Installation instructions
Cyyz101 intelligent wireless pressure transmitter
Safety guidance
This installation instruction contains important information on
how to use the transmitter correctly. The transmitter installer
shall carefully read this operation manual before operating the
transmitter. In case of further understanding or special
problems, which are not described in detail in this
installation manual, please contact our company to obtain
necessary information.
Please pay attention to the warning signs in the manual! It is
forbidden to crystallize or solidify the measured medium,
otherwise the sensor will be damaged!
The operator must strictly follow the installation
instructions. In addition, occupational safety rules, accident
prevention guidelines, national installation standards and
engineering specifications must be observed.
Please keep this manual properly and store it in a convenient
place near the transmitter.
The copyright of these installation instructions is protected.
The installation instructions of this version are written
according to the functions that can be realized by the
corresponding product at the time of printing, and describe the
product functions and operation steps as fully as possible. If
you find mistakes, you are welcome to criticize and correct
them. The company shall not be liable for any possible wrong
description and possible consequences.
– reserve the right to modify the technical parameters –
Icon description
Danger! – A hazardous situation that could result
！
in death or serious injury.
Warning! – A potentially hazardous situation that
！
could result in death or serious injury.
Be careful! – A potentially hazardous situation
！
that may result in minor injury.
Reminder! – A potentially hazardous situation that
could result in personal injury.
Tips! – Tips and information to ensure trouble free
operation of the equipment.
Unpack
a) After unpacking, check whether the documents and accessories
are complete according to the packing list.
Packing documents: one copy of installation instructions.
One product certificate.
A warranty card.
A magnet.
b) When receiving the product, please check whether the package
is intact, and check whether the transmitter model and
specification are consistent with the product you choose.
c) Observe whether the transmitter is damaged due to
transportation for proper treatment.
d) The user is expected to keep the "warranty card" properly
and do not lose it, otherwise it cannot be returned to the
factory for free maintenance!
