  • Page 1 HULALA ITEM NO.SBYL1000 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/25...
  • Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.

  • Page 3: Explosive View

    EXPLOSIVE VIEW 2PERSONEN 03/25...

  • Page 4: Parts List

    PARTS LIST 04/25...
  • Page 5 PARTS LIST 05/25...

  • Page 6: Hardware List

    HARDWARE LIST Ø4*38mm Ø8*30mm Ø3*15mm Ø3*15mm Ø6*50mm Ø8*30mm Ø3*15mm TOOL LIST HARDWARE SPARE LIST Ø4*38mm Ø3*15mm Ø6*50mm Ø8*30mm 06/25...
  • Page 7 HARDWARE SPARE LIST Ø3*15mm Ø8*30mm Ø3*15mm 07/25...
  • Page 8 ASSEMBLY INSTRUCTIONS STEP-1 1.Use screw B1 to attach magnetic catch B3 to the corresponding hole of top panel(A), tighten screw with screwdriver B18. 08/25...
  • Page 9 ASSEMBLY INSTRUCTIONS STEP-2 1.connect part(A16/A17) to top panel (A1) with screw B6 and wood dowel B10, tight screw with screwdriver B18 Ø4*38mm Ø8*30mm 09/25...
  • Page 10 ASSEMBLY INSTRUCTIONS STEP-3 1. insert part(A3/A4/A5/A6) to top panel (A1), make sure all holes aligned, tight it with allen wrench (B17). A4&A5&A6&A3 A4&A5&A6&A3 FRONT 10/25...
  • Page 11 ASSEMBLY INSTRUCTIONS STEP-4 1.Insert bottom panel (A2) to pre-assembled unit at step 3, make sure all holes aligned , tight it with allen wrench B17. A4&A5&A6&A3 A4&A5&A6&A3 FRONT 11/25...
  • Page 12 ASSEMBLY INSTRUCTIONS STEP-5 1. attach leg (A15) to bottom panel (A12) with bolt B8, spring washer B11 and flat washer B12, tight bolt with allen wrench B17. 2. attach leg (A19) to bottom panel with hand. B12x8 B8x8 B11x8 BACK Ø6*50mm 12/25...
  • Page 13 ASSEMBLY INSTRUCTIONS STEP-6 1.attach part (A10/A18) to bottom panel (A2) with wood dowel B10 and part B20 and part B7. tight part B7 with screwdriver B18. Ø8*30mm A10&A18 BACK 13/25...
  • Page 14 ASSEMBLY INSTRUCTIONS STEP-7 1.open back panel A7. connect back panel to pre-assembled unit at step 6 with screw B1, tight screw with screwdriver B18. 14/25...
  • Page 15 ASSEMBLY INSTRUCTIONS STEP-8 15/25...
  • Page 16 ASSEMBLY INSTRUCTIONS STEP-9 1.connect part B5 to door(A14/A12) with screw B16, tight screw with screwdriver B18. A12&A14 Ø3*15mm 16/25...
  • Page 17 ASSEMBLY INSTRUCTIONS STEP-10 1.Connect door (A14/A12) to pre-assembled unit at step 8 with screw B16, tight screw with screwdriver B18 . A14&12 Ø3*15mm 17/25...
  • Page 18 ASSEMBLY INSTRUCTIONS STEP-11 1.Connect B4 to door A13 with screw B16, tight screw with screwdriver B18. Ø3*15mm 18/25...
  • Page 19 ASSEMBLY INSTRUCTIONS STEP-12 1.Connect door (A13) to pre-assembled unit at step 10 with screw B16, tight screw with screwdriver B18 . Ø3*15mm 19/25...
  • Page 20 ASSEMBLY INSTRUCTIONS STEP-13 Concealed hinges are three-way adjustable: Horizontal by screw adjustment! Concealed hinges are three-way adjustable: In-and-out by loosening the hinge arm mounting screw or via cam adjustment! Concealed hinges are three-way adjustable: Vertical via slots in the mounting plate or via cam adjustment! Hinge adjustment method 20/25...
  • Page 21 ASSEMBLY INSTRUCTIONS STEP-14 1.Insert shelf holder B2 into the corresponding hole of pre-assembled unit at step 12 and attach part (A8/A9/A11) to it. Shelf holder can be adjusted up or down 21/25...
  • Page 22 ASSEMBLY INSTRUCTIONS B16 x4 Ø3.5*14MM STEP-15 Use screw B16 to attach part B9 to preassemble unit at step 15 , tighten screws with screwdriver B18 22/25...
  • Page 23 ASSEMBLY INSTRUCTIONS B13 x4 STEP-16 1.Mark the position on the wall, that corresponds to the location of bracket B9 on the back of top panel (A1); Drill and insert the expandable screw B13 by hammer. 2.Assemble the bracket B13 to the wall. Align the hole in the bracket B9 with the expandable screw B13 , use screw B4 to attach it ，...
  • Page 24 ASSEMBLY INSTRUCTIONS B15 x2 STEP-17 3.Let the plastic belt B15 pass through bracket B9 and pull tightly. 24/25...

  • Page 25: Warranty

    WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
