Installation and Operating Instructions
Issue 1
Description
: Robinhood Wall Canopy DC Motor with Gesture Control
Model Number : RHWC60TBWDC (60cm), RHWC90TBWDC(90cm)
Model Pictured: RHWC60TBWDC
Model Pictured: RHWC90TBWDC
*Actual unit may vary from above model pictured
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ROBINHOOD RHWC60TBWDC
Summary of Contents for ROBINHOOD RHWC60TBWDC
- Page 1 Installation and Operating Instructions Issue 1 Description : Robinhood Wall Canopy DC Motor with Gesture Control Model Number : RHWC60TBWDC (60cm), RHWC90TBWDC(90cm) Model Pictured: RHWC60TBWDC Model Pictured: RHWC90TBWDC *Actual unit may vary from above model pictured...
- Page 2 It is important that you retain these instructions and your proof of purchase along with any other important documents about this product for future reference. Due to continual product development, Robinhood reserves the right to alter specifications or appearances without notice. Important Safety Instructions..........................1 Appliance Details ..............................
- Page 3 Important Safety Instructions IMPORTANT: Read the assembly instruction section and safety precautions of this booklet carefully before removing the contents of this carton. 1. All electrical work must be done by a registered electrician in accordance with local and national electrical codes as applicable.
- Page 4 Appliance Details Voltage & Frequency 220 ‐ 240Vac 50Hz Model RHWC60TBWDC RHWC60TBWDC Lamp Max 2 x 2W LED lights Rated Input Power 274 W Supply connection 10A plug Contents of packaging: Typical equipment required: • 1 x Rangehood unit • Electric drill •...
- Page 5 • Robinhood strongly recommends semi‐ rigid ducting pipe to be used for optimised performance. • Please contact Robinhood for further information about Uniduct® professional rangehood ducting solutions. Fig.1 Before Connecting to Power Supply •...
- Page 6 Installation Instructions Warning: Do not connect the rangehood ventilation to the same conductor used for circulating hot air or evacuating fumes from other power sources operated appliances. Wall Mounting Preparations • Carefully design and cut the venting hole in a desired area on the wall according to the most suitable ducting solution.
- Page 7 Installation Instructions 3. Install 2 screws for the flue supporting 4. Insert the screws into the black brackets, see Fig.5. mounting lugs and hand tight them only. Do not firmly tighten the screws yet, see Fig.6. Fig.5 5. Place the hanging plate on the top of rangehood unit and fix it with 4 screws that are firmly tightened, see Fig.7.
- Page 8 Ensure screws A & B are fully flue pieces down to the rangehood top, see tightened, see Fig.11. Fig.10.(Note: Ducting pipe needs to be purchased separately. Please contact Robinhood or installation experts for more details.) Fig.11 Fig.10 For safety reason, please use only the same size of fixing or mounting screws which ...
- Page 9 Operation Instructions Control Panel Icon Icon Icon Key Indicator Display Name/Type Definition Working with H Through the A‐H induction Infrared zone, the area, the rangehood starts the Sensor rangehoo fan, lights and adjusts the gear d starts or When the button is touched, it Power The hood lit up and the rangehood...
- Page 10 Operation Instructions Icon Icon Icon Key Indicator Display Name/Type Definition Gear Sliding The key is touched by sliding, adjustment/ control and the gear is 01‐10 (10 Touch key quantizati gears). (Press) on values When the key is touched, it lit Controls up, and the fan starts;...
- Page 11 Operation Instructions Functions & Operations • In standby mode, press F key, the motor starts from first gear (fan speed 1), and D display shows the first bar on the left. At this time, the fan speed can be changed by sliding touch E and reflected on D display;...
- Page 12 Cleaning & Maintenances Any electrical repairs to this appliance must conform to your local, state and federal laws. Please contact the service center if in any doubt before undertaking any of the above General Cleaning • Regularly clean the filters, fan and other surfaces of the rangehood by using a damp cloth with mild household cleaning detergent.
- Page 13 Fig.13. • Replace a new lamp and snap fit back to the original position. • Always use the genuine light from Robinhood. • It is recommended to conduct the light replacement by authorized personnel. Fig.13...
- Page 14 The following conditions apply in respect of the warranty given in this certificate: 1. Monaco Corporation Limited (“Monaco”) warrants the following Robinhood products against manufacturing defects and faulty materials, under normal use and subject to the exclusions in this certificate, for a period of: Rangehood, Ovens, Cooktops, Dishwashers - 24 months from date of original purchase for domestic use.
