Printronix P5 Quick Setup Manual page 11

3. Remove the cardboard packing.
4. Open the tractor doors.
5. Push the tractor locks down.
6. Slide the tractors outward as far as they will go.
7. Raise the forms thickness lever to the fully open position.
8. Remove the envelope containing the sample configuration
printout.
9. Store the envelope in the pouch attached to the left interior side
of the cabinet.
Figure 6. Removing the Hammer Bank Protective Foam - P5000 Series Models
Remove Packing Materials
Hammer Bank
Protective Foam
Paper Supports (2)
11
