Regency Fireplace Products Alterra Ci1150CSA Owners & Installation Manual

Wood insert
Hide thumbs Also See for Alterra Ci1150CSA:

Advertisement

Quick Links

Download this manual
Owner's & Installation Manual
French Manual:
https://bit.ly/3rAduEq
Manuel en Français :
https://bit.ly/3rAduEq
MODEL: Ci1150CSA
Tested by:
Project No.
0219WN027S
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
920-824
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Ci1150CSA
Alterra
®
Wood Insert
11.06.24

Advertisement

loading
Need help?

Need help?

Do you have a question about the Alterra Ci1150CSA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Regency Fireplace Products Alterra Ci1150CSA

Summary of Contents for Regency Fireplace Products Alterra Ci1150CSA

  • Page 1 Ci1150CSA Alterra ® Wood Insert Owner's & Installation Manual French Manual: https://bit.ly/3rAduEq Manuel en Français : https://bit.ly/3rAduEq MODEL: Ci1150CSA Tested by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. Project No.
  • Page 2 Thank-you for purchasing a REGENCY FIREPLACE PRODUCT. The pride of workmanship that goes into each of our products will give you years of trouble-free enjoyment. Should you have any questions about your product that are not covered in this manual, please contact the REGENCY DEALER in your area. “This wood heater has a manufacturer set minimum low burn rate that must not be altered.
  • Page 3 table of contents Safety Decal Maintenance Copy of the Safety Decal ..........4 Ash Disposal ..............21 Safety Guidelines and Warnings........21 Maintenance ..............22 Dimensions Creosote ............... 22 Wood Storage ............... 22 Unit Dimensions .............. 5 Door Gasket ..............23 Optional Backing Plate Dimensions ........
  • Page 4 safety decal Copy of the Ci1150CSA Safety Decal (Duplicate Serial #) LISTED MASONRY FIREPLACE INSERT DO NOT REMOVE THIS LABEL / NE PAS ENLEVER CETTE ÉTIQUETTE CERTIFIED FOR USE IN CANADA This is a copy of the label that accompanies each Ci1150CSA MODEL: Ci1150CSA Wood Insert.
  • Page 5 dimensions Unit Dimensions NOTE: Before assembling Offset Flue your Insert, use these Adapter dimensions to ensure appropriate clearances will be met (refer to M a s o n r y F i r e p l a c e Clearances section). 15 1/8"...
  • Page 6 dimensions Optional Backing Plate Dimensions Ci1150CSA Standard 40” (1016mm) 40” (1016mm) Ci1150CSA Custom - Minimum Dimensions 37” (940mm) 37” (914mm) Regency Ci1150CSA Wood Cast Insert...
  • Page 7 installation Masonry Fireplace Clearances The minimum required clearances to combustible materials when installed into a masonry fireplace are listed below. Unit Adjacent Mantel*** Side Minimum Minimum From Top of From Side of Side Wall (to top) Facing Facing Hearth Hearth Side Door Door Ci1150CSA...
  • Page 8 installation How to Determine if Alternate Floor Protection Materials are Acceptable All floor protection must be noncombustible (i.e. metals, brick, stone, mineral fiber boards, concrete board etc.). The noncombustible floor protection specified includes some form of thermal designation such as R-value (thermal resistance) or k-factor (thermal conductivity).
  • Page 9 installation Chimney Specifications Installation Into a Masonry Draft Fireplace Before installing, check and clean your chimney Draft is the force which moves air from the ap- system thoroughly. If in doubt about its condition, pliance up through the chimney. The amount of Regency inserts are constructed with the highest seek professional advice.
  • Page 10 installation Installing Your Insert 4. Slide the unit back until the flue adaptor is 9. Remove the pull rod from the top center of the slightly engaged. fireplace. See Diagram 7. SAFETY NOTE: The insert is very heavy and 5. At this point it is recommended to level the will require two or three people to move it into unit and ensure that the leveling bolts rest position.
  • Page 11 CI1150 installation Cast Faceplate Installation CAST FACEPLATE INSTALLATION Stop! Read Carefully. Cast components are very fragile. Use extreme care when handling. 1) Open the door to about 45°- then remove it from the hinge by lifting 3) Remove two bolts from the bracket on the unit as shown below. up and out.
  • Page 12 CI1150 installation 10) Tighten both screws once all three cast pieces are level. 6) Repeat Steps 3 and 5 to install right cast surround. 11) Remove the two (2) bolts from the lower part of the brackets on the unit - see diagram below. 12) Move the damper control lever to the right so it is out of the way.
