- Page 1 INSTRUCTION MANUAL AIR91-IN-HP...
- Page 3 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
- Page 4 TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 30MIN. ASSEMBLY HARDWERE M3.5x30mm SCREW M3.5x40mm SCREW 7PCS+ +1 spare 10PCS+1 spare M3.5x25mm SCREW M3.0x16mm SCREW 2PCS ++ 1 spare 6PCS ++ 1 spare Plastic Feets M6.0x60mm BOLT 4PCS 8PCS+1 spare...
- Page 5 PARTS Front panel PVC Curtain Eave Right panel Back panel Left panel Supporting bars Bottom floor-1 Bottom floor-2 2PCS...
- Page 6 PARTS House insulated liner Platform layer Roof Roof insulated liner Waterproof bar Heater Notice: This part only used for two cat houses connection.
- Page 7 PRODUCT ASSEMBLY ① Screw the curtain Part A to the INSIDE of Part C by 2xP4. ② Screw Part B from the INSIDE of Part C by 2xP1. Pls line up the Part C Part D Part E Part F as shown on the picture by 8xP1.
- Page 8 PRODUCT ASSEMBLY Attach 4 pcs of plastic feets P5 to the house. Put in Part G Part H.
- Page 9 PRODUCT ASSEMBLY Screw the supporting bars 2xPart I by 4xP6. Screw the platform layer Part J by 4xP2.
- Page 10 PRODUCT ASSEMBLY Open the insulated bottom liner Part L and then put the heater Part O inside .
- Page 11 PRODUCT ASSEMBLY ① Put the insulated liner Part L in the house first. ② And then finally put in the bottom liner.
- Page 12 PRODUCT ASSEMBLY Screw the roof Part K by 6xP3. Stick the roof insulated liner Part M to the INSIDE roof. ① ② Connect the power supply.
- Page 13 Notice Read Before Assemble! Notice:The below steps are using for two cat houses AIR91 connection, pls ignore if you don’t have two cat houses AIR91. Push upward to take out the small door of right panel. ① Choose one cat house only, take out the platform layer of left panel, ②...
- Page 14 PRODUCT ASSEMBLY Take apart the lock on the front panel Part C. Take apart the roof hinge on the back panel Part D.
- Page 15 PRODUCT ASSEMBLY Close the roof, and keep roof aligned with both side panel, then screw the lock on the front panel.
- Page 16 PRODUCT ASSEMBLY Screw the roof hinge to the back. Connect two cat houses together by 2xP6 in front.
- Page 17 PRODUCT ASSEMBLY Connect two cat houses together by 2xP6 in back. Screw the waterproof bar Part N to connect two houses by 3xP2. Finish...
- Page 18 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or lo ss,whe ther direct ,indir ect,or incid ental ,resul ting f rom th e inc orrect attachment,improper use,inadequate miantenance,or neglect of this product.
