Regency Fireplace Products Alterra CI1150 Quick Start Manual

Hide thumbs Also See for Alterra CI1150:
1
2
3
4

Advertisement

Quick Links

Download this manual
Model
Maximum Cordwood BTU's
Emissions (grams/hr) EPA Certified
Efficiency (EPA HHV)*
Efficiency (EPA LHV)
Flue Size
Volume
US Biomass Tax Rebate Eligible
*US Biomass Tax Rebate eligibility is based on the HHV value being
greater than or equal to 75%.
6" (152mm) Diameter
6" (152mm) Diameter
STANDARD FLUE ADAPTOR (172-942)
STANDARD FLUE ADAPTOR (172-942)
CI1150 Alterra
®
Ci1150
55,000 BTU's
1.7 grams/hr
70%
75%
6" (152mm)
0.98 cu. ft.
No
UNIT DIMENSIONS
Standard Flue Adapter
Wood Insert
15 1/8"
(384 mm)
15 1/8"
(384 mm)
6" (152mm) Diameter
6" (152mm) Diameter
OFFSET FLUE ADAPTOR (172-946)
OFFSET FLUE ADAPTOR (172-946)
CI1150 Alterra
NOTE: Before assembling
your Insert, use these
dimensions to ensure
appropriate clearances
will be met (refer to
Masonry and Factory Built
Fireplace Clearances
section).
Wood Insert |
®
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Alterra CI1150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Regency Fireplace Products Alterra CI1150

Summary of Contents for Regency Fireplace Products Alterra CI1150

  • Page 1 CI1150 Alterra Wood Insert ® Model Ci1150 Maximum Cordwood BTU’s 55,000 BTU’s Emissions (grams/hr) EPA Certified 1.7 grams/hr Efficiency (EPA HHV)* Efficiency (EPA LHV) Flue Size 6" (152mm) Volume 0.98 cu. ft. US Biomass Tax Rebate Eligible *US Biomass Tax Rebate eligibility is based on the HHV value being greater than or equal to 75%.
  • Page 2 OPTIONAL BACKING PLATE DIMENSIONS CI1150 Standard 40” (1016mm) 40” (1 CI1150 Custom - Minimum Dimensions 37” (940mm) 37” ( | CI1150 Alterra Wood Insert ®...
  • Page 3 MASONRY FIREPLACE CLEARANCES The minimum required clearances to combustible materials when installed into a masonry fireplace are listed below. Unit Adjacent Mantel*** Side Minimum Minimum From Top of From Side of Side Wall (to top) Facing Facing Hearth Hearth Side Door Door CI1150...
  • Page 4 CHIMNEY SPECIFICATIONS INSTALLATION INTO A MA- DRAFT SONRY FIREPLACE Before installing, check and clean your chimney Draft is the force which moves air from the system thoroughly. If in doubt about its condition, appliance up through the chimney. The amount of Regency inserts are constructed with the highest seek professional advice.
