- Page 1 HULALA ITEM NO.SBSD1117 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/33...
- Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.
- Page 3 EXPLOSIVE VIEW 2PERSONEN 03/33...
- Page 4 PARTS LIST 04/33...
- Page 5 PARTS LIST 05/33...
- Page 6 HARDWARE LIST ∅ ∅ ∅ 6x30mm 8x30mm 15x11mm x50mm x15mm x50mm ∅ M3.5 20mm x14mm 1 pair 1 pair x35mm φ8*30mm HARDWARE LIST ∅ M3.5 6x30mm x15mm x50mm x14mm 06/33...
- Page 7 ASSEMBLY INSTRUCTIONS STEP-1 Align the holes in part D, insert wooden dowel #2 by hand. #2*2 #2*2 ∅ 8x30mm 07/33...
- Page 8 ASSEMBLY INSTRUCTIONS STEP-2 Use #6 screws to fix the U component to the corresponding position on the panel (D), and use a #17 hex wrench to tighten the screws. x50mm 08/33...
- Page 9 ASSEMBLY INSTRUCTIONS STEP-3 Lift the black button up with your hand and pull out the movable rail. Male slider Female slider 1付 09/33...
- Page 10 ASSEMBLY INSTRUCTIONS STEP-4 Use #11 screws to fix the slide rail #14 to the corresponding position of the part (U), and tighten the screws with a screwdriver #18. #11*2 #11*2 ∅ 3.5*14mm 10/33...
- Page 11 ASSEMBLY INSTRUCTIONS STEP-5 Use #11 screws to fix the slide rail #14 to the corresponding position of the part (F), and tighten the screws with a screwdriver#18. #11*2 #11*2 ∅ 3.5*14mm 11/33...
- Page 12 ASSEMBLY INSTRUCTIONS STEP-6 1.Prepare for part A. Align the holes in part A, insert wooden dowel #2 by hand, and tighten bolt #1 with screwdriver #18 。 2.Use bolt #11 to attach bouncer #12 to top panel (A) tighten bolts with ，...
- Page 13 ASSEMBLY INSTRUCTIONS STEP-7 1.Connect the part A with part C&D. align the hole in the part C&D,insert the bolt #1 and wooden dowel #2 in part A into part C&D. insert cam bolt #3 into the corresponding hole of side panel C&D,and tighten the nuts #3 with a screwdriver #18.
- Page 14 ASSEMBLY INSTRUCTIONS STEP-8 1.Connect the part A with part E&F. align the hole in the part E&F,insert the bolt #1 and wooden dowel #2 in part A into part E&F. insert cam bolt #3 into the corresponding hole of side panel E&F,and tighten the nuts #3 with a screwdriver #18.
- Page 15 ASSEMBLY INSTRUCTIONS STEP-9 1.Slide parts G, H, G into the grooves of part C, E and, Fand D. Make sure they are in the slots in Part A as well. 15/33...
- Page 16 ASSEMBLY INSTRUCTIONS STEP-10 1.Insert the wooden dowel #2 into the part C&E&F&D as the picture show. 2.Connect the part B the pre-assembled unit in step 9. Then align the holes in part B,Insert screw #4 and push it down so that it connects to parts C&E&F&D. Next,and tighten the screw #4with an Allen key #17.
- Page 17 ASSEMBLY INSTRUCTIONS STEP-11 1.Align the holes of part K insert the bolt #5, Install the middle foot(L) to part K. Use bolt #5 to mount I and K together.and tighten the bolt #5 with an Allen key #17. x15mm 17/33...
- Page 18 ASSEMBLY INSTRUCTIONS STEP-12 1.connect the leg frame to the cabinet.Attach the leg frame to the pre-assembled unit in step 10 with a bolt #6 and tighten #6 with a allen key #17. x50mm 18/33...
- Page 19 ASSEMBLY INSTRUCTIONS STEP-13 Attention: Before the next step, adjust the feet of the locker to keep it level. 19/33...
