Mec Micro2032 Service & Parts Manual page 71

Section 13 - Chassis
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
Page 67
Part Number
46237 Wheel
53509 Screw HHCS M12-1.50 × 40 ZP
41237 Cap
53282 Screw CSCS M08-1.25 × 20 ZP
41025 Bearing Seat
41002 Ladder
43585 Cotter Pin
43586 Spindle
49139 Ladder
50429 Screw HHCS M10-1.50 × 25 Serrated Flange ZP
53260 Screw HHCS M06-1.00 × 10 Serrated Flange ZP
41003 Ground Strap
53290 Screw HHCS M12-1.75 × 65 Flange ZP
53194 Screw HHCS M08-1.25 × 16 Serrated Flange ZP
REF Charger Assembly (Refer to page 68)
53261 Nut NNYL M12-1.75 Flange ZP
43588 Seal
41029 Bearing
41024 Bearing
41304 Washer
53262 Castle Nut M22-1.50 ZP
REF - Reference
Micro2032 - Service & Parts Manual - 96898
Description
December 2024
Qty.
2
10
2
16
2
2
2
2
1
4
1
1
8
2
1
8
2
2
2
2
2
