KROHNE OPTISWITCH 5300 C Handbook

KROHNE OPTISWITCH 5300 C Handbook

Vibrating level switch
Hide thumbs Also See for OPTISWITCH 5300 C:
Table of Contents

Advertisement

Quick Links

Download this manual
OPTISWITCH 5300 C
Handbook
Vibrating Level Switch
Transistor (NPN/PNP)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OPTISWITCH 5300 C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KROHNE OPTISWITCH 5300 C

Summary of Contents for KROHNE OPTISWITCH 5300 C

  • Page 1 OPTISWITCH 5300 C Handbook Vibrating Level Switch Transistor (NPN/PNP)

  • Page 2: Table Of Contents

    How to proceed if a repair is necessary ................29 Dismount..........................30 Dismounting steps......................30 Disposal ......................... 30 Supplement ..........................31 Technical data ........................ 31 Dimensions ........................37 Trademark ........................40 Editing status: 2023-08-24 OPTISWITCH 5300 C • Transistor (NPN/PNP)

  • Page 3: About This Document

    List The dot set in front indicates a list with no implied sequence. Sequence of actions Numbers set in front indicate successive steps in a procedure. Disposal This symbol indicates special instructions for disposal. OPTISWITCH 5300 C • Transistor (NPN/PNP)

  • Page 4: For Your Safety

    During work on and with the device, the required personal protective equipment must always be worn. Appropriate use The OPTISWITCH 5300 C is a sensor for point level detection. You can find detailed information about the area of application in chapter " Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions.

  • Page 5: Namur Recommendations

    Safety instructions for Ex areas For applications in explosion-proof areas (Ex), only devices with cor- responding Ex approval may be used. Observe the Ex-specific safety instructions. These are an integral part of the operating instructions and are enclosed with every device with Ex approval. OPTISWITCH 5300 C • Transistor (NPN/PNP)

  • Page 6: Product Description

    – If necessary, further certificates Information: Optional instrument features are also described in this operating instructions manual. The respective scope of delivery results from the order specification. The OPTISWITCH 5300 C consists of the components: Constituent parts • Housing lid • Housing with electronics •...
  • Page 7 3 Product description Fig. 1: OPTISWITCH 5300 C , compact version with plastic housing Housing lid Housing with electronics Temperature adapter 4 Process fitting OPTISWITCH 5300 C • Transistor (NPN/PNP)
  • Page 8 3 Product description Fig. 2: OPTISWITCH 5300 C with plastic housing and tube extension Housing lid Housing with electronics Temperature adapter 4 Process fitting Tube extension Type label The type label contains the most important data for identification and use of the instrument: • Instrument type • Information about approvals •...

  • Page 9: Principle Of Operation

    Principle of operation Application area OPTISWITCH 5300 C is a point level sensor with tuning fork for point level detection. It is designed for industrial use in all areas of process technology and can be used in liquids. It is particularly suitable for applications with high temperatures up to 450 °C (842 °F) and high process pressure...

  • Page 10: Packaging, Transport And Storage

    For connecting the sensors with a separator to voltage supply or sig- nal processing, the sensors are also available with plug connectors. The following plug connectors are available: • M12 x 1 • ISO 4400 • Harting HAN 7D OPTISWITCH 5300 C • Transistor (NPN/PNP)
  • Page 11 3 Product description • Harting HAN 8D • Amphenol-Tuchel OPTISWITCH 5300 C • Transistor (NPN/PNP)

  • Page 12: Mounting

    Switching point In general, OPTISWITCH 5300 C can be installed in any position. The instrument only has to be mounted in such a way that the tuning fork is at the height of the desired switching point.
  • Page 13 Switching point approx. 33 mm (1.3 in) Fig. 4: Horizontal mounting Switching point 2 Marking on top with threaded versions, marking aligned to flange holes with flange versions Fig. 5: Horizontal installation (recommended mounting position, particularly for adhesive products) Switching point Marking with screwed version, facing up In the case of flange versions, the fork is aligned as follows. OPTISWITCH 5300 C • Transistor (NPN/PNP)
  • Page 14 To maintain the housing protection, make sure that the housing lid is closed during operation and locked, if necessary. Caution: Transport Do not hold OPTISWITCH 5300 C on the tuning fork. Particularly with flange or tube versions, the tuning fork can be damaged just by the weight of the instrument. Transport coated instruments very carefully and avoid touching the tuning fork.

