SC2000E Series Vision Sensor Quick Start Guide
Parameter Name
Input Logic Level Low
Input Logic Level High
Input Falling Delay
Input Rising Delay

9.2 Output Signal

The device has one output signal (Line 3) and two configurable bi-directional I/Os (Line
0/1) that can be configured to output signal, and their internal circuit is shown below.
GPO
Note
The max. output current is 25 mA.
Internal
Logic
Output
Level High
Output
Level Low
When the external voltage is 12 VDC and pull-up resistor is 1 KΩ, output electric feature is
Table 9-1 Input Electrical Feature
VL
VH
TDF
TDR
Figure 9-3 Internal Circuit of Output Signal
50%
TDF
90%
50%
10%
TF
Figure 9-4 Output Logic Level
Parameter Symbol
20
Value
1 VDC
2 VDC
200 ns
1 μs
50%
TDR
90%
50%
10%
TR
