Simplified MFG EXMICRO2iSW User Manual

18gbps extender with 2 input switch

Advertisement

Quick Links

EXMICRO2iSW
18Gbps Extender with 2 input Switch
VER 2.1
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the EXMICRO2iSW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Simplified MFG EXMICRO2iSW

  • Page 1 EXMICRO2iSW 18Gbps Extender with 2 input Switch VER 2.1...
  • Page 2 Thank you for purchasing this product The Simplified MFG EXMICRO2iSW is designed to provide years of reliable service. At Simplified MFG, we want the experience with this device to be the best possible and are committed to helping achieve that experience.
  • Page 3 this device more efficient and smaller. 2. Features • HDMI 2.0b, HDCP 2.2 / HDCP 1.4 and DVI 1.0 compliant • Supports input and output video resolution up to 4k2k@60Hz 4:4:4 up to 18Gbps • Two source (selectable via remote) inputs •...
  • Page 4 4. Specifications Technical HDMI Compliance HDMI 2.0b HDCP Compliance HDCP 2.2 / HDCP 1.4 Video Bandwidth 18Gbps HDR Formats HDR/HDR10+ Video Resolution Up to 4K60Hz 4:4:4 Color Space RGB / YCbCr 4:4:4, YCbCr 4:2:2/4:2:0, YUV 4:4:4 Color Depth 8/10/12-bit (1080P60Hz, 4K30Hz, 4K60Hz YCbCr 4:2:2/4:2:0) 8-bit (4K60Hz 4:4:4) HDMI Audio Formats LPCM 2.0/2.1/5.1/6.1/7.1, Dolby Digital, Dolby...
  • Page 5 5. Operation Controls and Functions 5.1 Transmitter Panel ❻ ❶ ❷ ❹ ❸ ❺ ❼ ❽ ❾ Number Name Function description HDMI In 1 HDMI Input 1 port, connect to HDMI source such as a streamer or a set top box HDMI In 2 HDMI input 2 port, connect to second HDMI source device such as a streamer or set top box...
  • Page 6 5.2 Receiver Panel ❻ ❶ ❷ ❹ ❸ ❺ ❼ ❽ ❾ Name Function description Number HDMI Out HDMI output port, connect to HDMI display device such as TV or Projector with an HDMI cable. TOSLINK Optical Audio Breakout CAT In Connect to CAT Out port on the transmitter end with a CAT6 cable.
  • Page 7 5.4 IR Remote Function and Codes 6. Application Example The terms HDMI and HDMI High-Definition Multimedia interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
  • Page 8 7. Troubleshooting The EXMICRO2iSW is 100% tested and uses a very stable and reliable chipset. It is unlikely to not work out of the box. HDMI is a constantly changing format and can change with little to now warning. The EXMICRO2iSW has a lot of safeguards built in to alleviate these pressures.
  • Page 9 Or b) Replace the product with new or refurbished product. All Simplified MFG products are covered by a 3-year warranty. During this period there will be no charge for unit repair, replacement of unit components or replacement of the product if deemed necessary.
