Summary of Contents for ACME RISSA LED-PAR200 WW IP
- Page 1 LED-PAR200 WW IP LED-PAR200 CW IP...
- Page 2 Menu 1. Safety Instructions ..........................1 2. Technical Specifications ........................3 3. Installation and Connection ......................4 4. How to set the unit ...........................4 4.1 Rear Panel ............................4 4.2 Main Function..........................6 5. How to control the unit ........................10 6. DMX512 configuration ......................... 11` 7.
- Page 3 1. Safety Instructions Please read the instruction carefully which includes important information about the installation, usage and maintenance. WARNING Please keep this User Manual for future consultation. If you sell the fixture to another user, be sure that they also receive this instruction booklet. ...
- Page 4 2. Technical Specifications 1/2/3 channel Mode; Dimmer, Strobe; Ideal for Professional stages, Concerts, clubs, discotheques, Mobile DJs, etc. Input Voltage: AC100V~240V，50/60Hz Total Power consumption: 245W Beam Angle: 9°/15°/20°/25°/30° IP Grade: IP X4 LED Sources: 200 W COB ...
- Page 5 Installation and Connection The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. Always ensure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.
- Page 6 MENU To select the programming functions DOWN To go forward in the selected functions To go backward in the selected functions ENTER To confirm the selected functions ○ Mains input/output:：Use Powercon true one mains connection. ○ DMX input/output: For DMX512 link, use 3/5-pin XLR plug cable to input DMX signal, and to link the next unit. The beam angle can be adjusted manually, which is 9°/15°/20°/25°/30°.
- Page 7 4.2 Main Function To select any functions, press MENU button until the required one is shown on the display. Select the function by ENTER button. Use DOWN and UP button to change the mode. Once the required mode has been selected, press ENTER button to setup or it will return to the main functions without any change after idling 8 seconds automatically.
- Page 8 Channel Mode , press the ENTER button. Use the DOWN and UP button to select the channel mode Select the (1CH/ 2CH/3CH). Once the address has been selected, press the ENTER button to setup or exit menu mode without any change after 8 seconds automatically. Back to the previous functions without any change press the MENU button.
- Page 9 DMX State Select the , press the ENTER button. Use the DOWN and UP button to select (Blackout) or (Hold the last state) . Once selected, press the ENTER button to setup or exit menu mode without any change after 8 seconds. Back to the functions without any change press the MENU button again.
- Page 10 Factory setting Select the , use the UP/DOWN button to select No or Yes (the fixture will reset to factory settings and exit menu mode). DMX START 0-512 MANUFAC TURER ACME DEVICE MODEL DESCRIPTION RISSA DMX PERSONALITY 1Channel 2Channel 3Channel...
- Page 11 5. How to control the unit 1. By DMX controller； No need to turn the unit off when you change the DMX address, as new DMX address setting will be affected at once. Turn on the unit, under the DMX signal , the LED will display the saved channel address （001-512）.
- Page 12 6. DMX512 configuration Channel Mode： 7. DMX512 Connection Mode connection：...
- Page 13 1. Connect the fixture together in a “daisy chain” by XLR plug cable from the output of the fixture to the input of the next fixture. The cable cannot be branched or split to a “Y” cable. Inadequate or damaged cables, soldered joints or corroded connectors can easily distort the signal and shut down the system 2.
- Page 14 1. DMX LED should be on. If not, check DMX connectors, cables to see if link properly. 2. If the DMX LED is on and no response to the channel, check the address settings and DMX polarity. 3. If you have intermittent DMX signal problems, check the pins on connectors or on PCB of the fixture or the previous one.
- Page 16 Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 2004/108/EC. EN55103-1: 2009 ; EN55103-2: 2009; EN61000-3-2: 2006 + A1:2009 + A2:2009; EN61000-3-3: 2008. &...
