Installation and Operating Instructions
Description:
Robinhood Curved Glass Canopy Rangehood
Model Number: RWK3CL6G (60cm); RWK3CL9G (90cm)
Model Pictured: RWK3CL6G
Model Pictured: RWK3CL9G
Actual unit may vary from image shown
Issue 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the RWK3CL6G and is the answer not in the manual?

Questions and answers

Summary of Contents for ROBINHOOD RWK3CL6G

  • Page 1 Installation and Operating Instructions Issue 1 Description: Robinhood Curved Glass Canopy Rangehood Model Number: RWK3CL6G (60cm); RWK3CL9G (90cm) Model Pictured: RWK3CL6G Model Pictured: RWK3CL9G Actual unit may vary from image shown...
  • Page 2: Table Of Contents

    Contents Congratulations! Thank you for choosing one of our appliances. Before you use the appliance, we strongly recommend that you read through the whole user manual which provides important safety instructions and description of the product and the proper use of its functions. To avoid the ever‐present risks involved with using an electrical appliance it is vital that the oven is installed correctly and that you read the safety instructions carefully to avoid misuse and hazards.
  • Page 3: Important Safety Instructions

    Important Safety Instructions IMPORTANT: Read the assembly instruction section and safety precautions of this booklet carefully before removing the contents of this carton. In certain circumstances electrical appliances may be a safety hazard. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience or knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety.
  • Page 4: Appliance Details

    220-240V 50Hz Lamp Max: 2 x 1.5W LED Rated Input Power: 103W RWK3CL6G RWK3CL9G General Information Before installing and operating the rangehood, carefully read the following important information regarding installation safety and maintenance. Keep this information booklet accessible for further consultations.
  • Page 5: Installation Instructions

    Installation Instructions Preparation Ensure the rangehood is not connected to the power supply until installation is complete. If you have an outlet leading outside, you can connect your rangehood, according to the image below, by means of an extraction duct (enamel, aluminum, flexible pipe or inflammable material) with an interior diameter of 150mm. The rangehood must be placed at least 60cm above the cooking surface.
  • Page 6 Installation Instructions Exhaust Fix the one-way valve to the air outlet of the rangehood, and then attach the exhaust pipe (needs to be purchased separately) to the one-way valve. Chimney Installation • Put the upper chimney into lower chimney. Then pulling the upper chimney upwards. Adjust to reach the required height.
  • Page 7 Installation Instructions Re-circulation If you do not have a vent leading outside, the rangehood can be installed in recirculation mode. Activated carbon filters (need to be purchased separately) will be used to filter the air and recirculate it back into the room. Installation is similar to the installation method for exhaust above, but without the duct.
  • Page 8: Operating Instructions

    Operating Instructions Controls On / Off Push to turn the fan on / off. Low Speed Push to set the fan to low speed. Medium Speed Push to set the fan to medium speed. High Speed Push to set the fan to high speed. Light Push to turn the light on / off.
  • Page 9: Troubleshooting

    Troubleshooting Fault Possible Cause Solution Fan switch turned off Select a fan switch position. Light on, but motor Fan switch failed Contact service center. does not work Motor failed Contact service center. House fuses blown Reset/Replace fuses. Light does not work; Refit mains power cable to power Mains power cable is loose or motor does not work...
  • Page 10: Cleaning And Maintenance

    Cleaning and Maintenance Caution: • Before maintenance or cleaning is carried out, the cooker hood should be disconnected from the mains power supply. Ensure that the cooker hood is switched off at the wall socket and the plug removed. • External surfaces are susceptible to scratches and abrasions, so follow the cleaning instructions to ensure the best possible result is achieved without damage.
  • Page 11 Cleaning and Maintenance Note: Before cleaning, disconnect the rangehood from the power supply. Regular Cleaning Use a soft cloth dampened with lukewarm, mildly soapy water to wipe the surface clean. Never use metal pads, chemicals, abrasive materials, or stiff brushes to clean the rangehood. Monthly Cleaning –...
  • Page 12: Warranty Certificate (New Zealand)