  • Page 15: Mounting Instructions

    (1.16 in). To mount the sensor, proceed as follows: 1. Screw the OPTISWITCH 5300 C into the mounting boss up to the stop. You can determine the later position already before welding. 2. Mark the position of the OPTISWITCH 5300 C on the mounting boss.
  • Page 16 Fig. 7: Mounting the instrument on insulated vessels. Temperature isolation - max. 50 mm (1.97 in) Ambient temperature on the housing Inflowing medium If OPTISWITCH 5300 C is mounted in the filling stream, unwanted false measurement signals can be generated. For this reason, mount OPTISWITCH 5300 C • Transistor (NPN/PNP)
  • Page 17 4 Mounting OPTISWITCH 5300 C at a position in the vessel where no distur- bances, e.g. from filling openings, agitators, etc., can occur. This applies particularly to instrument types with long extension tube. Fig. 8: Inflowing medium Product flow To make sure the tuning fork of OPTISWITCH 5300 C generates as little resistance as possible to product flow, mount the sensor so that the surfaces are parallel to the product movement.
  • Page 18 See " Technical data". Caution: If it is determined (e.g. via a fault signal from OPTISWITCH 5300 C ) that medium has already penetrated into the vibrating element, the instrument must be exchanged immediately.

  • Page 19: Connecting To Power Supply

    EN 61326 for industrial areas, shielded cable should be used. Make sure that the cable used has the required temperature resist- ance and fire safety for max. occurring ambient temperature Use cable with round cross section for instruments with housing and cable gland. To ensure the seal effect of the cable gland (IP protection OPTISWITCH 5300 C • Transistor (NPN/PNP)

  • Page 20: Connection Procedure

    10. Screw the housing lid back on The electrical connection is finished. Wiring plan, single chamber housing The following illustrations apply to the non-Ex as well as to the Ex d version. OPTISWITCH 5300 C • Transistor (NPN/PNP)
  • Page 21 Control lamp - fault indication (red) Control lamp - Switching status (yellow) Control lamp - Operating status (green) Mode switch for selecting the switching behaviour (min./max.) DIL switch for sensitivity adjustment Ground terminal Connection terminals OPTISWITCH 5300 C • Transistor (NPN/PNP)
  • Page 22 5 Connecting to power supply Wiring plan - Transistor We recommend connecting OPTISWITCH 5300 C according to the output closed-circuit principle, i.e. the switching circuit is open when there is a level signal, line break or fault (safe state). The instrument is used to control relays, contactors, magnet valves, warning lights, horns as well as PLC inputs.

  • Page 23: Setup

    DIL switch for adjustment of the density range (5) Note: Always immerse the tuning fork of OPTISWITCH 5300 C in a liquid to test its function. Do not test the function of OPTISWITCH 5300 C with your hand. This can damage the sensor.

  • Page 24: Adjustment Elements

    Green LED lights = operating voltage on ing condition (green) Mode setting (4) With the mode switch (max./min.) you can change the switching sta- tus. You can set the required mode according to the " Function table" OPTISWITCH 5300 C • Transistor (NPN/PNP)

  • Page 25: Function Table

    - red Voltage supply Switching sta- Fault message Mode max. closed Overflow pro- tection Mode max. open Overflow pro- tection Mode min. closed Dry run protec- tion Mode min. open Dry run protec- tion OPTISWITCH 5300 C • Transistor (NPN/PNP)
  • Page 26 6 Setup Level Switching sta- Signal lamp - Signal lamp - Signal lamp green yellow - red Voltage supply Switching sta- Fault message Failure of the open supply voltage Mode max./min. Fault open OPTISWITCH 5300 C • Transistor (NPN/PNP)

  • Page 27: Maintenance And Fault Rectification

    The operator of the system is responsible for taking suitable meas- tion occurs ures to rectify faults. Causes of malfunction The device offers maximum reliability. Nevertheless, faults can occur during operation. These may be caused by the following, e.g.: • Sensor • Process • Voltage supply • Signal processing The first measure to take is to check the output signal. In many cases, Fault rectification the causes can be determined this way and the faults quickly rectified. OPTISWITCH 5300 C • Transistor (NPN/PNP)

  • Page 28: Exchanging The Electronics

    In general, all electronics modules of the respective type series can be interchanged. The type name is stated on the electronics module. If you want to use an electronics module with a different signal output, you have to carry out the complete setup. You can find the required operating instructions manual on our homepage. OPTISWITCH 5300 C • Transistor (NPN/PNP)

  • Page 29: How To Proceed If A Repair Is Necessary

    7 Maintenance and fault rectification How to proceed if a repair is necessary If a repair should be necessary, please contact your contact person. OPTISWITCH 5300 C • Transistor (NPN/PNP)

  • Page 30: Dismount

    If personal data is stored on the old device to be disposed of, delete it before disposal. If you have no way to dispose of the old instrument properly, please contact us concerning return and disposal. OPTISWITCH 5300 C • Transistor (NPN/PNP)

