SC2000E Series Vision Sensor Quick Start Guide
6.1 Installation Preparation
You need to prepare following accessories before installation.
No. Name
1 17-Pin Cable
Power Adapter or
2 Switch Power
Supply
3 IO Box
6.2 Install Device
Before You Start
● Make sure that the device in the package is in good condition and all assembly parts are
included.
● Make sure that all related devices are powered off during the installation.
Steps
1. Use M3 screws to fix the device to the installation position.
2. Connect the 17-pin M12 connector of the cable to the device, insert RJ45 connector of
the cable into a switch or a PC for debugging images or transmitting data.
3. Connect the supplied 8-pin connector to a power adapter or a switch power supply for
power supply.
Chapter 6 Installation
Table 6-1 Accessories
Quantity
It refers to the supplied 17-pin cable that is
1
included in the package.
You should select suitable power adapter or
switch power supply according to the device
1
power supply and consumption. You need to
purchase separately.
It refers to the IO box that is used for wiring with
pull-up and pull-down resistors when devices
connect to the external NPN/PNP devices.
1
Whether the IO box is included in the package may
differ by device models. Please refer to the actual
one.
Description
Note
