Star Meter CYYZ3051DA Installation Instructions

Installation instructions
CYYZ3051DA Single crystal silicon single
flange pressure transmitter
Summary
Safety guidance
These installation instructions contain important information on how
to use the transmitter correctly. The transmitter installer shall
carefully read the installation instructions before operating the
transmitter. In case of further understanding or special problems,
which are not described in detail in this operation manual, please
contact our company to obtain necessary information.
Please pay attention to the warning signs on the instructions!
Operators must strictly follow the safety instructions in the
installation instructions. In addition, occupational safety rules,
accident prevention guidelines, national installation standards and
engineering specifications must be observed.
Please keep this instruction properly and store it in a convenient
place near the transmitter.
The copyright of these installation instructions is protected. The
installation instructions of this version are written according to
the functions that can be realized by the corresponding product
during printing, and describe the product functions and operation
steps as detailed and complete as possible. If you find mistakes, you
are welcome to criticize and correct them. The company is not
responsible for the possible wrong description and possible
consequences.
– reserve the right to modify the technical parameters –
Icon description
Danger! – A dangerous situation that could result in death or
！
serious injury.
Warning! – A potentially hazardous situation that could result
！
in death or serious injury.
！ Be careful! – A potentially hazardous situation that may
result in minor injury.
！ Reminder! – A potentially hazardous situation that may cause
personal injury.
Tips! – Tips and information to ensure trouble free operation
of the equipment.
User
！ Warning! These installation instructions are for technicians.
Limitation of liability
If the transmitter is damaged due to non-compliance with the
operation and installation instructions, improper use, self
modification and destruction, the company will not be liable for
compensation and will not provide warranty service.
Unboxing
a) After unpacking, check whether the documents and
attachments are complete according to the packing list.
Packing documents: One copy of installation instructions.
One product qualification certificate.
One warranty card.
b) When receiving the product, please check if the
packaging is intact and verify the transmitter type
Does the number and specifications match the product you
have selected.
c) Observe if there is any damage to the transmitter due
to transportation, in order to ensure proper handling
Be good at handling.
d) Please keep the "warranty card" properly and do not
lose it, otherwise it cannot be returned to the factory
Free maintenance!
ID
Pressure transmitter
星仪
model
model
：
Rated range
Rated range ：
accuracy
output
：
：
accuracy
power supply
protect
：
protect ：
authentication
星仪传感器
24小时服务热线：400-600-4496
Precautions for use on explosion-proof sites
！ danger
Non explosion-proof products, when used in explosion-proof
areas, can cause serious personal injury and significant
material damage. Please note if the model category is an
explosion-proof product.
Warning!
！
The transmitter shall be installed strictly in accordance
with the relevant provisions of GB3836.15-2017 Electrical
Equipment for Explosive Gas Atmospheres Part 15:
Electrical Installation in Hazardous Areas (Except for
Coal Mines).
danger
！
The transmitter casing must be effectively grounded.
danger
！
The product casing is made of aluminum alloy material, and
it is necessary to prevent ignition hazards caused by
impact or friction!
Warning!
！
When the internal components of the transmitter are
damaged and need to be repaired or replaced, they need to
be returned to the factory for replacement or repair.
danger
！
To avoid the risk of explosion, the following rules must
be followed:
-When there is a risk of explosion, it is prohibited to
operate the transmitter in the powered state. Except for
cases where the transmitter is connected through an
intrinsic safety circuit.
-Ensure that the entire circuit is in an equipotential
protection state, regardless of whether it is in an
explosion hazard area or not.
-If there is a possibility of lightning or overvoltage
damage, lightning protection measures must be taken to
prevent overvoltage.
-It is necessary to avoid excessive deposition of dust on
the surface of the transmitter (exceeding 5mm) or complete
coverage by dust.
-It is necessary to form an intrinsic safety
explosion-proof system together with associated equipment
that has passed explosion-proof certification before it
can be used in explosion-proof gas environments. The
system wiring must comply with the user manual
requirements of both the transmitter and the associated
equipment, and the wiring terminals must not be connected
incorrectly.
-Maintenance can only be carried out after confirming that
there are no combustible gases present on the installation
site.
-The connecting cable between this product and its
associated equipment should be a shielded cable with
insulation sheath, and its shielding layer should be
grounded in a safe place.
danger
！
When using explosion-proof, dust isolated, and dust
intrinsic safety transmitters in hazardous areas, the
casing cover of the transmitter must be tightened. To
ensure safe use, safety regulations should be strictly
followed, and it is absolutely not allowed to open the
transmitter cover when powered on. When installing the
transmitter, ensure that the cable outlet is well sealed.
！ danger
Intrinsically Safe and Dust Intrinsically Safe
Transmitters
-Safety barriers must be used in hazardous areas with
explosive mixtures. The safety barrier should comply with
the provisions of GB3836.4-2010 Electrical Equipment for
Explosive Gas Atmospheres Part 4: Intrinsic Safety Type
"i", and undergo explosion-proof testing by relevant
explosion-proof departments and obtain an explosion-proof
certificate. Installation should be carried out according
to the requirements of its user manual. The system wiring
is shown in the diagram.
