Mec Micro2032 Service & Parts Manual page 77

Section 14 - Scissor
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
Page 73
Part Number
53271 Screw HHCS M10-1.50 × 100 Flange ZP
49147 Platform Slider
50311 Nut NNYL M10-1.50 Flange ZP
44910 Pin
49148 Bearing
53267 Screw HHCS M10-1.50 × 110 Flange ZP
Inner Arm 4
49149
49150 Outer Arm 4
43595 Cable Bridge
44533 Clamp
Inner Arm 3
49151
49152 Left Single Link
53270 Screw HHCS M08-1.25 × 25 Serrated Flange ZP
50313 Nut NNYL M08-1.25 Flange ZP
41615 Safety Arm
41616 Safety Arm Bushing
49153 Pin
49154 Pin
41688 Washer
48859 Washer
41202 Bearing
41710 Chassis Slider
44900 Pin
49155 Outer Arm 1
44902 Hose
Inner Arm 1
49156
50022 Screw HHCS M10-1.50 × 70 ZP
50049 Nut NNYL M10-1.50 ZP
46328 Pin
REF Lower Lift Cylinder Assembly (Refer to page 84)
53269 Screw CSCS M05-0.80 × 16 ZP
44884 Washer 2
Inner Arm 2
49157
41114 Block
49158 Right Single Link
44909 Pin
REF - Reference
Micro2032 - Service & Parts Manual - 96898
Description
December 2024
Qty.
2
4
4
4
28
2
1
1
3
6
1
2
2
2
2
2
9
2
22
22
40
2
2
1
1
1
5
5
1
1
6
6
1
32
2
2
