Figure 7: wired connection terminal block
i
Information on the connection as a floor door
station can be found in the operating instruc-
tions of the line power supply.
„ Attach connection terminal block to video insert.
Circuit symbols and elements of the circuit
diagrams
Line power supply RMD
Power transformer
Door release
Video door station
Wrapped wire pair for 2D video devices
(recommendation: white/yellow wire pair)
Unwrapped wire pair, for e.g. for door release
Figure 8: Door release connection on the door
station
Figure 9: Connection of door station video with
manipulation-protected door release
3 Elcom Kommunikation GmbH - Gottfried-Leibniz-Str.1 - D-74172 Neckarsulm - www.elcom.de -
Individual call push-
button address/function
Automatic call push-
button addressing
(13)
Door speaker
volume
Microphone
sensitivity
Operating sig-
nal sound volume
Door release
unlocking time
Door release
function
set
door address
Camera present
Call push-button
Backlighting settings
(switch-on brightness
level)
Display error codes
(max. 5 can be saved)
Reset error codes
factory setting
1)
Door release functions without door call only possible single door systems
Calling up and changing of system settings
On the back of the video insert, there are 3 operat-
ing buttons and a 2-digit 7-segment display (Figure
2, 8 - 11).
„ Press /
Device turns to setting mode. The first menu
entry is displayed.
i The reading directions of the 7-segment display
varies by 180° depending on which button
you start with.
„ Select the desired menu entry with
(figure 10).
„ Confirm the selection with
i The 7 segments display goes dark if there is no
actuation for 5 seconds. Settings are applied.
The device returns to normal operation.
Confirm the call push-
button to be set
= Cancel
= Start addressing
...
Default setting
...
Default setting
...
= Acoustic signal off
Default setting
... Seconds
Default setting seconds
= only with door call
= also without door call
Default setting
x ... x
x = received line
address
Default setting
= No camera
= with camera
Default setting: Audio
Video
...
= Off
= lowest value
= highest value
= always on
Default setting
... Error codes
= module communication
= sticking call button
= module address
= no error present
= Cancel
= Reset
= Cancel
= Reset
Figure 10: Overview of system settings
button.
/
.
... = Call push-button address
= Light push-button
= Door release push-button
= no function
Addressing executed/cancel-
led, is displayed
Volume set,
is displayed
Sensitivity set.
is displayed
Volume set,
is displayed
Unlocking time set,
is displayed
Door release function is set,
1)
is displayed
Door address set,
is displayed
Camera option set,
is displayed
Backlighting set,
is displayed
Error codes were displayed,
is displayed
Error codes were deleted,
is deleted
Reset to the factory setting, in-
dication goes out
Setting the values
The menu entry to be set is confirmed and flashes
alternately with the value to be set.
„ Press / button.
Short button-press: change the value by one
step.
Long button-press: run through values. Scroll-
ing stops when the button is released.
/
„ Confirm set value with
The device applies the setting and returns to
the previous menu entry.
Address/Function
saved,
is displayed
.
