Simplified MFG EX1502K User Manual

1080p hdmi extender over single 150m/500ft. category cable with ir and rs232 control

Advertisement

Quick Links

EX1502K
1080p HDMI Extender
over single 150m/500ft. Category Cable with IR
and RS232 Control
----------1----------

Advertisement

loading
Need help?

Need help?

Do you have a question about the EX1502K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Simplified MFG EX1502K

  • Page 1 EX1502K 1080p HDMI Extender over single 150m/500ft. Category Cable with IR and RS232 Control ----------1----------...
  • Page 2 Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. ----------2----------...
  • Page 3 Surge protection device recommended The EX1502K contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc. Use of surge protection systems is highly recommended in order to protect and extend the life of your equipment.
  • Page 4: Table Of Contents

    Table of Contents Introduction Features Package Contents Specifications Operation Controls and Functions Connection Diagram Warranty Contact Us ----------4----------...
  • Page 5: Introduction

    Introduction The EX1502K is a 150 meter (500 ft.) HDMI of Category cable extender with Two-Way IR and RS232 transmission. Features HDMI 1.4, HDCP 1.4 and DVI compliant Supports video resolutions up to 1080p/60Hz./YUV4:4:4 HBR (High Bit Rate) Audio pass through 150m (500ft.) on Category 6 cable...
  • Page 6: Package Contents

    Package Contents (1) HDMI Extender Transmitter (1) HDMI Extender Receiver (1) Wideband IR Emitter (1) Wideband IR Receiver (1) 24V/1A multi-voltage AC power supply (1)User Manual ----------6----------...
  • Page 7: Specifications

    Specifications HDMI Compliance HDMI 1.4 HDCP Compliance HDCP 1.4 Video Bandwidth 148.5 MHz Video Resolutions 1080p/60Hz, YUV 4:4:4 / RGB 4:4:4 Color Space RGB/YUV 4:2:2, 4:4:4 Color Depth 8 Bit HDMI Audio Formats LPCM, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby True HD, DTS-HD Master Audio, Dolby Atmos, DTS-X ----------7----------...
  • Page 8 ESD Protection Human Body Model - ±8Kv (Air Gap Discharge) and ±4Kv (Contact discharge) Inputs TX: (1) HDMI Type A (19pin Female) (1) IR Input (3.5mm) (1) RS232 (Phoenix Connector) RX: (1) HDBaseT (RJ-45) (1) IR Input (3.5mm) (1) RS232 (Phoenix Connector) Outputs TX;...
  • Page 9 Mechanical Housing Metal Enclosure Color Black Dimensions 115mm(4.5”)x64.7mm(2.5”)x17mm(.67”) Weight 406g (14.3 oz.) Power Supply Input AC 100-240V 50/60Hz. Output DV 24V 1 Amp Power Consumption 5.76W Operation Temperature 32-104°F/0-40°C Storage Temperature -4-140°F/-20-60°C Relative Humidity 20-90% RH (non-condensing) ----------9----------...
  • Page 10: Operation Controls And Functions

    Operation Controls and Functions Transmitter ❶ Power System Power indicator – ❷ DC 24V – Connection for 24V/1A AC Power Supply ❸ HDBaseT Out – UTP cable Connection for HDBaseT Transmission ❹ HDMI In – HDMI Type A 19 pin signal input ----------10----------...
  • Page 11 ❺ IR In- IR receiver input to receive IR signals ❻ IR Out – IR Emitter connection ❼ RS232 – Phoenix connector for RS232 signal connection Green LED on RJ-45 – Illuminated = TX and RX are communicating properly Flashing = TX and RX have a poor connection Dark = TX and RX have no connection Amber LED on RJ-45 –...
  • Page 12 Receiver ❶ Power System Power indicator – ❷ DC 24V – Connection for 24V/1A AC Power Supply ❸ HDBaseT In – UTP cable Connection for HDBaseT from TX device ❹ HDMI Out – HDMI Type A 19 pin output to display ❺...
  • Page 13 ❼ RS232 – Phoenix connector for RS232 signal connection Green LED on RJ-45 – Illuminated = TX and RX are communicating properly Flashing = TX and RX have a poor connection Dark = TX and RX have no connection Amber LED on RJ-45 – Illuminated = HDMI input signal has HDCP Flashing = HDMI signal does not have HDCP Dark = HDMI signal is not present ----------13----------...
  • Page 14: Connection Diagram

    Connection Diagrams Power over Cable Illustration ----------14----------...
  • Page 15 Bi-Directional IR Illustration RS232 Illustration ----------15----------...
  • Page 16: Warranty

    Replace it with a new or refurbished product. All Simplified MFG products are covered by a 3 year PARTS and LABOR warranty. During this period there will be no charge for unit repair, replacement of unit components or replacement of product if necessary.
  • Page 17 warranty period. A purchase receipt or other proof of original purchase date is required for the limited warranty service. 1.This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship and DOES NOT COVER normal wear and tear or cosmetic damage. The limited warranty also DOES NOT COVER damage that occurs in shipment or failures caused by products not supplied by the warrantor, failures resulting from accident, misuse, abuse, neglect, mishandling, misapplication, alteration, incorrect installation,...
  • Page 18 2.There are no express warranties except as listed under “limited warranty coverage.” The warrantor is not liable for incidental or consequential damage resulting from the use of this product or arising out of any breach of this warranty. For example: damages for lost time, the cost of having a person/persons remove or re-install previously installed equipment, travel to and from service location, loss of or damage to media, images, data or other recorded/stored content.
  • Page 19 MFG reserves the right to change software, control codes and specifications without notice. Simplified MFG will not be liable for any use of this information or any changes it may make to those products. The use of this information constitutes an agreement by the user to these limitations and exclusions.
  • Page 20: Contact Us

    Contact 1-833-HDMI-411 info@simplifiedmfg.com ----------20----------...
  • Page 21 ̶ ̶ ̶ ̶ ̶ ̶ Ir RX Ir RX ̶ ̶ ̶ ̶ ̶ ̶ ̶ ̶ ̶ ̶ ̶ ̶ RS232 RS232 Simplified MFG • 550 W Baseline Road Ste 102-121 • Mesa, AZ 85210 • www.simplifiedmfg.com • 833-HDMI-411 (436-4411)
