SC2000E Series Vision Sensor Quick Start Guide
Note
Appearance here is for reference only. Refer to the device's specification for detailed
dimension information.
No.
Name
1
Focus Knob
2
Screw Hole
Trigger
3
Button
4
SR Cable
Chapter 3 Appearance
Figure 3-1 Appearance
Table 3-1 Component Description
It is used to adjust focal length manually.
It is used to fix the device to the installation position. You should use
M3 screw.
When the device is in trigger mode, press the button and the device
triggers once.
SR cable connector provides power, digital I/O, Ethernet, and serial
port.
Description
5
