- Page 1 HULALA SBHM0854 ITEM NO. NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/27...
- Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.
- Page 3 2PERSONEN 03/27...
-
Page 4: Parts List
PARTS LIST 04/27... -
Page 5: Hardware List
HARDWARE LIST Ø3*14mm*6 Ø3.5*20m*7 Ø3.5*14m*7 Ø1/4*2 Ø8*1\4m* Ø3*16m TOOL LIST HARDWARE SPARE LIST 05/27... - Page 6 ASSEMBLY INSTRUCTIONS STEP-1 1.Use bolt #4 to attach leg(L) to bottom panel (B),make sure all holes aligned and tighten it with allen key #14 . #4x8 06/27...
- Page 7 ASSEMBLY INSTRUCTIONS STEP-2 1.Screw leg(M) into panel (B) with hand as picture show . 07/27...
- Page 8 ASSEMBLY INSTRUCTIONS STEP-3 1.Use bolt #15 to attach Weight blocks (P) to bottom panel (B),make sure all holes aligned and tighten it with screwdrive #13. 08/27...
- Page 9 ASSEMBLY INSTRUCTIONS STEP-4 1.Insert side panel(C)&(D) into bottom panel (B),make sure all holes aligned and then tighten it with allen key #14 as picture show . 09/27...
- Page 10 ASSEMBLY INSTRUCTIONS STEP-5 1.Insert middle vertical panel(E) into bottom panel (B),make sure all holes aligned and then tighten it with allen key #14 as picture show . 10/27...
- Page 11 ASSEMBLY INSTRUCTIONS STEP-5 1.Use screws #3 to attach rebound device #5 to panel(A) ,make sure all holes aligned and then tighten it with screwdrive #13 . #3x16 #5x4 11/27...
- Page 12 ASSEMBLY INSTRUCTIONS STEP-6 1.Use screws #15 to attach wine glass rack (N&O) to panel(A) ,make sure all holes aligned and then tighten it with screwdrive #13 . #15x9 12/27...
- Page 13 ASSEMBLY INSTRUCTIONS STEP-7 1.Insert panel(A) into preassembled unit at step 6 ， make sure all holes aligned and then tighten it with allen key #14 . 13/27...
- Page 14 ASSEMBLY INSTRUCTIONS STEP-8 1.Open the panel (F), insert panel(F) into the groove of preassembled step 7,and then use screw #2 to attach panel (F) to the preassembled step 7,tighten it with screwdriver #13 . 14/27...
- Page 15 ASSEMBLY INSTRUCTIONS STEP-9 1.Insert shelf pin #8 into preassemble unit at step 8 ， and attach adjustable shelf (G) to it. #8x8 Shelf holder can be adjusted up or down 15/27...
- Page 16 ASSEMBLY INSTRUCTIONS STEP-10 16/27...
- Page 17 ASSEMBLY INSTRUCTIONS STEP-11 1.Use screw #1 to attach the hinges #6 to door panel (H)&(K) ， tighten screws with screwdriver #13. #6x4 When installing hinge please pay attention to distinguish the category of hinge!!!! 17/27...
- Page 18 ASSEMBLY INSTRUCTIONS STEP-12 1.Use screw #1 to attach the hinges #7 to door panel (I)&(J) ， tighten screws with screwdriver #13 . #1x8 #7x4 When installing hinge ， please pay attention to distinguish the category of hinge!!!! 18/27...
- Page 19 ASSEMBLY INSTRUCTIONS STEP-13 1.Use screw #1 to attach left door (H) and right door (K) to preassemble unit at step 10 , tighten screws with screwdriver #13 . #1x16 19/27...
- Page 20 ASSEMBLY INSTRUCTIONS STEP-14 1.Use screw #1 to attach middle door (I) to pre-assemble unit at step 13 ,tighten screw with screwdriver #13. #1x8 20/27...
- Page 21 ASSEMBLY INSTRUCTIONS STEP-15 1.Use screw #1 to attach middle door (J) to pre-assemble unit at step 14 ,tighten screw with screwdriver #13. 21/27...
- Page 22 ASSEMBLY INSTRUCTIONS STEP-16 Concealed hinges are three-way adjustable: Horizontal by screw adjustment! Concealed hinges are three-way adjustable: In-and-out by loosening the hinge arm mounting screw or via cam adjustment! Concealed hinges are three-way adjustable: Vertical via slots in the mounting plate or via cam adjustment! Hinge adjustment method 22/27...
- Page 23 ASSEMBLY INSTRUCTIONS STEP-17 Attention: If the door looks over out or over in,you can adjust the head rebounder as image. 23/27...
- Page 24 ASSEMBLY INSTRUCTIONS #16 x4 STEP-18 Use screw #16 to attach part #12 to preassemble unit at step 15 , tighten screws with screwdriver #13 #16x4 24/27...
- Page 25 ASSEMBLY INSTRUCTIONS #11 x4 STEP-19 Install the anti-collapse device. 2.Mark the position on the wall, that corresponds to the location of part #12 on the back of panel (F); Drill and insert the expandable screw by hammer. Assemble the part #12 to the wall. Align the hole in the part #12 with the expandable screw #11 , use screw #10 to attach it and tighten by screwdriver #13.
- Page 26 ASSEMBLY INSTRUCTIONS STEP-20 Let the plastic belt #9 pass through the both part #9 and pull tightly. #9x2 #9x2 26/27...
-
Page 27: Warranty
WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
