- Page 1 – Expansion Unit for micnode 2 Microphone Sta on ARDWARE UIDE ©nnounce powered by Simpleway Keep this manual for future reference...
- Page 2 "Na onal Fire Alarm Code." The device is an accessory of the micnode2 microphone sta on and cannot be used as a stand-alone unit. Unpacking 1. micnode aux microphone station 2. handheld microphone 3. wall-mounting station holder nnounce by Simpleway...
- Page 3 A. Front panel 1. Zones buttons – 3x 2. Status LED 3. Handheld push-to-talk microphone 4. Button for call activation Note: The Talk/Start button is directly on the microphone. 5. Magnetic docking plate for microphone 6. Microphone cable nnounce by Simpleway...
- Page 4 – Hardware User Guide B. Rear panel Microphone input RJ-45 connector Clamp for microphone cable fixing nnounce by Simpleway...
-
Page 5: Preliminary Operations
3. Secure the microphone cable with the clamp for cable fixing with the two screws. 4. Push the cable through the cutout in the chase. Use the magne c docking plate on the front panel to posi on the microphone. nnounce by Simpleway... -
Page 6: Set-Up And Operations
IMPORTANT: The micnode aux device uses the same Q-SYS plugin as the micnode2 microphone sta on. NOTE: How to download the plugin and configure the main microphone sta on and stream, please see the micnode 2 Hardware user manual. nnounce by Simpleway... - Page 7 1. Select on your micnode aux device the zone/s to which your announcement is to be paged by clicking on the zone selec on bu on/s. The selected bu on/s will light up. 2. Start your announcement by pressing the Talk/Start bu on on the microphone side. nnounce by Simpleway...
-
Page 8: Technical Specifications
111 mm (W) x 42 mm (D) x 107 mm (H) US 2–gang box compa ble 400 g without Microphone Accessories Moun ng kit, Microphone, Desk stand (op onal) CONTACT Simpleway North America Simpleway Europe a.s. Headquarters: Address: Address: 1621 Central Avenue...
