    Thank you for purchasing the EXFBR The Simplified MFG EXFBR is designed to provide years of reliable service. At Simplified MFG, we want the experience with this device to be the best possible and are committed to helping achieve that experience.

  • Page 3: Introduction

    1. Introduction The EXFBR is a full featured fiber extender that can extend HDMI2.0b (18Gbps) 4K/Ultra HD signal over 33300 feet/10,000 meters over Single-mode fiber. The EXFBR supports HDMI2.0b 18Gbps 4K/2K @ 60Hz. YUV 4:4:4. 2. Features HDMI 2.0b (18Gbps), HDCP 2.2 and DVI 1.0 compliant •...

  • Page 4: Specifications

    4. Specifications Technical HDMI Compliance HDMI 2.0b HDCP Compliance HDCP 2.2 Video Bandwidth 18Gbps Video Resolutions Up to 4K2K@50/60Hz(YUV4:4:4),4K2K@30Hz,1080P@120Hz, and 1080P 3D@60Hz Color Space RGB, YCbCr 4:4:4/4:2:2, YUV 4:2:0 Color Depth 8-bit, 10-bit, 12-bit LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD HDMI Audio Formats Master Audio, Dolby Atmos, DTS:X Operation Range...

  • Page 5: Operation Controls And Functions

    IR OUT Outputs IR from IR IN on RX AUDIO Switch Selects Audio from 3.5mm input or from HDMI. Note: the EXFBR can be used as an audio only device without an HDMI connection This selects the EDID shown to the source...

  • Page 6: Receiver Panel

    IR OUT Outputs IR from IR IN on RX AUDIO Switch Selects Audio from 3.5mm input or from HDMI. Note: the EXFBR can be used as an audio only device without an HDMI connection This selects the EDID shown to the source...

  • Page 7: Optical Module Instructions

    5.4 Optical module instructions ❶ SFP-BL35T1-02DC is TX optical module. ❷ SFP-BL531T-02DC is RX optical module. 6. Connection Diagram 6 / 7...

  • Page 8: Warranty

    8. Contact Sales and Tech Support P. 833-HDMI-411 (833-436-4411) info@simplifiedmfg.com Simplified MFG • 550 W Baseline Rd Ste 102-121 • Mesa AZ 85210 © Simplified MFG 2022 7 / 7...
