HULALA HOME SBHM0624 Manual

Hide thumbs Also See for SBHM0624:

Advertisement

Table of Contents

HULALA
H
O
M
E
ITEM NO.SBHM0624
NOTE:
This brochure contains IMPORTANT safty info. Please read and keep for future
reference.
01/30

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SBHM0624 and is the answer not in the manual?

Questions and answers

Related Manuals for HULALA HOME SBHM0624

Summary of Contents for HULALA HOME SBHM0624

  • Page 1 HULALA ITEM NO.SBHM0624 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/30...
  • Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.

  • Page 3: Explosive View

    EXPLOSIVE VIEW 2PERSONEN Around 03/30...

  • Page 4: Parts List

    PARTS LIST 04/30...
  • Page 5 PARTS LIST 05/30...

  • Page 6: Hardware List

    HARDWARE LIST ∅ 5/32*3/4" ∅ 1/4"*1-3/4" ∅ 3*14mm ∅ ∅ 3.5*14mm 8#*1" ∅ 3.5*35mm*7# TOOL LIST HARDWARE SPARE LIST x１ ∅ 06/30 5/32*3/4" ∅ ∅ ∅ 1/4"*1-3/4" 3*14mm ∅ 3.5*14mm 8#*1"...
  • Page 7 ASSEMBLY INSTRUCTIONS STEP-1 1.Attach leg (X/Y) to bottom panel (B) with bolt (#1), tight it with Allen wrench (#2). ∅ 1/4"*1-3/4" 07/30...
  • Page 8 ASSEMBLY INSTRUCTIONS STEP-2 1.Attach Magnet (#3) to front rail (C) with screw (#4), tight it with screwdriver (#16). ∅ 3*14mm 08/30...
  • Page 9 ASSEMBLY INSTRUCTIONS STEP-3 1.Slide front rail (C) to middle left vertical vertical panel (E) and middle right vertical panel (F). 09/30...
  • Page 10 ASSEMBLY INSTRUCTIONS STEP-4 1.Attach left side panel (D) and right side panel (G) to preassemble unit at step 3, and tight it with Allen wrench (#2). 10/30...
  • Page 11 ASSEMBLY INSTRUCTIONS STEP-5 Attach bottom panel (B) to preassemble unit at step 4, and tight it with Allen wrench (#2). 11/30...
  • Page 12 ASSEMBLY INSTRUCTIONS STEP-6 top panel (A) to preassemble unit at step 5, and tight it with 1.Attach Allen wrench (#2). 12/30...
  • Page 13 ASSEMBLY INSTRUCTIONS STEP-7 Attach back panel (H) to preassemble unit at step 6 with screw (#4), tight screw with screwdriver (#16). ∅ 3*14mm 13/30...
  • Page 14 ASSEMBLY INSTRUCTIONS STEP-8 lnsert shelf holder (#5) to preassemble unit at step 7, and attach adjustable shelf (I/J) to it. Shelf holder can be adjusted up or down 14/30...
  • Page 15 ASSEMBLY INSTRUCTIONS STEP-9 1.Connect part (N&O) to part (K) using screw #8 and tighten it with screwdriver #16.Slide in the part (R) into the groove in part (N&O). make sure they are also in groove in part (K). ∅ 8#*1" 15/30...
  • Page 16 ASSEMBLY INSTRUCTIONS STEP-10 1.Connect part (N&O) to part (P) using screw #8 and tighten it with screwdriver #16. 2.Attach konb (#6) to drawer front left (K) with bolt(#7),Tight bolt with screwdriver (#16). ∅ 5/32*3/4" ∅ 8#*1" 16/30...
  • Page 17 ASSEMBLY INSTRUCTIONS STEP-11 1.Connect part (N&O) to part (M) using screw #8 and tighten it with screwdriver #16.Slide in the part (R) into the groove in part (N&O). make sure they are also in groove in part (M). ∅ 8#*1" 17/30...
  • Page 18 ASSEMBLY INSTRUCTIONS STEP-12 1.Connect part (N&O) to part (P) using screw #8 and tighten it with screwdriver #16. 2.Attach konb (#6) to drawer front (M) with bolt(#7),Tight bolt with screwdriver (#16). ∅ ∅ 5/32*3/4" 8#*1" 18/30...
  • Page 19 ASSEMBLY INSTRUCTIONS STEP-13 1.Connect part (N&O) to part (L) using screw #8 and tighten it with screwdriver #16.Slide in the part (S) into the groove in part (N&O). make sure they are also in groove in part (L). ∅ 8#*1" 19/30...
  • Page 20 ASSEMBLY INSTRUCTIONS STEP-14 1.Connect part (N&O) to part (Q) using screw #8 and tighten it with screwdriver #16. 2.Attach konb (#6) to drawer front (L) with bolt(#7),Tight bolt with screwdriver (#16). ∅ ∅ 5/32*3/4" 8#*1" 20/30...
  • Page 21 ASSEMBLY INSTRUCTIONS STEP-15 Attention ： When installing the drawer,slide the steel ball slide rail of side panel to the most front as picture show. Female slider Male slider Schematic diagram of slide rail disassembly 21/30...
  • Page 22 ASSEMBLY INSTRUCTIONS STEP-16 1.connect part #9 to part (T/W) with screw #11, tight screw with screwdriver #16. 2. connect part #6 to part (T/W) with screw #7, tight screw with screwdriver #16. ∅ 5/32*3/4" ∅ 3.5*14mm 22/30...
  • Page 23 ASSEMBLY INSTRUCTIONS STEP-17 1.connect part #10 to part (U/V) with screw #11, tight screw with screwdriver #16. 2. connect part #6 to part (U/V) with screw #7, tight screw with screwdriver #16. ∅ 5/32*3/4" ∅ 3.5*14mm 23/30...
  • Page 24 ASSEMBLY INSTRUCTIONS STEP-18 1.Attach left door (T) and right door (W) to preassemble unit at step 15 with screw (#11), tight screw with screwdriver (#16). ∅ 3.5*14mm 24/30...
  • Page 25 ASSEMBLY INSTRUCTIONS STEP-19 1.Attach middle left door (U) and middle right door (V) to preassemble unit at step 18 with screw (#11), tight screw with screwdriver (#16). ∅ 3.5*14mm 25/30...
  • Page 26 ASSEMBLY INSTRUCTIONS STEP-20 Concealed hinges are three-way adjustable: Horizontal by screw adjustment! Concealed hinges are three-way adjustable: In-and-out by loosening the hinge arm mounting screw or via cam adjustment! Concealed hinges are three-way adjustable: Vertical via slots in the mounting plate or via cam adjustment! Hinge adjustment method 26/30...
  • Page 27 ASSEMBLY INSTRUCTIONS STEP-21 1.Attach bracket (#12) to preassemble unit at step 19, with screw (#11), and tight screw with screwdriver (#16). ∅ 3.5*14mm 27/30...
  • Page 28 ASSEMBLY INSTRUCTIONS ∅ 3.5*35mm*7# STEP-22 1.lnstall the anti-collapse device. 2.Mark the position on the wall, that corresponds to the location of part (#12) on the Top panel (A); Drill and insert the expandable screw (#13) by hammer. 3.Assemble the part (#12) to the well. Align the hole in the part (#12) with the expandable screw (#13), use screw (#14) to attach it and tighten by screwdriver (#16) 28/30...
  • Page 29 ASSEMBLY INSTRUCTIONS STEP-23 Let the plastic belt #15 pass through the both part #12 and pull tightly. #15x2 29/30...

  • Page 30: Warranty

    WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
