Simplified MFG EX2ARC User Manual

Hdmi 2.0b (18gbps) 90m extender with arc, lan, ir, and rs232

Advertisement

Quick Links

EX2ARC
HDMI 2.0b (18Gbps) 90m Extender with
ARC, LAN, IR, and RS232
VER 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EX2ARC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Simplified MFG EX2ARC

  • Page 1 EX2ARC HDMI 2.0b (18Gbps) 90m Extender with ARC, LAN, IR, and RS232 VER 1.0...
  • Page 2: Table Of Contents

    Thank you for purchasing this device The Simplified MFG EX2ARC was designed to provide years of reliable service. At Simplified MFG we want your experience with this device to be the best possible and are committed to helping achieve that experience.
  • Page 3: Introduction

    24V power supply that can be used at either the RX or the TX. The EX2ARC is a perfect solution for instances when you need a LAN connection in an extender and has the added benefits of ARC, S/PDIF Audio return from the display, and Audio extraction depending on the setting of the function switch.
  • Page 4: Package Contents

    3. Package Contents Item 18Gbps HDMI over HDBaseT Extender (Transmitter) 18Gbps HDMI over HDBaseT Extender (Receiver) IR Blaster cable (1.5 meters) 20~60KHz IR Receiver cable (1.5 meters) Mounting Ears 3-pin Phoenix connector 24V/1A Locking Power adapter User Manual Machine screws- KM3*4mm 4.
  • Page 5 Connection Inputs: 1x HDMI Type A [19-pin female] Outputs: 1x HDBT OUT [RJ45, 8-pin female] 1x SPDIF OUT [S/PDIF] 1×L/R OUT [3.5mm Stereo Mini- jack] 1×LAN [RJ45] Transmitter Control: 1x IR IN [3.5mm Stereo Mini-jack] 1x IR OUT [3.5mm Stereo Mini-jack] 1x RS-232 [Phoenix jack] 1x SERVICE [Mini-USB, Update port] Inputs: 1x HDBT IN [RJ45, 8-pin female]...
  • Page 6: Operation Controls And Functions

    Resolution / 4K60 - 4K30 - 1080P60 - Cable Feet / Feet / Feet / Meters Length Meters Meters HDMI IN / OUT 16ft / 5M 32ft / 10M 50ft / 15M The use of “Premium High-Speed HDMI” cable is highly recommended. 5.
  • Page 7: Receiver Panel

    ▪ Illuminated: Transmitter and Receiver are in good Green Connection connection status. Signal Indicator ▪ Flashing: Transmitter and Receiver are in poor connection status. (on the left side of ▪ Dark: Transmitter and Receiver are not connected. port) HDBT OUT Amber Data ▪...
  • Page 8: Audio Output Function

    Green LED is on when SPDIF OUT port outputs the SPIDIF LED audio signal returned from SPDIF IN on receiver. Press the button to switch the output audio signal source FUNCTION for SPDIF OUT and L/R OUT port. SERVICE port Firmware update port.
  • Page 9: Ir Pin Definition

    5.4 IR Pin Definition IR Receiver and Blaster pin’s definition is as below: IR RECEIVER IR BLASTER IR BLASTER IR RECEIVER IR SIGNAL GROUNDING POWER 12V Note: IR remote sends signal at the distance of 0~5 meters / 0~8 meters with the angle of ±...
  • Page 10: Ir System Diagram

    5.5 IR System Diagram The following is IR system diagram about IR cable use method. TV remote Remote IR Receiver cable CAT 5e/6 cable Transmitter Receiver IR Blaster cable BRP or Streamer Note: When the angle between the IR receiver and the remote control is ± 45 °, the transmission distance is 0-5 meters;...
  • Page 11: Application Example

    6. Application Example RS232 from TX Connect to TV or Strreamer 9 / 10...
  • Page 12: Warranty And Contact Information

    A purchase receipt or other proof of purchase date is required for the limited warranty service. Sales and Tech Support P. 833-HDMI-411 (833-436-4411) info@simplifiedmfg.com Simplified MFG • 550 W Baseline Rd Ste 102-121 • Mesa AZ 85210 10 / 10...
  • Page 13 ̶ ̶ ̶ ̶ ̶ ̶ Ir RX Ir RX ̶ ̶ ̶ ̶ ̶ ̶ ̶ ̶ ̶ ̶ ̶ ̶ RS232 RS232 Simplified MFG • 550 W Baseline Road Ste 102-121 • Mesa, AZ 85210 • www.simplifiedmfg.com • 833-HDMI-411 (436-4411)
  • Page 14 1080P 3D@60Hz Color Space RGB, YCbCr 4:4:4, YCbCr 4:2:2 Color Depth 10-bit, 12-bit The EX2ARC is a HDMI over category HDMI Audio cable extender that supports ARC and LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby Formats TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X (Pass-through) outputs the display’s ARC audio at the...
  • Page 15 Known working terminated Category cable • means no HDCP, off means no signal at HDMI port(s) • SP12S splitter for clocking issues, etc. Simplified MFG • 550 W Baseline Road Ste 102-121 • Mesa, AZ 85210 • www.simplifiedmfg.com • 833-HDMI-411 (436-4411)
