Chapter 1 Product Introduction

1.1 System Features

1.1.1 System parameters
Model
Intel Xeon processor E5-2600 V3/V4 series
Processor
Socket H3 (LGA2011) up to 145W CPU
Virtual cloud desktop
3D rendering production
Key Financial analysis
applications
Environmental assessment
Biological science research
Big data mining
1600 W 1+1 Redundant Platinum-Efficiency Power Supply
Support 12* 3.5/2.5-inch SATA3.0 6Gb/s hard drive
Outstanding
High density, high performance, low cost, low power consumption,
features
without cables
Dedicated Gigabit management LAN with IPMI 2.0
Motherboard
G1DCN-B
Chipset
Intel PCH WellsBurg C612 chip
Single node supports 16* ECC DDR4-1600/1866/2133 RDIMM/
Memory
LRDIMM
Expansion
Single node supports 1* PCI-E X16 full-height expansion card or 2 *
card
PCI-E X8 full-height expansion cards
SATA
Support RAID 0, 1, 10, 5 (Windows Only)
LAN Single node supports 2* 1GbE
VGA
Aspeed AST2400 Graphics
Management
IPMI 2.0 + KVM with dedicated LAN
interface
1600W
Power supply
hot-swap replacement
Fan
4* non-hot-swap
Dimensions 2U Rackmount, 760mm* 444mm* 88mm

1.1.2 System Overview

The SY202-D12R barebone system is a high-performance & high-density server barebone
product. The product supports 2* simple-plug high-performance server nodes and 12*
hot-swap hard disk modules in a 2U chassis height .
Features:
Each node supports 6* 3.5/ 2.5-inch SATA3.0 hard drives.

Each NODE is independent and supports hot-swap. During the process of

adding NODE, customers do not need to stop the business of other NODEs.
Server system adopts Intel Grantley-EP platform, with LGA2011 CPU,

supports Intel Xeon Processor E5-2600 V3/V4 series, up to 145W, and is
compatible with Broadwell series processors.
SY202-D12R
1+1 Redundant Platinum-Efficiency
8038
fans (12V/Max 3.3A)
1
power supply, support
