- Page 1 MODEL: S1423S-XX Version: 1.0 INSTALLATION GUIDE WIDESPREAD BATHROOM SINK FAUCET MODEL FINISH S1423S-CH Chrome S1423S-BN Brushed Nickel S1423S-OB Oil Rubbed Bronze S1423S-MB Matte Black S1423S-BG Brushed Gold HOT LINE: +1-866-203-0866...
-
Page 2: Before Proceeding
THANK YOU Dear Valued Customer, SUMERAIN would like to take this opportunity to thank you for purchasing SUMERAIN products. It is our sincere hope that you are completely satisfied with your new purchase. All SUMERAIN products are carefully engineered, and factory tested to provide long trouble-free use under normal conditions. This product is easy to install using basic tools and our easy to follow illustrated instructions. -
Page 3: Limited Lifetime Consumer Warranty
If a defect is found in normal residential use, SUMERAIN will, at its election, repair, provide a replacement part or product, or make appropriate adjustment. - Page 4 FUNCTIONS AND SPECIFICATION Bathroom Sink Faucets Function Feature Widespread Style Traditional Chrome/Brushed Nickel/Matte Black/Brushed Gold/Oil Rubbed Bronze Finish Installation Holes Three Holes Two Lever Number of Handles Total Height 5.0 Inch [127mm] Spout Reach 5-5/16 Inch [135mm ] Spout Width 1-11/16 Inch [43mm] Spout Height 3-3/16 Inch...
- Page 5 DEMENSION FRONT VIEW OF FAUCET SIDE VIEW OF FAUCET...
-
Page 6: Installation Steps
Set screw SUS304 PSC00001XX Screw Cover (Blue) PSA00023XX Spout Zn Alloy No.3 PSP14230XX Disc cartridge(Cold) ASSEMBLE PCT14231XX Rubber washer PRW23165XX Supply hose ASSEMBLE PFH00006XX If any of these items are missing, please contact SUMERAIN consumer service by email to: supports@sumerain.com... - Page 7 4. INSTALLATION HOLES INSPECTION Verify that the hole sizes and positions in the wall are correct, the diameter of mounting hole recommend 1-1/4” (32mm), the max thickness of deck should be 1-1/2” (35mm). BASIN...
- Page 8 5. INSTALLATION 5.1 Turn on your shut-off valve for cleaning the hot and cold water supply pipe before connect to the faucet, allow the water flush 3~5 minutes to flush out dirt and debris. Shut off the water supply again after done. HOT WATER SUPPLY COLD WATER SUPPLY 5.2 Remove the mounting hardware from the mounting shank...
- Page 9 5.3 Make certain the seal (O-ring) is properly seated in bottom recess of faucet body. Insert shank through mounting hole of deck, seat faucet body base onto sink or mounting surface and attach all mounting hardware and tighten with screw by Philips screwdriver from below.
- Page 10 5.5 Install the hot water valve on the left and the cold water valve on the right of the spout. Slide rubber and metal washers onto the valves from under the sink. Hand-tighten the mounting nut of valves counterclockwise onto the countertop. Secure with a Phillips screwdriver by tightening the two screws on the mounting nuts.
- Page 11 5.7 Connect the cold and hot water supply hoses to their respective valve inlets. Attach the other ends to the cold and hot water supply stops. Use 3/8" compression fittings for North America and G1/2 (1/2" BSPP) for Europe, Asia, and the Middle East.