  • Page 13 CI1150 installation 15) Reinstall door. 16) The fan cord can be re-routed to the right side of the unit if necessary. Before installing the lower cast surround - run the cord between the left cast surround and the unit. Then run the cord along the lower part of the lower cast surround and out in between the right cast and the unit.
  • Page 14 installation 3-Piece Backing Plate Installation An optional backing plate is available in either a standard or custom Install 2 clips to the back of the top cast faceplate with hex bolts. size. If the unit is already installed - remove the top cast faceplate from the unit if access is too difficult - see 'Cast Faceplate Installation' in the owners manual for instructions.
  • Page 15 installation Brick Installation Firebrick is included to extend the life of your stove and radiate heat more evenly. Check to see that all firebricks are in their correct positions and have not become misaligned during shipping. Install all firebricks (if bricks were removed at install) per the Diagram below and place in their correct positions. Do not use a grate.
  • Page 16 installation Baffle Installation Note: unit in images may not be identical to the Ci1150CSA — they depict 5. Secure the baffles into position by lifting up on the brick slightly so that the the process. locking bracket slides over the airtube as shown. Repeat step on other side. 1.
  • Page 17 installation Stainless Steel Smoke Deflector Installation The stainless smoke deflector is located in the upper front area of the firebox. The deflector is held in place with 2 bolts. Prior to the first fire, ensure deflector is seated properly and secured with 2 hand tightened bolts which are accessible from behind the smoke deflector. Smoke deflector Smoke deflector is installed through the door opening in location shown in Diagram To replace the deflector, loosen off both bolts and slide deflector downward, push deflector to the back wall of the unit and manoeuver out.
  • Page 18 operating instructions Seasoned Wood Whether you burn wood in a fireplace, stove or insert, good quality firewood is the key to convenience, efficiency and safety. Wet wood and pieces that are not the right size and shape for your wood burner can be frustrating, burn inefficiently and deposit creosote that can fuel a dangerous chimney fire.
  • Page 19 operating instructions Operating Instructions Optimum Fueling & WARNING: Never build a roaring fire in a cold wood insert. Always warm your wood Operating Procedures stove up slowly! With your unit now correctly installed and safety inspected by your local authority, you are now 1.
  • Page 20 maintenance Fan Operation Cord Reversal The fan is to be operated only with the draft control rod pulled out at least The fan cord comes out from the left hand side of the unit. if it is necessary 1/2" from the fully closed position. The fan is not to be operated when the to have the cord coming from the right side - follow these steps: draft control rod is in the closed position (pushed in).
  • Page 21 maintenance Ash Disposal Safety Guidelines and CAUTION: HOT WHILE IN OPERATION. KEEP CHILDREN, Warnings During constant use, ashes should be removed CLOTHING AND FURNITURE every few days. AWAY. CONTACT MAY CAUSE CAUTION: Do not use chemicals as fluids to SKIN BURNS. start fire.
  • Page 22 maintenance Maintenance 4. A small hot fire is preferable to a large smouldering one that can deposit creosote within the system. It is very important to carefully maintain your fireplace stove, including burning seasoned wood 5. The chimney and chimney connector should be and maintaining a clean stove and chimney system.
  • Page 23 maintenance Door Gasket Glass Replacement If the door gasket requires replacement, 7/8" diameter material must be used. Allow the stove to cool before removing or replacing glass. Remove the door A proper high temperature gasket adhesive is required. A gasket repair kit, from the stove and remove the glass retainer.
  • Page 24 maintenance Handle Replacement Fan Maintenance 1) Remove handle by undoing the hex head bolt using a 7/16" socket wrench. TO REMOVE THE FAN 2) Fit new door handle over door latch and secure. 1) See next page. Assemble handle by: Maintenance: The sealed bearings are lubricated, there is no need to lu- a) Placing lock washer and split lock washer over hex head bolt.
  • Page 25 maintenance Fan Removal Prior to removing fan, disconnect / unplug power source to fan 5) Remove fan from unit. CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. 1) Open door to a 45° angle. 2) Holding door firmly from top and bottom - lift door up and off to remove.
