- Page 1 HULALA SBPZ0887 ITEM NO. NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/19...
- Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.
- Page 3 2PERSONEN 03/19...
-
Page 4: Parts List
PARTS LIST 04/19... -
Page 5: Hardware List
HARDWARE LIST Ø3*15mm Ø3*16mm Ø3.5*15mm Ø3.5*35mm 1/4''*2'' ∅ 1/4"*1/2" TOOL LIST HARDWARE SPARE LIST Ø Ø3*16mm ''*2'' Ø3.5*35mm 05/19... - Page 6 ASSEMBLY INSTRUCTIONS STEP-1 1.Aligned part (O) with leg(N&M)and then insert part (O) into part (N&M),make sure all holes aligned and use bolt #12 to attach them ， tighten screw #12 with allen key #14 . Insert leg stand into the bottom （B）， make sure all holes aligned and then use bolt #5 &spring washer #13 to attach them ，...
- Page 7 ASSEMBLY INSTRUCTIONS STEP-2 1.Insert side panel (C ＆ D&E&F) into bottom panel (B),make sure all holes aligned and then tighten it with allen key #14 as picture show. C&E &F 07/19...
- Page 8 ASSEMBLY INSTRUCTIONS STEP-3 1.Insert top panel(A) into the corresponding hole of preassembled step 2 ， make sure all holes aligned and use allen key #14 to tighten it as picture show. C&E&F 08/19...
- Page 9 ASSEMBLY INSTRUCTIONS STEP-4 Open the back panel (G),insert back panel(G) into the groove of preassembled step 3,make sure all holes aligned and use screw#2 to attach them ，tighten screw #2 with screwdriver #2x28 #2X28 Ø3*15mm 09/19...
- Page 10 ASSEMBLY INSTRUCTIONS STEP-5 1.Attention:After installation, adjust the adjustable leveler to keep the cabinet balanced . Attention: After installation, adjust the adjustable leveler to keep the cabinet balanced . 10/19...
- Page 11 ASSEMBLY INSTRUCTIONS STEP-6 1.Use screw #1 to attach hinge #10 to door (J)&(L),tighten screw #1 with screwdriver #15 . 2.Use screw #1 to attach hinge #11 to door (K),tighten screw #1 with screwdriver #15 . Ø3.5*15mm 11/19...
- Page 12 ASSEMBLY INSTRUCTIONS STEP-7 1.Use screw #1 to attach left door (J) and right door (L) to pre-assemble unit at step 5 ,tighten screw with screwdriver #15. Ø3.5*15mm 12/19...
- Page 13 ASSEMBLY INSTRUCTIONS STEP-8 1.Use screw #1 to attach middle door (K) to pre-assemble unit at step 7 ,tighten screw with screwdriver #15. Ø3.5*15mm 13/19...
- Page 14 ASSEMBLY INSTRUCTIONS STEP-9 Insert shelf holder #6 into the corresponding hole of panel (C)&(D)&(E)&(F) and then attach panel (H&I) to it. Shelf holder can be adjusted up or down 14/19...
- Page 15 ASSEMBLY INSTRUCTIONS STEP-10 Concealed hinges are three-way adjustable: Horizontal by screw adjustment! Concealed hinges are three-way adjustable: In-and-out by loosening the hinge arm mounting screw or via cam adjustment! Concealed hinges are three-way adjustable: Vertical via slots in the mounting plate or via cam adjustment! Hinge adjustment method 15/19...
- Page 16 ASSEMBLY INSTRUCTIONS Ø3*16mm STEP-11 to attach part #7 to back panel (G),tighten screw #1 with screwdriver Use screw #15 . 16/19...
- Page 17 ASSEMBLY INSTRUCTIONS Ø3.5*35mm STEP-12 Install the anti-collapse device. 2.Mark the position on the wall, that corresponds to the location of part #7 on the back of panel (G); Drill and insert the expandable screw by hammer. Assemble the part #7 to the wall. Align the hole in the part #7 with the expandable screw #8 , use screw #4 to attach it and tighten by screwdriver #15.
- Page 18 ASSEMBLY INSTRUCTIONS STEP-13 Let the plastic belt #9 pass through the both part #7 and pull tightly. #9x2 #9x2 18/19...
-
Page 19: Warranty
WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
