Summary of Contents for ACME LED-635S
- Page 1 Intelligent Scanner Professional Lighting Technology User Guide Please read the instructions carefully before use...
- Page 2 INDEX 1. Safety Introduction 2. Technical Specification 3. How To Control The Unit 4. DMX512 Configuration 5. DMX512 Connection 6. Troubleshooting 7. Fixture Cleaning Широкий ассортимент оборудования ACME на www.maxlight.ru...
-
Page 3: Safety Introduction
1. Safety Introduction Please read the instructions carefully which include important information about the installation, operation and maintenance. WARNING Please keep this booklet with the unit for future consultation. If you sell the unit to another user, be sure that the new user also receives this instruction booklet thus giving them the necessary information about the use and general warnings regarding the unit. -
Page 4: Technical Specification
2. Technical Specification Voltage AC 100V-240V 50-60Hz Red: 16pcs, Green: 12pcs, Blue: 12pcs, white: 12pcs Dimension 385×170×122mm(LED-635S) 405×170×122mm(LED-635B) Weight 2.6KG(LED-635S) 3KG(LED-635B) The unit is a DMX512 scanner. It features full DMX512 control, 10 gobos/colors plus open and white, focus adjustable accurate optics system and stepper motor with blackout feature. -
Page 5: How To Control The Unit
3. How To Control The Unit (1) Master/Slave operation The unit can be linked together in daisy chain as many as you need in master/slave mode to perform the great built-in pre-programmed lighting shows triggered by music. In Master/Slave mode refer to the DMX settings below: Master unit: DMX start address MUST be set to 001. - Page 6 (3) Universal DMX controller When using a universal DMX controller to control the chain of units, you have to set DMX address by Dip switches from 1 to 9 to make sure all the units will receive its DMX signal. Please refer to the following diagram to know how to address your DMX 512 system in the binary code.
-
Page 7: Dmx512 Configuration
4. DMX512 Configuration... -
Page 8: Dmx512 Connection
5. DMX512 Connection The DMX512 is widely used in intelligent lighting control, with a maximum of 512 channels. A DMX512 system requires a controller, lighting equipment and cable. These are connected together in a “daisy chain” with the terminator at the end. The cable cannot be branched or split to a “Y”... -
Page 9: Troubleshooting
6. Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connect power and main fuse. 2. -
Page 10: Fixture Cleaning
7. Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surroundings can cause greater accumulation of dirt on the unit’s optics. Clean with a soft cloth using normal glass cleaning products.
