Advantech UNO-247 V2 Startup Manual

UNO-247 V2 Intel® N97 Edge Intelligent Gateway
for Automation
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
1. UNO-247 V2 bare-bone system x 1
2. Startup manual EN\CN\TC for UNO-247 V2 1st Ed
P/N: 2041024700
3. Remote Power Connector
P/N: 1652007993-01
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note:
Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at: get.
adobe.com/reader (Acrobat is a trademark of
Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our sup-
port website for UNO-247 V2 at:
Register your products on our website and get 2
months extra warranty for Free at:
http://www.register.advantech.com
Part No. 2041024700
Printed in China
1st Edition
November 2024
Packing List (Cont.)
Caution: DANGER OF EXPLOSION IF BATTERY IS
INCORRECTLY REPLACED. REPLACE ONLY
WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER,
DISCARD USED BATTERIES ACCORDING TO
THE MANUFACTURER'S INSTRUCTIONS.
Attention: DANGER D'EXPLOSION SI LA BATTERIE EST
INEXACTEMENT REMPLACÉE. REMPLACEZ
SEULEMENT AVEC LA MÊME CHOSE OU
LE TYPE ÉQUIVALENT RECOMMANDÉ PAR
LE FABRICANT, JETTENT LES BATTERIES
UTILISÉES INSTRUCTIONS DE S SELON
FABRICANT DES'.
Specifications
Processor System
• Intel® N97 4 Core 6M Cache, up to 3.60 GHz 12W
Memory
• Supports dual channel DDR5 SODIMM-4800 MHz; Max.
capacity is 16 GB
Graphics
• Intel® UHD Graphics
Serial Ports
• 2 x RS-232/422/485 (50 to 115.2Kbps)
• 4 x RS-485 DB9, (50bps ~ 115.2kbps)
Ethernet
• LAN A: 4 x RJ45, 10/100/1000 Mbps IEEE 802.3u
Storage
• 1 x mSATA (full size)
• Or 1 x drive bay for SATA 2.5" HDD
Expansion
• 1 x Full size mPCIe slot (SATA/ USB2.0 Signal)
• 1 x M.2 (3042/3052, B Key, PCIe/SATA/USB3.0)
• 1 x Nano SIM card slot
External I/O
• Display: 1 x VGA, 1 x HDMI
• USB: 2 x USB 3.2, 2 x USB 2.0
• Serial: 2 x RS232/422/485, 4 x RS485
• Power Connector: 1 x Terminal Block, 1 x Remote
Switch
UNO-247 V2 Startup Manual 1
