  • Page 1 OPTISWITCH 5200 C, 5250 C Handbook Vibrating Level Switch Two-wire 8/16 mA...

  • Page 2: Table Of Contents

    How to proceed if a repair is necessary ................30 Dismount..........................31 Dismounting steps......................31 Disposal ......................... 31 Supplement ..........................32 Technical data ........................ 32 Dimensions ........................39 Trademark ........................42 OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...
  • Page 3 Contents Editing status: 2019-11-21 OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...

  • Page 4: About This Document

    The dot set in front indicates a list with no implied sequence. Sequence of actions Numbers set in front indicate successive steps in a procedure. Battery disposal This symbol indicates special information about the disposal of bat- teries and accumulators. OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...

  • Page 5: For Your Safety

    During work on and with the device, the required personal protective equipment must always be worn. Appropriate use The OPTISWITCH 5200 C, 5250 C is a sensor for point level detec- tion. You can find detailed information about the area of application in chapter "Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions.

  • Page 6: Safety Label On The Instrument

    Safety instructions for Ex areas For Ex applications, only devices with corresponding Ex approval may be used. Observe the Ex-specific safety instructions. These are an integral part of the operating instructions and are enclosed with every device with Ex approval. OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...

  • Page 7: Product Description

    Documentation – This operating instructions manual – Safety Manual "Functional safety (SIL)" (optional) – Ex-specific "Safety instructions" (with Ex versions) – If necessary, further certificates The OPTISWITCH 5200 C, 5250 C consists of the components: Constituent parts • Housing lid • Housing with electronics •...

  • Page 8: Principle Of Operation

    3 Product description Principle of operation Application area OPTISWITCH 5200 C, 5250 C is a point level sensor with tuning fork for point level detection. It is designed for industrial use in all areas of process technology and can be used in liquids.

  • Page 9: Storage And Transport

    For connecting the sensors with a separator to voltage supply or sig- nal processing, the sensors are also available with plug connectors. The following plug connectors are available: • M12 x 1 OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...
  • Page 10 3 Product description • ISO 4400 • Harting HAN 7D • Harting HAN 8D • Amphenol-Tuchel OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...

  • Page 11: Mounting

    DIN/EN/IEC/ANSI/ISA/UL/CSA 61010-1. Switching point In general, OPTISWITCH 5200 C, 5250 C can be installed in any position. The instrument only has to be mounted in such a way that the tuning fork is at the height of the desired switching point.
  • Page 12 Fig. 3: Horizontal mounting Switching point Marking with screwed version, facing up Fig. 4: Horizontal installation (recommended mounting position, particularly for adhesive products) Switching point Marking with screwed version, facing up In the case of flange versions, the fork is aligned as follows. OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...
  • Page 13 "Technical data" meets the existing ambient conditions. Fig. 6: Measures against moisture ingress Caution: Transport Do not hold OPTISWITCH 5200 C, 5250 C on the tuning fork. Particu- larly with flange or tube versions, the tuning fork can be damaged just by the weight of the instrument. Transport coated instruments very carefully and avoid touching the tuning fork.

  • Page 14: Mounting Instructions

    This means that every OPTISWITCH 5200 C, 5250 C is in the same fork position after being screwed in. Remove therefore the supplied seal from the thread of OPTISWITCH 5200 C, 5250 C. This seal is not required when using a welded socket with O-ring in front.
  • Page 15 Inflowing medium If OPTISWITCH 5200 C, 5250 C is mounted in the filling stream, un- wanted false measurement signals can be generated. For this reason, mount OPTISWITCH 5200 C, 5250 C at a position in the vessel where no disturbances, e.g. from filling openings, agitators, etc., can occur. This applies particularly to instrument types with long extension tube. Fig. 8: Inflowing medium Product flow...
  • Page 16 For this reason, do not use an overly long extension tube for OPTISWITCH 5200 C, 5250 C, but check if you can mount a level switch on the side of the vessel in horizontal position.

  • Page 17: Connecting To Power Supply

    Cover all housing openings conforming to standard according to EN 60079-1. Connection procedure With Ex instruments, the housing cover may only be opened if there is no explosive atmosphere present. Proceed as follows: 1. Unscrew the housing lid OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...

  • Page 18: Wiring Plan, Single Chamber Housing

    Fig. 10: Material versions, single chamber housing Plastic (not with Ex d) Aluminium Stainless steel, precision casting Stainless steel, electropolished (not with Ex d) Filter element for pressure compensation (not with Ex d) OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...
  • Page 19 Take note of the operating instructions manual of the controller. Suit- able controllers are listed in chapter "Technical data". If OPTISWITCH 5200 C, 5250 C is used in Ex areas as part of an overfill protection system according to WHG (Water Resources Act), take note of the regulations in the safety instructions and conformity certificates. If the instrument with electronics module SWE60Z EX,...
  • Page 20 5 Connecting to power supply Fig. 12: Wiring plan, single chamber housing OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...

  • Page 21: Setup

    The switching delay can also be modified on the controller. Note: Always immerse the tuning fork of OPTISWITCH 5200 C, 5250 C in a liquid to test its function. Do not test the function of OPTISWITCH 5200 C, 5250 C with your hand. This can damage the sensor.

  • Page 22: Function Table

    < 21 mA protection Mode B approx. > 12.5 mA 16 mA Dry run < 21 mA protection Mode B approx. > 3.8 mA 8 mA Dry run < 11.5 mA protection Green OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...

