ROBINHOOD WALL CANOPY RANGEHOODS
Model Numbers:
RHWC60X,RHWC90X, RHWC60TB,RHWC90TB, RHWC60TG, RHWC90TG
RHWC60X Brimstone 60
RHWC60TB Argus 60
RHWC60TG Adonis 60
1
RHWC90X Brimstone 90
RHWC90TB Argus 90
RHWC90TG Adonis 90
Models may vary slightly from images pictured
Issue: 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Brimstone 60 and is the answer not in the manual?

Questions and answers

Summary of Contents for ROBINHOOD Brimstone 60

  • Page 1 Issue: 2 Description: ROBINHOOD WALL CANOPY RANGEHOODS Model Numbers: RHWC60X,RHWC90X, RHWC60TB,RHWC90TB, RHWC60TG, RHWC90TG RHWC90X Brimstone 90 RHWC60X Brimstone 60 RHWC90TB Argus 90 RHWC60TB Argus 60 RHWC60TG Adonis 60 RHWC90TG Adonis 90 Models may vary slightly from images pictured...
  • Page 2: Product Dimensions

    Product Dimensions RHWC90TB RHWC60TB Argus 90/60 RHWC90X RHWC60X Brimstone 90/60 RHWC90TG Adonis 90 RHWC60TG Adonis 60...
  • Page 3: Important Safety Information

    Product approvals and ratings Appliance: RHWC60X: 184W 220-240V ~50Hz LED: 2x2W RHWC90X: 184W 220-240V ~50Hz LED: 2x2W Product rating RHWC60TB: 184W 220-240V ~50Hz LED: 2x2W RHWC90TB: 184W 220-240V ~50Hz LED: 2x2W RHWC90TG: 184W 220-240V ~50Hz LED: 2x2W RHWC60TG: 184W 220-240V ~50Hz LED: 2x2W Important safety information All electrical work must be done by a registered electrician in accordance with local and national electrical codes as applicable.
  • Page 4: Pre-Installation

    Pre-installation Thank you for purchasing a quality Robinhood rangehood. Robinhood has a high standard of quality control and every range hood is tested and approved before it leaves the factory. Important: Please read the entire instructions before installing the rangehood. Check appliance for damage or missing parts (if damaged, do not install).
  • Page 5: Ducting Options

    Please note that this chart is designed as a guide. Please consult Robinhood customer services if unsure. For NZ phone (09) 415 6000 or www.robinhood.co.nz. For AUS phone 1800 648 556 or www.robinhood.com.au.
  • Page 6: Installation Instructions

    Fit the ducting to the outlet and secure in place with the supplied 4mm screws. *Flexible or semi-rigid ducting pipe can be used, however, Robinhood strongly recommend the use of semi-rigid ducting wherever is possible. We offer a full range of semi-rigid ducting solutions under the Uniduct brand, for more information please visit www.robinhood.co.nz...
  • Page 7 Installation...
  • Page 8: Fan Speed

    Operating instructions Controls RHWC60TB, RHWC90TB, RHWC60TG & RHWC90TG The control panel is made up of black glass. Each function is represented by an icon, which when pressed will activate the function. Each time it is pressed a “beep” will be heard. Power Once the appliance is connected to the power source, the icons will all light up for 1 second and turn off, leaving the appliance in stand-by mode.
  • Page 9 Operating instructions Controls RHWC60X, RHWC90X The control panel is made up of stainless steel with 5 buttons. Each function is represented by an icon on the button, which when pressed will light up. Each time a button is pressed a “beep” will be heard. Power Once the appliance is connected to the power source, the buttons will all light up for 1 second and turn off, leaving the appliance in stand-by mode.
  • Page 10: Filter Maintenance

    Cleaning and maintenance General Maintenance Switch off the rangehood before cleaning or maintenance. To prevent surface damage never use abrasive or oil based liquid cleaners. To clean the surfaces of the appliance, use mild detergent and warm water. In areas of high humidity and coastal environments cleaning should be carried out frequently.
  • Page 11: Cleaning And Maintenance

    Cleaning and maintenance Fault Cause Solution The LED damaged Lights do not work, but fan LED wiring connection poor Contact Service Department works LED switch damage Motor bearings damage Motor burn out Contact Service Department Lights work, but fan does not work Motor control switch damage Plug contact outlet bad...
  • Page 12 The following conditions apply in respect of the warranty given in this certificate: 1. Monaco Corporation Limited (“Monaco”) warrants the following Robinhood products against manufacturing defects and faulty materials, under normal use and subject to the exclusions in this certificate, for a period of: Rangehood, Ovens, Cooktops, Dishwashers - 24 months from date of original purchase for domestic use.
  • Page 13 The product was used outdoors. 2. All Robinhood Rangehoods are suitable for indoor use only and not suitable over BBQs or charcoal cookers designed for outdoor use. 3. In addition, this warranty does not extend to damage or defects which in our opinion, directly or indirectly arise from or are due to: exposing the product to acidic or corrosive materials or chemicals such as dyes, solvents, denture cleaner or acetone;...
