micnode2 – Hardware User Guide
Q-SYS Plugin – Download & Configuration
To configure the micnode2 microphone station, you will need to install the respective plugin for Q-SYS designer so that you
can then set up the device's properties.
IMPORTANT: Configuration from the Q-SYS designer is auto populated to the nnounce configuration UI and thus your
micnode 2 device.
1. The nnounce micnode2 plugin for Q-SYS designer can be obtained from:
a. Q-SYS marketplace,
b. nnounce webpage in the Download center.
2. The downloaded file with the plugin needs to be placed on your computer in the folder:
C:\Users\username\Documents\QSC\Q-Sys Designer\Plugins
3. Open your Q-SYS designer.
4. Find the micnode2 plugin in the right panel below and drag and drop it into your design.
Example design:
5. Setup the properties of your micnode2 microphone station –
NOTE: Properties are opened by simple click on the micnode2 item in the right-hand panel.
•
Zone Group Count - define the number of paging zones for the mic station.
•
Configuration Mode – select stream configuration mode:
o Basic – default micnode2 design is applied and stream configuration is predefined for you.
TM