  • Page 23: Proof Test (Whg, Sil)

    WHG. The implementation of the proof test according to WHG is stipulated in the general type approval, item 8. Take note of these higher-ranking approvals if OPTISWITCH 5200 C, 5250 C Ex is used as part of an overfill protection system according to WHG. The following instrument combinations meet the requirements ac-...
  • Page 24 Procedure 1. Carry out the function test according to the above description (1 Short interruption of the supply line to the sensor. Separate the instrument briefly (> 2 s) from voltage supply or push the test key. OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...
  • Page 25 Check if the switching status changes (signal lamp - switching status). By doing so, you can check the function of the measuring system. If this is not the case, then there is a fault in the measuring sys- tem. OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...
  • Page 26 Pushing the test key An integrated test key is lowered in the front plate of the controller or in the electronics module of the OPTISWITCH 5200 C, 5250 C. Push the test key for > 2 seconds with a suitable object.
  • Page 27 Push the test key for > 2 seconds with a suitable object (screwdriver, pen, etc.). When the OPTISWITCH 5200 C, 5250 C is connected to a process- ing system or an SPLC, you have to interrupt the connection cable to the sensor for >...
  • Page 28 < 3.6 mA 0.6 s (±0.2 s) Uncovered 8 mA (±1.5 mA) 1.5 s (±0.5 s) Covered 16 mA (±1.5 mA) 1.5 s (±0.5 s) Starting time of the voltage supply OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...

  • Page 29: Maintenance And Fault Rectification

    Check the vibrating element and the sensor for buildup ement and remove the buildup if there is any. Wrong mode selected Set the correct mode on the controller (overflow protec- tion, dry run protection). Wiring should be carried out according to the idle current principle. OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...

  • Page 30: Exchanging The Electronics

    These electronics modules are called SW60E or SW60E1. How to proceed if a repair is necessary If it is necessary to repair the instrument, please contact the responsi- ble Krohne agency. OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...

  • Page 31: Dismount

    Pass the instrument directly on to a specialised recycling company and do not use the municipal collecting points. If you have no way to dispose of the old instrument properly, please contact us concerning return and disposal. OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...

  • Page 32: Supplement

    Ʋ Supporting material 316L OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...
  • Page 33 10 Nm (7.376 lbf ft) Ʋ Aluminium/Stainless steel housing max. 50 Nm (36.88 lbf ft) High voltage test (enamel) max. 5 KV Gas-tight leadthrough (optional) Ʋ Leakage rate < 10 mbar l/s OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...
  • Page 34 1 g/cm³ (0.036 lbs/in³) (water) Ʋ Product viscosity 1 mPa s Ʋ Superimposed pressure 0 kPa Ʋ Sensor installation Vertically from top Ʋ Density selection switch ≥ 0.7 g/cm³ Measurement accuracy Deviation ± 1 mm (0.04 in) OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...
  • Page 35 (0,043) (0,051) (0,058) (0,065) (0,072) (0,079) (0,087) Fig. 16: Influence of the product density on the switching point Shifting of the switching point in mm (in) Product density in g/cm³ (lb/in³) Switch position ≥ 0.5 g/cm³ (0.018 lb/in³) Switch position ≥ 0.7 g/cm³ (0.025 lb/in³) Switching point at reference conditions (notch) Tuning fork OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...
  • Page 36 The function of the instrument is ensured up to an operating pressure of 100 bar/10000 kPa (1450 psig) at a maximum process temperature of +50 °C (+122 °F) (only with threaded versions). Process temperature (thread or flange temperature) Ʋ OPTISWITCH 5200 C, 5250 C of -50 … +150 °C (-58 … +302 °F) 316L/Alloy C22 (2.4602) OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...
  • Page 37 150 °C 200 °C 250 °C (32 °F) (-58 °F) (122 °F) (212 °F) (302 °F) (392 °F) (482 °F) Fig. 19: Process temperature - Process pressure with switch position ≥ 0.7 g/cm³ (sensitivity switch) Process pressure in bar (psig) Process temperature in °C (°F) OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...
  • Page 38 M20 x 1.5; ½ NPT Ʋ Closing cap ½ NPT Screw terminals for wire cross-section up to 1.5 mm² (AWG 16) Adjustment elements Sensitivity switch Ʋ ≥ 0.5 g/cm³ 0.5 … 2.5 g/cm³ (0.018 … 0.09 lbs/in³) Ʋ ≥ 0.7 g/cm³ 0.7 … 2.5 g/cm³ (0.025 … 0.09 lbs/in³) OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...

  • Page 39: Dimensions

    (3.31") M20x1,5 M20x1,5/ M20x1,5/ M20x1,5/ ½ NPT ½ NPT ½ NPT M20x1,5/ ½ NPT Fig. 21: Housing versions Plastic housing Stainless steel housing (electropolished) Stainless steel housing (precision casting) Aluminium housing OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...
  • Page 40 (0.84") ø 33,7 mm (1.33") Fig. 22: OPTISWITCH 5200 C, 5250 C Thread Clamp Cone DN 25 Slotted nut DN 40 Flange Tuchenhagen Varivent = Sensor length, see chapter "Technical data" OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...
  • Page 41 9 Supplement OPTISWITCH 5200 C, 5250 C, options Fig. 23: Options Gas-tight leadthrough Temperature adapter OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...

  • Page 42: Trademark

    9 Supplement Trademark All the brands as well as trade and company names used are property of their lawful proprietor/ originator. OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...
  • Page 43 Notes OPTISWITCH 5200 C, 5250 C • Two-wire 8/16 mA...
  • Page 44 Products and systems for the oil and gas industry KROHNE Messtechnick GmbH & Co. KG Ludwig-Krohne-Straße 5 D-47058 Duisburg Tel.: +49 (0) 203 301 0 Tel.: +49 (0) 203 301 10389 info@krohne.de The current list of all KROHNE contacts and addresses can be found at: www.krohne.com...