  • Page 31: Supplement

    The Second Line of Defense is required for various ap- provals. Ʋ Supporting material 316L Ʋ Material Ceramic Al (99.5 %) OPTISWITCH 5300 C • Transistor (NPN/PNP)
  • Page 32 < 2 V Switching voltage < 55 V DC Blocking current < 10 µA Modes (switchable) Ʋ Max. Max. detection or overflow/overfill protection Ʋ Min. Min. detection or dry run protection Depending on the mounting boss of the vessel. OPTISWITCH 5300 C • Transistor (NPN/PNP)
  • Page 33 (0,029) (0,036) (0,043) (0,051) (0,058) (0,065) (0,072) (0,079) (0,087) (0,022) Fig. 14: Influence of the product density on the switching point Shifting of the switching point in mm (in) Product density in g/cm³ (lb/in³) Switch position ≥ 0.47 g/cm³ (0.017 lb/in³) Switch position ≥ 0.7 g/cm³ (0.025 lb/in³) Switching point at reference conditions (notch) Tuning fork OPTISWITCH 5300 C • Transistor (NPN/PNP)
  • Page 34 -1 … 100 bar/-100 … 10000 kPa (-14.5 … 1450 psig) (1450 psig) The process pressure is dependent on the process fit- ting, e.g. flange (see the following diagrams) Ʋ Instrument version up to 160 bar -1 … 160 bar/-100 … 16000 kPa (-14.5 … 2320 psig) (2320 psig) The process pressure is dependent on the process fit- ting, e.g. flange (see the following diagrams) OPTISWITCH 5300 C • Transistor (NPN/PNP)
  • Page 35 Fig. 17: Process temperature - Process pressure - Version up to 160 bar (2321 psig) Process pressure in bar (psig) Process temperature in °C (°F) Process temperature (thread or flange temperature) Ʋ OPTISWITCH 5300 C of 316L/Al- -196 … +450 °C (-321 … +842 °F) loy C22 (2.4602)/Inconel 718 (2.4668) 70 °C (158 °F) 50 °C...
  • Page 36 Min. detection or dry run protection Sensitivity switch Ʋ ≥ 0.47 g/cm³ 0.47 … 2.5 g/cm³ (0.017 … 0.09 lbs/in³) Ʋ ≥ 0.7 g/cm³ 0.7 … 2.5 g/cm³ (0.025 … 0.09 lbs/in³) Voltage supply Operating voltage 9.6 … 55 V DC Max. power consumption 2 W (without load) Max. permissible process pressure: 25 bar (363 psig) OPTISWITCH 5300 C • Transistor (NPN/PNP)

  • Page 37: Dimensions

    ½ NPT M20x1,5/ ½ NPT Fig. 19: Housing versions in protection IP66/IP67 and IP66/IP68 (0.2 bar) Plastic single chamber Stainless steel single chamber (electropolished) Stainless steel single chamber (precision casting) Aluminium - single chamber OPTISWITCH 5300 C • Transistor (NPN/PNP)
  • Page 38 OPTISWITCH 5300 C , compact version ø 33,7 mm (1.33") DN50 PN40 G 1, 1 NPT ø 28,5 mm ø 28,5 mm (1.12") (1.12") Fig. 20: OPTISWITCH 5300 C , compact version Sealing surface OPTISWITCH 5300 C • Transistor (NPN/PNP)
  • Page 39 DN50 PN40 G 1, 1 NPT ø 21,3 mm (0.84") ø 28,5 mm ø 28,5 mm (1.12") (1.12") Fig. 21: OPTISWITCH 5300 C , tube version Sensor length, see chapter " Technical data" Sealing surface OPTISWITCH 5300 C • Transistor (NPN/PNP)

  • Page 40: Trademark

    9 Supplement Trademark All the brands as well as trade and company names used are property of their lawful proprietor/ originator. OPTISWITCH 5300 C • Transistor (NPN/PNP)
  • Page 41 Notes OPTISWITCH 5300 C • Transistor (NPN/PNP)
  • Page 42 Notes OPTISWITCH 5300 C • Transistor (NPN/PNP)
  • Page 43 Notes OPTISWITCH 5300 C • Transistor (NPN/PNP)
  • Page 44 • training services Head Office KROHNE Messtechnick GmbH Ludwig-Krohne-Straße 5 47058 Duisburg (Germany) Tel.: +49 (0) 203 301 0 Tel.: +49 (0) 203 301 10389 info@krohne.de The current list of all KROHNE contacts and addresses can be found at: www.krohne.com...