- Page 20 ASSEMBLY INSTRUCTIONS STEP-14 1.Insert hardware #16 into part G&H&G as shown, screw in screw #11 using screwdriver #18 and tighten fully. M3.5 x14mm 20/33...
- Page 21 ASSEMBLY INSTRUCTIONS STEP-15 Step 15:Preparing the drawers,insert the #1 bolt into the M part, and use a #18 screwdriver to screw the #1 bolt into the M part. Align the #15 slide rail with the hole in the N&O part and use a #18 screwdriver to screw the #11 bolt into the N&O part.
- Page 22 ASSEMBLY INSTRUCTIONS STEP-16 Step 16: Prepare the drawers. Slide the inner box R&Q&S parts into the N and O grooves. Then slide the P&T section into the N and O slots, align the holes in the P section, and use a #18 screwdriver to screw the #12 bolt into the N&O section 1 pair 22/33...
- Page 23 ASSEMBLY INSTRUCTIONS STEP-17 STEP17: Slide in the drawer into cabinet as the picture show. You can adjust the distance between drawer and the cabinet. Attention ： When installing the drawer ， .slide the steel ball slide rail of side panel to the most front as picture show .
- Page 24 ASSEMBLY INSTRUCTIONS STEP-18 1.Insert shelf pin #8 into pre-assemble unit at step 18.attach adjustable shelf I&J to pin #8. Shelf holder can be adjusted up or down 24/33...
- Page 25 ASSEMBLY INSTRUCTIONS STEP-19 1.Use screw #5 to attach the hinges #9 to door panel (V&X)，tighten screws #5 with screwdriver #18. 2.Use screw #5 to attach the part #12 to door panel (V&X)，tighten screws #5 with screwdriver #18. When installing hinge please ，...
- Page 26 ASSEMBLY INSTRUCTIONS STEP-20 1.Use screw #11 to attach left door (V) and right door (X) to pre-assemble unit at step 18 ,tighten screw #11 with screwdriver #18 . M3.5 x14mm 26/33...
- Page 27 ASSEMBLY INSTRUCTIONS STEP-21 1.Use screw #11to attach the hinges #10 to door panel (W)，tighten screws #11 with screwdriver #18. 2.Use screw #11 to attach the part #12 to door panel (W)，tighten screws #11 with screwdriver #18. When installing hinge please ，...
- Page 28 ASSEMBLY INSTRUCTIONS STEP-22 1.Use #11 screws to connect the pre-assembled door panel (W) to the pre-assembled unit in step 18, and tighten the #11 screws with a #18 screwdriver. M3.5 x14mm 28/33...
- Page 29 ASSEMBLY INSTRUCTIONS STEP-23 Concealed hinges are three-way adjustable: Horizontal by screw adjustment! Concealed hinges are three-way adjustable: In-and-out by loosening the hinge arm mounting screw or via cam adjustment! Concealed hinges are three-way adjustable: Vertical via slots in the mounting plate or via cam adjustment! Hinge adjustment method 29/33...
- Page 30 ASSEMBLY INSTRUCTIONS STEP-24 1.Use screw #11 to attach part #20 to pre-assemble unit at step 24 ,tighten screws with screwdriver #18. #20x2 #11x4 #20x2 #11x4 M3.5 x14mm 30/33...
- Page 31 ASSEMBLY INSTRUCTIONS STEP-25 φ8*30mm M4*35mm 1.Install the anti-collapse device. 2.Mark the position on the wall, that corresponds to the location of part B15 on the top of panel (A11); Drill and insert the expandable screw B14 by electric drill. 3.Assemble the part B15 to the wall. Align the hole in the part B15 with the expandable screw B14, use screw B5 to attach it and tighten by screwdriver B18.
- Page 32 ASSEMBLY INSTRUCTIONS STEP-26 1.Let the plastic belt B16 pass through the both part B15 and pull tightly. 32/33...
- Page 33 WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