ExiaⅡCT6
Hazardous
Locations
P
P
I
-Ensure that the connections between each intrinsic safety
transmitter comply with intrinsic safety requirements. The
operator must ensure the intrinsic safety of the entire
system (installation of each intrinsic safety component).
-For safety reasons, intrinsic safety circuits and non
intrinsic safety circuits should be distinguished, and the
wiring of intrinsic safety circuits should be separated
from the wiring of other electrical circuits. The power
transformer supplying power to the safety barrier should
comply with the requirements of Article 8.1 of
GB3836.4-2010 standard.
Warning!
！
Please follow the relevant national regulations for the
parts that are not mentioned and the instructions for the
Explosion proof
parameters (only use of explosion-proof transmitters are incomplete.
for explosion-proof
types)
Wiring diagram
Set range
Product number
[Exia]ⅡCT6
Safe place
+
+
RL
Safety
Power Supply
－
－
barrier
24V D C
1
Explosion proof instructions
Explosion proof type
Complies with standards GB3836.1-2010 and GB3836.2-2010
Explosion proof sign: Ex d Ⅱ C T6 Gb
Explosion proof certificate number: CLEx20.1827
Explosion proof dust type
Complies with standards GB/T 3836.1-2021, GB/T 3836.2-2021,
GB/T 3836.31-2021, GB/T 4208-2017
Explosion proof sign: Ex tb IIIC T80 ℃ Db
Explosion proof certificate number: CCRI 22.1623X
Intrinsic safety type
Complies with standards GB/T 3836.1-2021 and GB/T
3836.4-2021
Explosion proof sign: Ex ia IIC T6 Ga
Intrinsic safety parameters: Ui: 28V, Ii: 93mA, Ci: 10nF,
Li: 0mH, Pi: 0.65W
Associated device parameters: Uo ≤ Ui Io ≤ Ii Po ≤ Pi
Co=Cc+Ci Lo=Lc+Li Uo, Io, Po, Co, Lo are safety barrier
parameters, and Cc and Lc are distribution parameters for
connecting cables.
Explosion proof certificate number: CMExC23.4181XG
Dust intrinsic safety type
Complies with standards GB/T 3836.1-2021 and GB/T 3836.4-2021
Explosion proof mark: Ex ia Ⅲ C T20080 ℃ Da
Intrinsic safety parameters: Ui: 28V, Ii: 93mA, Ci: 10nF,
Li: 0mH, Pi: 0.65W
Associated device parameters: Uo ≤ Ui Io ≤ Ii Po ≤ Pi Co=Cc+Ci
Lo=Lc+Li Uo
Io, Po, Co, and Lo are safety barrier parameters, while Cc and
Lc are distribution parameters for connecting cables.
Explosion proof certificate number: CMExC23.4181XG
Precautions for use
danger
！
Determine the type of filling fluid, only fluorine oil can measure
oxygen. Improper use of other filling liquids can cause explosion
accidents. To ensure safety, it is strictly prohibited to measure
oxygen.
Warning!
！
It is prohibited to measure media that are incompatible with the
material in contact with the transmitter.
! Handle with care and do not throw it casually. Do not use brute
force when installing this transmitter.
When measuring steam or other high-temperature media, be careful
not to let the medium temperature exceed the upper limit of the
transmitter's operating temperature. If necessary, cooling devices
should be installed.
! This product belongs to weak current equipment and must be laid
separately from strong current cables during wiring. It should comply
with relevant national wiring standards (GB/T50312-2016) for wiring.
Ensure that the power supply voltage meets the transmitter power
supply requirements. Ensure that the high pressure of the pressure
source is within the range of the transmitter;
During the pressure measurement process, pressure should be
slowly applied and released to avoid instantaneously increasing to
high pressure or decreasing to low pressure;
Users are advised not to disassemble the product by themselves
and should not touch the membrane to avoid product damage.
Installation precautions
Try to install it in situations with small temperature gradient changes,
while avoiding vibration and impact.
It is recommended to install a pressure shut-off valve before the
pressure measurement point to facilitate the maintenance and disassembly
of the transmitter. In addition, during the initial installation of
pressure measurement, it can reduce pressure impact. After waiting for
the pressure in the pipeline to stabilize, slowly open the shut-off
valve to start measuring.
！
Warning!
Equipment installation must be carried out without pressure or power supply.
If the transmitter is installed in a harsh environment and may
encounter dangerous damage such as lightning strikes or overvoltage,
we recommend that users install lightning protection and overvoltage
protection between the distribution box or power supply and the
transmitter.
执行标准GBT 28474.1-2012
www.star-sensor.com
星仪传感器
STAR METER
版号24.03.26