  • Page 26 maintenance Secondary Air Tube Removal/Installation 1. Allow the stove to burn out and cool down, until cool to touch. 5. To reinstall or replace, first slide left side of tube into hole on left side air channel. Align tab on right side air channel with notch on right hand end 2.
  • Page 27 maintenance Vertical Stainless Deflector Replacement I1200 CONTEMPORARY 7/16'' Bolts 7/16'' Nuts Slide right + down to remove. Reverse to replace. Vertical Deflector Remove 2 front air tubes 1. Remove 2 front secondary air tubes / vermiculite baffles (see manual for details). of 1 157-500.SLDASM 10/15/2019...
  • Page 28 maintenance Annual Maintenance Completely clean out entire unit Annually Inspect air tube and bricks Replace any damaged parts. Adjust door catch assembly If unable to obtain a tight seal on the door - replace door gasket seal. Readjust door catch after new gasket installed. Inspect condition and seal of: Glass Gasket Door Gasket...
  • Page 29 parts list Main Assembly Ci1150CSA Part # Description Part # Description 075-037 Smoke Deflector 14) 075-064 Andiron Bracket (Each) 075-041 Baffle Holder 15) 156-523 Door Hinge 033-953 Air Tubes (each) 16) 156-035 Glass Gasket Frame 075-955 Baffle Set Complete 17) 940-366/P Neoceram Glass (includes Glass Gasket) 075-040 Side Baffle Cover (Each)
  • Page 30 parts list Brick Panels 075-960 Ci1150CSA Brick Kit Complete Fire bricks Size 4-1/4" x 7" 4-1/2" x 7" 9" x 4-1/2" 9" x 2" 3-1/2" x 4-1/2" 4-1/4" x 8" 3-1/2" x 2-1/4" 30 | Regency Ci1150CSA Wood Cast Insert...
  • Page 31 parts list Cast Faceplate Part # Description 156-951 Metallic Black Faceplate CI1150CSA Top Surround Left Side Surround Right Side Surround Bottom Surround * Not available as a replacement part. Ci1150CSA Bottom Surround Regency Ci1150CSA Wood Cast Insert...
  • Page 32 warranty Indoor Wood Product Warranty Limited Lifetime Warranty FPI Fireplace Products International Ltd. (for Canadian customers) and Fireplace Products U S, Inc. (for US customers) (collectively referred to herein as “FPI”) extends this Limited Lifetime Warranty to the original purchaser of this Appliance provided the product remains in the original place of installation.
  • Page 33 warranty The authorized selling dealer, or an alternative authorized FPI dealer if pre-approved by FPI, is responsible for all in- field diagnosis and service work related to all warranty claims. FPI is not responsible for results or costs of workmanship of unauthorized FPI dealers or agents in the negligence of their service work. At all times, FPI reserves the right to inspect reported in the field/on location complaints of products claimed to be defective before processing or authorizing any claim.
  • Page 34 warranty FPI has no obligation to enhance or modify any Appliance once manufactured (i.e. as products evolve, field modifications or upgrades will not be performed on existing Appliances). Any Appliance showing signs of neglect or misuse will not be covered under the terms of this warranty policy and may void this warranty, including Appliances with rusted or corroded fireboxes that have not been reported as rusted or corroded within three (3) months of installation/purchase.
  • Page 35 warranty Warranty Registration Card Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
  • Page 36 36 | Regency Ci1150CSA Wood Cast Insert...
  • Page 37 recycling PRODUCT LIFE CYCLE: By recycling your used appliances, you divert waste from your local landfills and help the environment. You also reduce the need for raw materials to manufacture new products. Contact your local municipality for appliance recycling services, local recycling programs, or appliance removal services to ensure your Regency appliance components, and packaging are properly recycled.
  • Page 38 notes 38 | Regency Ci1150CSA Wood Cast Insert...
  • Page 39 Regency Ci1150CSA Wood Cast Insert...
  • Page 40 Installer: Please complete the following information Dealer Name & Address: _______________________________________ ___________________________________________________________ Installer: ___________________________________________________ Phone #: ___________________________________________________ Date Installed: _______________________________________________ Serial #: ____________________________________________________ Regency, Alterra are trademarks of FPI Fireplace Products International Ltd ® Printed in Canada © Copyright 2024, FPI Fireplace Products International Ltd. All rights reserved.
