Model
Maximum Cordwood BTU's
Emissions (grams/hr) EPA Certified
Efficiency (EPA HHV)*
Flue Size
Volume
Maximum Log Size
*The stated efficiency is based on the higher heating value of the fuel.
This Model cannot be sold in the U.S.A.
6" (152mm) Diameter
6" (152mm) Diameter
STANDARD FLUE ADAPTOR (172-942)
STANDARD FLUE ADAPTOR (172-942)
Ci1150CSA Alterra
Ci1150CSA
55,000 BTU's
1.7 grams/hr
0.088 g/MJ (Output)
70%
6" (152mm)
0.98 cu. ft.
18" (457 mm)
UNIT DIMENSIONS
Standard Flue Adapter
Wood Insert
®
15 1/8"
(384 mm)
15 1/8"
(384 mm)
6" (152mm) Diameter
6" (152mm) Diameter
OFFSET FLUE ADAPTOR (172-946)
OFFSET FLUE ADAPTOR (172-946)
Ci1150CSA Alterra
Wood Insert |
1
®
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Regency Fireplace Products Alterra Ci1150CSA
Summary of Contents for Regency Fireplace Products Alterra Ci1150CSA
- Page 1 Ci1150CSA Alterra Wood Insert ® Model Ci1150CSA Maximum Cordwood BTU’s 55,000 BTU’s 1.7 grams/hr Emissions (grams/hr) EPA Certified 0.088 g/MJ (Output) Efficiency (EPA HHV)* Flue Size 6" (152mm) Volume 0.98 cu. ft. Maximum Log Size 18” (457 mm) *The stated efficiency is based on the higher heating value of the fuel. This Model cannot be sold in the U.S.A.
- Page 2 OPTIONAL BACKING PLATE DIMENSIONS CI1150 Standard 40” (1016mm) 40” (1 CI1150 Custom - Minimum Dimensions 37” (940mm) 37” ( | Ci1150CSA Alterra Wood Insert ®...
- Page 3 MASONRY FIREPLACE CLEARANCES The minimum required clearances to combustible materials when installed into a masonry fireplace are listed below. Unit Adjacent Mantel*** Side Minimum Minimum From Top of From Side of Side Wall (to top) Facing Facing Hearth Hearth Side Door Door CI1150...
- Page 4 CHIMNEY SPECIFICATIONS INSTALLATION INTO A MA- DRAFT SONRY FIREPLACE Before installing, check and clean your chimney Draft is the force which moves air from the system thoroughly. If in doubt about its condition, appliance up through the chimney. The amount of Regency inserts are constructed with the highest seek professional advice.
