DigiGuide 05.18.2024
After using one of the Advanced methods to pick the bands, you will pair
them with the transmitter and then calibrate.
watch video on Youtube:
Scan, Pick, Pair - English (1:52 min)
https://youtu.be/pTEpehZ09A4
BASIC - QUICK SCAN PAIR
STEP 1 OF 8
Before You Start
Basic - Quick Scan Pair scans noise and selects the best frequencies for the
preset Up and Down bands. These presets may not be the best bands for the
jobsite.
Use Advanced - Scan Pick Pair t o view noise on all bands.
STEP 2 OF 8
Ensure all transmitters are powered off or more than 30.5 m away from the
locator.
Inspect the job site and move locator to active noise area of concern or deep
part of bore - keep locator above and parallel to bore path.
STEP 3 OF 8
From the Main menu, select
Quick Scan Pair.
STEP 4 OF 8
Confirm the pre-set bands and the power mode.
